Select your vehicle to find the exact plug-and-play parts that fit — no cutting or splicing.
This fits: 2016-2019 Lexus RX350 All
Whatever your task at hand -- whether it's launching that boat before daybreak, setting up your camper before the rush or getting a final load to the dump before close -- CURT class 3 trailer hitches offer the strength needed for serious towing. They make it easy to hitch up and Bring It, offering a vehicle-specific fit and the weight capacity to handle a variety of trailers. Custom class 3 hitches are the most common type of receiver hitch for pickup trucks and SUVs. Because of their weight range, they are also found on full-size cars, crossovers and minivans. Each custom-fit class 3 hitch package is made for vehicle-specific mounting. This particular kit fits certain years of the Lexus RX350 (see application info to verify vehicle compatibility). It provides a weight carrying capacity of 4,000 lbs. GTW and 600 lbs. TW. It is also compatible with a weight distribution hitch for level towing and a rating of 5,000 lbs. WD and 600 lbs. WDTW. CURT class 3 trailer hitches are typically used to attach and haul utility trailers, boat trailers, campers, snowmobile or ATV haulers and more (NOTE: Never exceed the lowest-rated towing component). Each class 3 hitch has a 2" receiver tube and is tested in accordance with SAE J684 for safety. To ensure that CURT class 3 receiver hitches have what it takes for serious trailering, they are designed using a hands-on approach and are constructed with rugged, high-strength steel and precise welding. We also protect our class 3 hitches in a co-cured finish of liquid A-coat and black powder coat for superior resistance to rust, chipping and UV damage.
Trailer hitch weight ratings are limited to vehicle manufacturer's stated capacities
Not compatible for use with vertical hanging bicycles (bike racks that require the bicycles to be hung / mounted vertically)
Includes installation hardware
2016, 2017, 2018, 2019 Lexus RX350 All Class 3 Trailer Hitch, 2" Receiver, Select Lexus RX350
CURT offers a variety of high-quality trailer hitches and accessories for select vehicle models. Find the perfect fit for your towing needs at TowUniverse.
CURT, a Lippert brand, offers a complete line of towing products and is the leading manufacturer of custom-fit trailer hitches. We offer the broadest selection of custom-fit hitches, and each one is designed, welded, and coated in Wisconsin.
CURT is also a leader in flat towing products, as well as 5th wheel, gooseneck, and weight distribution hitches, ball mounts, electrical components, cargo solutions, and other towing accessories.
For everything from passenger cars and vans to full-size pickups and SUVs, CURT is 'The First Name in Towing Products®.'
Experts available to answer your questions
Call 888-634-9494Lifetime
1 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2016 - 2019 | Lexus RX350 | — |
The 2016-2019 Lexus RX350 All CURT Class 3 Trailer Hitch, 2" Receiver + 2" Ball + 1-7/8" Ball Kit (Part #CHD-13272-001) fits the following vehicles: 2016-2019 Lexus RX350. Always verify your specific year, make, and model before ordering.
Yes, the 2016-2019 Lexus RX350 All CURT Class 3 Trailer Hitch, 2" Receiver + 2" Ball + 1-7/8" Ball Kit (Part #CHD-13272-001) is designed to fit the 2016-2019 Lexus RX350.
The 2016-2019 Lexus RX350 All CURT Class 3 Trailer Hitch, 2" Receiver + 2" Ball + 1-7/8" Ball Kit (Part #CHD-13272-001) fits 2016-2019 Lexus RX350 models. The 2019 model year is the last year covered by this part number. For newer models, check for an updated version.
The 2016-2019 Lexus RX350 All CURT Class 3 Trailer Hitch, 2" Receiver + 2" Ball + 1-7/8" Ball Kit (Part #CHD-13272-001) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
Yes, CURT part number 13272 is designed for 2016-Present Lexus RX350 SUVs. Before purchasing, verify your vehicle matches this year range and model. If you have a different model year or variant, contact CURT technical support at 877-287-8634 to confirm fitment.
When used as a weight carrying hitch, the CURT 13272 supports a maximum trailer weight of 4,000 lbs and tongue weight of 600 lbs. When used as a weight distribution hitch, it supports a maximum trailer weight of 5,000 lbs and tongue weight of 600 lbs. However, you must never exceed your vehicle manufacturer's recommended towing capacity, which may be lower than these ratings.
The hitch weight is 30 lbs.
You will need: 17mm socket, 19mm socket, 6-inch extension, ratchet, torque wrench, screwdriver, and safety glasses. A torque wrench is essential because all fasteners must be torqued to exactly 86 ft-lbs.
No, drilling is not required. The CURT 13272 uses existing weld nuts already present in the frame of your 2016-Present Lexus RX350.
While one person may be able to install the hitch, CURT recommends that 2 people may be required to ease installation. If you are hesitant to undertake this task on your own, contact an authorized CURT installer for additional assistance.
1. Using a 17mm socket, remove the 2 existing 12mm bolts from the tow loop and return them to the owner. Remove 5 plugs from the bottom of the driver side frame rail and 2 plugs from the passenger side frame rail. 2. Raise the hitch into position and loosely secure it with the supplied M12 bolts and conical washers. 3. Torque all hardware to 86 ft-lbs.
All M12 bolts and fasteners must be torqued to 86 ft-lbs. Use a torque wrench to ensure this specification is met exactly.
The kit includes 6 M12x1.25 grade 10.9 hex cap screws (part number 10-10277) and 6 conical washers (part number 30-00149). These fasteners are used to secure the hitch to the existing weld nuts in the vehicle frame.
Safety glasses must be worn at all times while installing this product. Before you begin installation, read all instructions thoroughly. Using proper tools will greatly improve the quality of the install and reduce the time required.
Periodically check the receiver hitch to ensure all fasteners are tight and all structural components are sound. This ongoing inspection helps maintain the integrity and safety of the hitch.
Yes, the CURT 13272 complies with safety specifications and requirements for connecting devices and towing systems of the state of New York, V.E.S.C. Regulation V-5 and SAE J684.
CURT Manufacturing warrants this product to be free of defects in material and/or workmanship at the time of retail purchase by the original purchaser. If the product is found to be defective, CURT may repair or replace it at their option when returned prepaid with proof of purchase. Alteration to, misuse of, or improper installation voids the warranty. CURT's liability is limited to repair or replacement of defective products and excludes liability for incidental or consequential loss or damage.
The CURT 13272 is designed for 2016-Present Lexus RX350 SUVs. Verify your vehicle matches this year range and model before purchasing.
No, drilling is not required. The hitch uses existing weld nuts in the vehicle frame.
You need 17mm and 19mm sockets, 6-inch extension, ratchet, torque wrench, screwdriver, and safety glasses. A torque wrench is essential for tightening to 86 ft-lbs.
As a weight carrying hitch: 4,000 lbs trailer weight, 600 lbs tongue weight. As a weight distribution hitch: 5,000 lbs trailer weight, 600 lbs tongue weight. Never exceed your vehicle manufacturer's recommended capacity.
All M12 fasteners must be torqued to 86 ft-lbs using a torque wrench.
Never exceed your vehicle manufacturer's recommended towing capacity. Wear safety glasses during installation. Periodically check all fasteners and structural components.
