Complete CURT Class 1 1-1/4" trailer hitch and 4-flat custom wiring kit engineered for the 2011 - 2015 Chevrolet Cruze Sedan, excluding diesel. Vehicle-specific fit, plug-and-play installation, all hardware and instructions included.
This custom kit fits the following vehicles:
All Hardware and Installation Instructions Included!
However you define adventure -- whether it's climbing onto the back of a mountain bike, hunting from the top of a tree stand or camping with the family a long way from nowhere -- CURT class 1 hitches provide a light-duty towing receiver to help you Bring It. Each is made to fit a specific vehicle, providing easier installation, a better fit and optimal towing capacity. Custom class 1 trailer hitches are available for a variety of smaller vehicle types, including the compact car, crossover, minivan and small SUV. This particular class 1 hitch is designed to be a custom hitch for certain years of the Chevy Cruze and Buick Verano (to verify vehicle compatibility, see the CURT application guide at curtmfg.com). Tested in accordance with SAE J684, it offers a weight carrying capacity of 2,000 lbs. GTW and 200 lbs. TW. It is equipped with 1-1/4" receiver tube opening to accept a ball mount shank or other hitch mount. This class 1 hitch also comes with all necessary mounting hardware. With its lightweight design and smaller receiver tube size, a class 1 hitch is especially useful for adding cargo space with a hitch-mounted bike rack or cargo carrier. They can also typically be used to tow small trailers such as a utility trailer, kayak trailer or teardrop camper (never exceed the lowest weight capacity of any towing component; i.e. the vehicle, hitch, trailer, etc). Though CURT class 1 trailer hitches are only intended for light-duty towing, we apply the same principles of quality as we do to the rest of our rear mount hitches. Each class 1 hitch is made with hands-on engineering, high-strength steel and precise welding. We use a co-cured finish of liquid A-coat, inside and out, and durable black powder coat to provide a lasting defense against rust, chips and UV rays.
If your vehicle is not equipped with wiring for towing a trailer, CURT custom wiring is the ideal solution. A custom wiring harness -- also called a T-connector -- is a simple, plug-and-play electrical device that plugs into your automotive electric system and provides a standard, universal trailer wiring connection. This is done using two or more vehicle-specific, OEM-compatible connectors to plug into the taillight assembly, eliminating the need for cutting, splicing and soldering during installation. Custom wiring harnesses are made vehicle-specific, and while they are not available for all vehicles, they do offer one of the fastest, easiest and most secure ways to wire a vehicle for towing. This particular plug-in harness provides a 4-way flat connector socket and is designed to be a custom wiring harness to fit certain years of the Chevy Cruze (to verify your vehicle compatibility, see application info). It comes with all necessary wiring components to establish a reliable trailer wiring connection, as well as a dust cover to keep the connector clean when not in use. You have a picture in mind of your next destination -- maybe it's the boat landing at your favorite fishing spot, maybe it's a campsite that overlooks one of nature's masterpieces, or maybe it's the next big jobsite. However, turning that picture into a reality takes more than just daydreaming. It takes a solid connection and the right amount of power. CURT custom wiring is made with some of the most sophisticated technology in the industry and is designed to install with ease, giving you a long-lasting electrical connection for your towing hitch setup.
CURT offers a variety of high-quality trailer hitches and accessories for select vehicle models. Find the perfect fit for your towing needs at TowUniverse.
CURT, a Lippert brand, offers a complete line of towing products and is the leading manufacturer of custom-fit trailer hitches. We offer the broadest selection of custom-fit hitches, and each one is designed, welded, and coated in Wisconsin.
CURT is also a leader in flat towing products, as well as 5th wheel, gooseneck, and weight distribution hitches, ball mounts, electrical components, cargo solutions, and other towing accessories.
For everything from passenger cars and vans to full-size pickups and SUVs, CURT is 'The First Name in Towing Products®.'
Experts available to answer your questions
Call 888-634-94941 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2011 - 2015 | Chevrolet Cruze | Sedan, excluding diesel |
The 11 - 15 Chevrolet Cruze Sedan, excluding diesel Curt 1-1/4", Class 1 Trailer Tow Hitch + 4-flat Wiring Kit 11282 (Part #CHW-370) fits 2011-2015 Chevrolet Cruze models. The 2015 model year is the last year covered by this part number. For newer models, check for an updated version.
The 11 - 15 Chevrolet Cruze Sedan, excluding diesel Curt 1-1/4", Class 1 Trailer Tow Hitch + 4-flat Wiring Kit 11282 (Part #CHW-370) fits the following vehicles: 2011-2015 Chevrolet Cruze. Always verify your specific year, make, and model before ordering.
Yes, the 11 - 15 Chevrolet Cruze Sedan, excluding diesel Curt 1-1/4", Class 1 Trailer Tow Hitch + 4-flat Wiring Kit 11282 (Part #CHW-370) is designed to fit the 2011-2015 Chevrolet Cruze.
The 11 - 15 Chevrolet Cruze Sedan, excluding diesel Curt 1-1/4", Class 1 Trailer Tow Hitch + 4-flat Wiring Kit 11282 (Part #CHW-370) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
Yes, part number 11282 is designed for Chevrolet Cruze and Buick Verano sedans from 2011 to present. However, it does not fit diesel models. Confirm your vehicle is a sedan and non-diesel before purchasing.
No. Part number 11282 is designed for Chevrolet Cruze and Buick Verano models excluding diesel variants. You will need a different hitch model for a diesel vehicle.
The hitch has a gross load capacity of 2,000 lbs trailer weight and 200 lbs tongue weight when used as a weight-carrying hitch. However, you must not exceed your vehicle manufacturer's recommended towing capacity, which may be lower.
The hitch weight is 35 lbs.
Required tools are: ratchet, torque wrench, 3/4" socket, 13 mm socket, aviation shears, safety glasses, and tape measure. No power tools or drilling equipment is needed.
The kit includes: 4× .250 x .88 x 2.25" square hole spacers (CM-SP2), 4× 7/16-14 UNC 1-1/4" grade 8 carriage bolts (10-10281), 4× 7/16-14 UNC grade 8 serrated flange nuts (20-00103), and 2× 7/16" fishwire.
No. The hitch uses existing holes on both frame rails. No drilling is required.
Two people may be required to ease installation. One person may be able to complete the installation, but having a second person is recommended.
The manual does not specify whether the battery must be disconnected. Contact Curt technical support at 1-877-287-8634 for clarification.
Only if a heat shield is present on your vehicle. If present, you must trim it to access the access hole in the frame. The trim dimensions are approximately 2.50 inches by 2.25 inches, but you should confirm the exact dimensions on your vehicle before trimming, as they are approximate. Use aviation shears for trimming.
The fishwire technique involves threading the 7/16" fishwire through the access holes in the frame and out through the mounting holes. The fishwire is then used to guide the 7/16" carriage bolts and CM-SP2 spacers into position. A detailed fishwire technique diagram is referenced in the manual on page 2, which should be consulted for the specific threading method.
Yes. Before installation, you must lower the exhaust by removing 2 rubber isolators from the muffler towards the center of the vehicle and removing the bolt securing the rearmost hanger to the frame. After the hitch is secured, you raise the exhaust back into position. Exhaust configuration varies by model.
All 7/16" hardware (carriage bolts and flange nuts) must be torqued to 70 ft-lbs.
All non-trailer loads (wheel-less loads) applied to this hitch must be supported by Curt 18050 stabilizing straps. Failure to properly support non-trailer loads will void the product warranty.
Safety glasses must be worn at all times while installing this product.
Periodically check the receiver hitch to ensure that all fasteners are tight and that all structural components are sound. This maintenance is essential for safe operation.
The hitch is designed for use with ball mount #D-221 or #45522. Euro mount options are available: #45591 (1-7/8" ball) or #45592 (2" ball).
Curt Manufacturing warrants the product to be free of defects in material and workmanship at the time of retail purchase by the original purchaser. If defective, Curt may repair or replace the product at their option when returned prepaid with proof of purchase. Alteration, misuse, or improper installation voids the warranty. Curt's liability is limited to repair or replacement and excludes incidental or consequential loss or damage.
Yes, for 2011-present sedans excluding diesel models. Confirm your vehicle is non-diesel before purchasing.
2,000 lbs trailer weight and 200 lbs tongue weight, but do not exceed your vehicle manufacturer's recommended towing capacity.
No drilling required. The hitch uses existing frame holes. You will need a ratchet, torque wrench, 3/4" and 13 mm sockets, aviation shears, safety glasses, and tape measure.
Only if a heat shield is present. Trim approximately 2.50 x 2.25 inches (confirm dimensions on your vehicle) using aviation shears to access the frame access hole.
Torque all 7/16" hardware (carriage bolts and flange nuts) to 70 ft-lbs.
All non-trailer (wheel-less) loads must be supported by Curt 18050 stabilizing straps. Failure to do so voids the warranty.
Periodically check that all fasteners are tight and all structural components are sound.
Yes, the T-Connector with Install Kit (part number 56214) is designed for the Chevrolet Cruze.
Yes, you must disconnect the negative battery terminal before beginning installation. This is a required safety step performed early in the installation process.
The vehicle's wiring harness connectors are located in the trunk behind the taillight in positions P3 and P4, as shown in the Wiring Location Guide. On the driver's side, pull back the felt trunk liner to locate the taillight wiring harness connectors.
Remove the spare tire cover, then remove the two plastic push fasteners on the rear scuff panel and pull the scuff panel out at the bottom and then up. Also remove the plastic push fastener holding the felt trunk liner in place and pull back the felt liner to access the taillight wiring harness connectors.
Separate the vehicle's taillight wiring harness connectors from the taillight housing, taking care not to damage the locking tabs. Insert the T-Connector end with the yellow wire between the separated connectors. Make sure the connectors are fully inserted with locking tabs in place.
Yes, you must drill a 3/32" pilot hole for the ground screw, unless a suitable existing screw with nut is available in the vehicle's frame near the connector. Before drilling, verify that miscellaneous items hidden behind or under surfaces will not be damaged.
Drill a 3/32" pilot hole for the provided ground screw. The drilling area should be free of rust, dirt or paint.
Locate a suitable grounding point near the connector, such as an existing screw with nut in the vehicle's frame, or drill a 3/32" pilot hole for the provided screw. The area should be free of rust, dirt or paint. Secure the white ground wire using the ring terminal and screw provided.
Yes, the installation requires T-Connectors on both sides. After installing the yellow-wire T-Connector on the driver's side, route the green-wire T-Connector to the passenger side behind the removed scuff panels and repeat the connection steps on the passenger side.
Inside the vehicle, locate a flat spot and adhere the black converter box using the double-sided tape provided.
The battery connection must be fuse protected with a maximum of 10 amps. Exceeding this rating can cause loss of warranty, overheating and potential fire.
Signal Circuits: 7.5 amps per side. Tail/Running Circuits: 7.5 amps total. Do not exceed the tow vehicle's lamp load rating or the product rating, whichever is lower.
Route the 4-flat wire to the center of the vehicle when in use. When not in use, roll it up and store in a convenient, out-of-the-way location.
Reinstall all items removed during installation, then connect the negative battery terminal.
Before drilling, verify that miscellaneous items hidden behind or under any surface will not be damaged. This is necessary to avoid damage to vehicle components and personal injury.
Exceeding the product rating can cause loss of warranty, overheating and potential fire. Do not exceed the tow vehicle's lamp load rating or the product rating (Signal Circuits 7.5 amps per side, Tail/Running Circuits 7.5 amps total), whichever is lower.
The Curt 56214 T-Connector with Install Kit is designed for the Chevrolet Cruze.
Yes, disconnect the negative battery terminal before starting installation.
Yes, you must drill a 3/32" pilot hole for the ground screw unless an existing screw with nut is available in the vehicle frame.
The battery connection must be fuse protected with a maximum of 10 amps.
Signal Circuits: 7.5 amps per side. Tail/Running Circuits: 7.5 amps total. Do not exceed the tow vehicle's lamp load rating or the product rating, whichever is lower.
