The Raybestos Voyager XP electric brake controller provides secure trailer braking when you need it most. As a tried-and-true proportional brake controller, the Voyager XP utilizes patented braking sensor technology and advanced electronics to provide a smooth braking response in any stopping situation. Its bi-colored LED brake indicator assures a complete connection between your vehicle and trailer, with the color changing gradually from green, which notes a completed circuit, to red to indicate relative braking power. This versatile controller has a compact design, a conveniently located power control knob to adjust settings, and a simple level knob for easy leveling during installation. Plus, the Voyager has a Plug & Play feature that allows for quick and easy connection with your vehicle?s wiring. The Raybestos Voyager XP trailer brake controller works with 1-4 axle trailers, comes with all the mounting hardware needed for installation.
| BRAND: | RAYBESTOS |
| PART NUMBER: | 761-9035 |
| WEIGHT: | 0.7 LBS |
| MATERIAL: | PLASTIC |
| BRAKE CONTROL TYPE: | PROPORTIONAL |
| TRAILER BRAKE WHEEL QUANTITY: | UP TO EIGHT WHEELS |
| LEVELING CAPABLE: | YES |
| BRAKE TYPE: | Electric |
| Diagnostic Capable: | YES |
| DISPLAY TYPE: | LED OUTPUT |
| HYDRAULIC CONNECTIONS: | NO |
| SOLID STATE CONSTRUCTION: | YES |
| CIRCUIT BREAKER PROTECTED: | YES |
| HOUSING COLOR: | BLACK |
| BRACKET INCLUDED: | YES |
Experts available to answer your questions
Call 888-634-94941 Year
1 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2005 - 2007 | Ford F-450 Super Duty | Cab & Chassis |
Yes, the 2005-2007 Ford F-450 Super Duty Raybestos Voyager XP Proportional Brake Controller for Trailers with 1 to 4 Axles Black 761-9035 (Part #761-9035 70347) is designed to fit the 2005-2007 Ford F-450 Super Duty.
The 2005-2007 Ford F-450 Super Duty Raybestos Voyager XP Proportional Brake Controller for Trailers with 1 to 4 Axles Black 761-9035 (Part #761-9035 70347) fits 2005-2007 Ford F-450 Super Duty models. The 2007 model year is the last year covered by this part number. For newer models, check for an updated version.
The 2005-2007 Ford F-450 Super Duty Raybestos Voyager XP Proportional Brake Controller for Trailers with 1 to 4 Axles Black 761-9035 (Part #761-9035 70347) fits the following vehicles: 2005-2007 Ford F-450 Super Duty. Always verify your specific year, make, and model before ordering.
The 2005-2007 Ford F-450 Super Duty Raybestos Voyager XP Proportional Brake Controller for Trailers with 1 to 4 Axles Black 761-9035 (Part #761-9035 70347) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
The 18287-037 adapter is designed for vehicles equipped with an OEM electric brake control harness. The harness must have a 4-pin Grey connector located behind the storage pocket just above the vehicle's ashtray towards the center of the dashboard. Check your vehicle's owner's manual or contact the manufacturer to confirm your vehicle has this specific OEM harness before purchasing.
Vehicles not equipped with an OEM trailer tow package may still work with the 18287-037, but they may require additional fuses and relays to complete the output and battery feed circuits. These components are sold separately. You will need to consult your vehicle's owner's manual for the locations where these fuses and relays should be installed.
The maximum capacity is 4 axles with 8 brakes, drawing a maximum of 24 amps. Do not exceed the lower of your towing manufacturer's rating or this limit. Overloading the circuit can cause fires.
The electric brake control harness is located behind the storage pocket just above the vehicle's ashtray towards the center of the dashboard. It has a 4-pin Grey connector that matches the end of the brake control adapter.
1. Locate the vehicle's electric brake control harness behind the storage pocket above the ashtray. 2. Carefully remove the storage pocket. 3. Locate the 4-pin Grey harness connector at the rear of the pocket. 4. Disconnect the harness from the storage pocket. 5. Plug the brake control adapter into the vehicle's electric brake control harness connector. 6. Follow all brake control manufacturer's installation instructions to complete the connection.
Yes. The caution states: plug the brake control adapter into the mating receptacle on the backside of the brake control before attaching to the vehicle connector.
Complete the installation per the electric brake control manufacturer's instructions and mount the unit as directed. Perform all test procedures as instructed by the brake control manufacturer. Do not operate the trailer brake system until all tests have been completed successfully.
Vehicles not equipped with an OEM trailer tow package may require fuses and relays to complete the output and battery feed circuits. These are sold separately. Consult your vehicle's owner's manual for the specific locations and specifications of any required fuses and relays.
The adapter fits vehicles with an OEM electric brake control harness (4-pin Grey connector) located behind the dashboard storage pocket above the ashtray. Check your vehicle's owner's manual to confirm compatibility.
Maximum 4 axles with 8 brakes at 24 amps. Do not exceed the lower of your towing manufacturer's rating or this limit.
Yes. Complete installation per the brake control manufacturer's instructions, mount the unit as directed, and perform all test procedures as instructed.
Vehicles without an OEM trailer tow package may require additional fuses and relays (sold separately). Consult your vehicle's owner's manual for locations and specifications.
