01-05 Hyundai Elantra Hatchback CURT 4-flat Plug and Play Trailer WiringCURT$66.76In Stock
View productAsk a Question About This Product
Our in-house experts typically reply within one business day.
Our in-house experts typically reply within one business day.
CURT
Verify Fitment
Select your vehicle to confirm this part fits.
Always the correct part
We know our products
Quality Products
Free Shipping!
Always the correct part
We know our products
Quality Products
Free Shipping!
| Converter Type | Circuit Protected |
| Electrical System Type | 3W |
| Finish | N/A |
| Material | Blank |
| Mount Type Description | Blank |
| Output Type | 4-Way Flat |
| Side Application Type Description | Blank |
| T-Connector Location | P3,P4 |
| Tail Light Circuits | 7.5 Amps |
| Turn and Brake Circuits | 3.0 Amps |
| Warranty | One-Year Limited Warranty |
CURT offers a variety of high-quality trailer hitches and accessories for select vehicle models. Find the perfect fit for your towing needs at TowUniverse.
CURT, a Lippert brand, offers a complete line of towing products and is the leading manufacturer of custom-fit trailer hitches. We offer the broadest selection of custom-fit hitches, and each one is designed, welded, and coated in Wisconsin.
CURT is also a leader in flat towing products, as well as 5th wheel, gooseneck, and weight distribution hitches, ball mounts, electrical components, cargo solutions, and other towing accessories.
For everything from passenger cars and vans to full-size pickups and SUVs, CURT is 'The First Name in Towing Products®.'
Experts available to answer your questions
Call 888-634-94941 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2009 - 2012 | Hyundai Elantra | Hatchback |
The 09-12 Hyundai Elantra Hatchback CURT 4-flat Plug and Play Trailer Wiring (Part #CTW1402) fits the following vehicles: 2009-2012 Hyundai Elantra. Always verify your specific year, make, and model before ordering.
The 09-12 Hyundai Elantra Hatchback CURT 4-flat Plug and Play Trailer Wiring (Part #CTW1402) fits 2009-2012 Hyundai Elantra models. The 2012 model year is the last year covered by this part number. For newer models, check for an updated version.
Yes, the 09-12 Hyundai Elantra Hatchback CURT 4-flat Plug and Play Trailer Wiring (Part #CTW1402) is designed to fit the 2009-2012 Hyundai Elantra.
The 09-12 Hyundai Elantra Hatchback CURT 4-flat Plug and Play Trailer Wiring (Part #CTW1402) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
Yes, part number 55310 is designed for both Hyundai Santa Fe and Hyundai Elantra. However, the installation procedure differs slightly between the two models. Santa Fe owners remove the rear cargo shade, threshold plate, storage covers and floor covering, then partially remove rear interior trim panels. Elantra owners remove rear storage compartments via four Phillips head screws on each side, the foam spare tire cover, and the rear threshold before removing felt trim panels.
For a Santa Fe, open the rear hatch and temporarily remove: the rear cargo shade, threshold plate, storage covers, and floor covering. Then partially remove the rear interior trim panels on both driver and passenger sides by removing the tie-down loop and several trim panel fasteners. Pull back the trim panels to reveal the vehicle's tow harness.
For an Elantra, open the rear hatch and remove the rear storage compartments by removing four Phillips head screws on each side. Also remove the foam spare tire cover. Remove the rear threshold by removing the trim fasteners on each side, then remove the trim fasteners holding the felt trim panels in place. Pull back the trim panels to reveal the vehicle's tow harness.
Disconnect the vehicle's wiring harness connectors on the driver's side, being careful not to break the locking tabs. Plug the T-connector with the yellow wire in between the two separate halves of the vehicle's harness. This allows the factory harness to pass through the T-connector while adding the new wiring.
The T-connector has a yellow wire that connects to the driver's side harness and a green wire that connects to the passenger's side harness. The yellow wire stays at the driver's side connection point, while the green wire end of the T-connector is routed to the passenger's side behind the panels and along the threshold for the passenger-side ground connection.
Drilling may be required. The manual instructs you to locate a suitable grounding point near the connector, such as an existing ground stud. If no existing ground stud is available, you will need to drill a 3/32" hole to secure the white wire with an eyelet using the screw provided. Do not drill into any exposed surfaces. Before drilling, verify that miscellaneous items hidden behind or under surfaces are not in the way to avoid damage to the vehicle and personal injury.
If a suitable existing ground stud is not available, drill a 3/32" hole to secure the white wire with an eyelet using the screw provided.
Locate a suitable grounding point near the connector, such as an existing ground stud. Secure the white wire with an eyelet using the screw provided. If no existing ground stud is available, drill a 3/32" hole and secure the white wire there. Do not drill into any exposed surfaces. Repeat this process for the passenger's side using the T-connector end with the green wire.
Route the T-connector end with the green wire to the passenger's side behind the panels and along the threshold. Mount the black box converter out of the way using the double-sided tape or cable tie provided, and secure all loose wires with cable ties. Route the 4-flat under the driver's side trim panel into the floor storage compartment and store it there when not in use.
Route the 4-flat under the driver's side trim panel into the floor storage compartment and store it there when not in use. Note: It may be necessary to cut a slit or notch in the storage tray to allow the 4-flat to fit in the compartment.
The 55310 includes double-sided tape or cable ties to mount the black box converter, a screw for securing the white wire eyelet to the grounding point, and cable ties to secure all loose wires.
Before drilling, verify that miscellaneous items hidden behind or under any surfaces are not in the way. Do not drill into any exposed surfaces. This precaution is necessary to avoid damage to the vehicle and personal injury.
When disconnecting the vehicle's wiring harness connectors on the driver's side, be careful not to break the locking tabs. The T-connector plugs in between the two separate halves of the harness.
It may be necessary to cut a slit or notch in the storage tray to allow the 4-flat connector to fit in the floor storage compartment where it is stored when not in use. Whether cutting is required depends on the fit of the 4-flat in your specific vehicle's storage compartment.
The 55310 fits Hyundai Santa Fe and Hyundai Elantra. Installation procedures differ between the two models.
Drilling may be required if no existing ground stud is available. You may need to drill a 3/32" hole for the white wire grounding point. You may also need to cut a slit or notch in the storage tray for the 4-flat connector.
The 55310 T-connector plugs between the vehicle's factory wiring harness halves on the driver's side (yellow wire) and passenger's side (green wire). White wires ground to existing ground studs or drilled holes on both sides.
Before drilling, verify that no miscellaneous items are hidden behind or under the surfaces where you plan to drill. Do not drill into any exposed surfaces.
