Complete CURT Class 1 1-1/4" trailer hitch and 5-flat wiring kit (with 4-way to 5-way adapter for surge brakes) engineered for the 2012 - 2016 Honda CR-V. Vehicle-specific fit, plug-and-play installation, all hardware and instructions included.
This custom kit fits the following vehicles:
All Hardware and Installation Instructions Included!
However you define adventure -- whether it's climbing onto the back of a mountain bike, hunting from the top of a tree stand or camping with the family a long way from nowhere -- CURT class 1 hitches provide a light-duty towing receiver to help you Bring It. Each is made to fit a specific vehicle, providing easier installation, a better fit and optimal towing capacity. Custom class 1 trailer hitches are available for a variety of smaller vehicle types, including the compact car, crossover, minivan and small SUV. This particular class 1 hitch is designed to be a custom hitch for certain years of the Honda CR-V (to verify vehicle compatibility, see the CURT application guide at curtmfg.com). Tested in accordance with SAE J684, it offers a weight carrying capacity of 2,000 lbs. GTW and 200 lbs. TW. It is equipped with 1-1/4" receiver tube opening to accept a ball mount shank or other hitch mount. This class 1 hitch also comes with all necessary mounting hardware. With its lightweight design and smaller receiver tube size, a class 1 hitch is especially useful for adding cargo space with a hitch-mounted bike rack or cargo carrier. They can also typically be used to tow small trailers such as a utility trailer, kayak trailer or teardrop camper (never exceed the lowest weight capacity of any towing component; i.e. the vehicle, hitch, trailer, etc). Though CURT class 1 trailer hitches are only intended for light-duty towing, we apply the same principles of quality as we do to the rest of our rear mount hitches. Each class 1 hitch is made with hands-on engineering, high-strength steel and precise welding. We use a co-cured finish of liquid A-coat, inside and out, and durable black powder coat to provide a lasting defense against rust, chips and UV rays.
If your vehicle is not equipped with wiring for towing a trailer, CURT custom wiring is the ideal solution. A custom wiring harness -- also called a T-connector -- is a simple, plug-and-play electrical device that plugs into your automotive electric system and provides a standard, universal trailer wiring connection. This is done using two or more vehicle-specific, OEM-compatible connectors to plug into the taillight assembly, eliminating the need for cutting, splicing and soldering during installation. Custom wiring harnesses are made vehicle-specific, and while they are not available for all vehicles, they do offer one of the fastest, easiest and most secure ways to wire a vehicle for towing. This particular plug-in harness provides a 4-way flat connector socket and is designed to be a custom wiring harness to fit certain years of the Honda CRV (to verify your vehicle compatibility, see application info). It comes with all necessary wiring components to establish a reliable trailer wiring connection, as well as a dust cover to keep the connector clean when not in use. You have a picture in mind of your next destination -- maybe it's the boat landing at your favorite fishing spot, maybe it's a campsite that overlooks one of nature's masterpieces, or maybe it's the next big jobsite. However, turning that picture into a reality takes more than just daydreaming. It takes a solid connection and the right amount of power. CURT custom wiring is made with some of the most sophisticated technology in the industry and is designed to install with ease, giving you a long-lasting electrical connection for your towing hitch setup.
CURT offers a variety of high-quality trailer hitches and accessories for select vehicle models. Find the perfect fit for your towing needs at TowUniverse.
CURT, a Lippert brand, offers a complete line of towing products and is the leading manufacturer of custom-fit trailer hitches. We offer the broadest selection of custom-fit hitches, and each one is designed, welded, and coated in Wisconsin.
CURT is also a leader in flat towing products, as well as 5th wheel, gooseneck, and weight distribution hitches, ball mounts, electrical components, cargo solutions, and other towing accessories.
For everything from passenger cars and vans to full-size pickups and SUVs, CURT is 'The First Name in Towing Products®.'
Experts available to answer your questions
Call 888-634-94941 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2012 - 2016 | Honda CR-V | — |
The 12 - 16 Honda CR-V Curt 1-1/4" Class 1 Trailer Tow Hitch + 5-Flat Wiring Kit Tow Boat/Utility Trailer with Surge Brakes 11555 (Part #5W-CHW-1749) fits 2012-2016 Honda CR-V models. The 2016 model year is the last year covered by this part number. For newer models, check for an updated version.
The 12 - 16 Honda CR-V Curt 1-1/4" Class 1 Trailer Tow Hitch + 5-Flat Wiring Kit Tow Boat/Utility Trailer with Surge Brakes 11555 (Part #5W-CHW-1749) fits the following vehicles: 2012-2016 Honda CR-V. Always verify your specific year, make, and model before ordering.
Yes, the 12 - 16 Honda CR-V Curt 1-1/4" Class 1 Trailer Tow Hitch + 5-Flat Wiring Kit Tow Boat/Utility Trailer with Surge Brakes 11555 (Part #5W-CHW-1749) is designed to fit the 2012-2016 Honda CR-V.
The 12 - 16 Honda CR-V Curt 1-1/4" Class 1 Trailer Tow Hitch + 5-Flat Wiring Kit Tow Boat/Utility Trailer with Surge Brakes 11555 (Part #5W-CHW-1749) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
Yes, CURT part number 11555 is designed for Honda CR-V. The manual specifies this product is designed for use with ballmount #55001 / 45501.
Yes. Step 1 requires you to remove 10 fasteners and lower the underbody panel. If the panel is present, you will need to raise it together with the hitch during installation (Step 6), and reattach it using the original fasteners after installation is complete (Step 11).
Yes. Step 2 requires you to lower the exhaust by removing rubber isolators from muffler hangers. After installation is complete, Step 12 requires you to raise the exhaust back into position and re-install the rubber isolators.
Yes. Step 3 requires you to mark and trim the underbody panel. The manual notes that dimensions are approximate and you must confirm fit prior to trimming. Use the ribs of the underbody panel as cutting guides. Refer to the underbody panel trim diagram for guidance.
Yes. Step 4 requires you to enlarge existing holes in both frame rails to allow access for 1.00 x 3.00 spacers to be inserted. The manual notes that dimensions are approximate; confirm fit prior to enlarging.
The kit includes: 2× 7/16-14 UNC 1-1/2" grade 8 carriage bolts (10-10282); 1× 1/2-13 UNC 2-1/2" grade 8 carriage bolt (10-10306); 1× 1/2-13 UNC serrated flange nut (20-00062); 2× 7/16-14 UNC serrated flange nuts (20-00103); 2× 0.250 x 1.00 x 2.50" square hole spacers (CM-SP11); 3× 0.250 x 1.00 x 2.00" square hole spacers (CM-SP12); and 2× 7/16" fishwire.
1. Remove underbody panel fasteners and lower panel. 2. Lower exhaust by removing rubber isolators. 3. Mark and trim underbody panel. 4. Enlarge existing frame rail holes. 5. Reverse fishwire carriage bolts and blocks into frame rails. 6. Raise hitch into position (with underbody panel if present). 7. Loosely install tow hook attachment bolt and spacers. 8. Level hitch and install tow loop attachment fasteners and tighten. 9. Loosely install hex flange nuts. 10. Torque fasteners. 11. Reattach underbody panel. 12. Raise exhaust and re-install rubber isolators.
Step 8 requires levelling the hitch and installing tow loop attachment fasteners before tightening other fasteners. This must be done to prevent the receiver tube from angling up when other fasteners are tightened.
Torque all 7/16" hardware to 59 lb-ft. Torque all 1/2" hardware to 110 lb-ft. This applies to the carriage bolts and flange nuts specified in the parts list.
All non-trailer loads applied to this product must be supported by 18050 stabilizing straps. Failure to properly support non-trailer loads will void the product warranty.
Do not exceed your vehicle manufacturer's recommended towing capacity. This is a requirement stated in the product warnings.
Periodically check the receiver hitch to ensure that all fasteners are tight and that all structural components are sound. This is a requirement stated in the installation notes.
CURT 11555 is designed for use with ballmount #55001 / 45501.
This product complies with safety specifications and requirements for connecting devices and towing systems of the state of New York, V.E.S.C. Regulation V-5 and SAE J684.
Yes, CURT 11555 is designed for Honda CR-V and works with ballmount #55001 / 45501.
Yes. You must remove the underbody panel fasteners and lower the exhaust by removing rubber isolators from muffler hangers before installation. Both are reattached after the hitch is installed.
Yes. You must trim the underbody panel and enlarge existing frame rail holes to accommodate the 1.00 x 3.00 spacers. Dimensions are approximate; confirm fit before cutting.
Torque all 7/16" hardware to 59 lb-ft and all 1/2" hardware to 110 lb-ft.
All non-trailer loads must be supported by 18050 stabilizing straps. Do not exceed your vehicle manufacturer's recommended towing capacity. Failure to properly support non-trailer loads voids the warranty.
Periodically check that all fasteners are tight and all structural components are sound.
The Curt 56158 is a custom wiring harness that integrates with your vehicle's taillight system to provide trailer lighting control. It includes a converter box that processes the vehicle's taillight signals and outputs a 4-flat connector for trailer connection.
Yes, the Curt 56158 is designed for the Honda CR-V. It is listed in the applications section for SUVs, Mini & Full-Sized Vans category.
The manual only confirms fitment for the Honda CR-V. For other vehicles, contact Curt Manufacturing or consult a fitment database to verify compatibility.
You will need a panel trim removal tool. Depending on your grounding point choice, you may also need a drill with a 3/32" bit if you choose to drill a new pilot hole instead of using an existing vehicle screw.
The harness includes a converter box, a white ground wire with ring terminal, a provided screw for grounding, double-sided tape for the converter box, a 10-amp fuse, a fuse holder with cap, cable ties for securing loose wires, and a 4-flat dust cover.
No. Step 1 requires you to open the vehicle tailgate and remove all trunk floor coverings to access the rear trim panels and taillight wiring harness connectors.
Open the tailgate and remove trunk floor coverings. Remove the rear scuff panel by pushing in the center of the two push fasteners and pulling the panel out at the bottom then up. On the driver side, remove the cargo loop and two plastic fasteners securing the rear trim panel, then remove the two screws securing the seat release handle. Pull back on the rear trim panel to locate the taillight wiring harness connectors. On some models, you may need to gently pull back the upper trim panel or remove the finish panel behind the driver side rear seat for better access.
Separate the vehicle's taillight housing connectors carefully, taking care not to damage the locking tabs. Insert the custom wiring harness end between the separated connectors. Make sure the connectors are fully inserted with locking tabs in place.
Locate a flat spot inside the vehicle near the taillight and adhere the black converter box using the provided double-sided tape.
Locate a suitable grounding point near the connector, such as an existing screw with nut in the vehicle frame. If no suitable point exists, drill a 3/32" pilot hole. The area should be free of rust, dirt and paint. Secure the white ground wire using the ring terminal and provided screw.
Install the 10-amp low profile mini fuse into the vehicle's fuse panel in position 10. The fuse panel is located under the dash.
Install the 10-amp fuse provided in the fuse holder and install the fuse holder cap.
When in use, route the 4-flat to the center of the vehicle. When not in use, roll it up and store in a convenient, out-of-the-way location.
Secure any loose wires with the provided cable ties.
Reinstall all items removed during installation. Install the provided 4-flat dust cover to help prevent corrosion. Test for proper function by using a test light or connecting a properly wired trailer.
Drilling is not always required. You only need to drill a 3/32" pilot hole if no suitable existing screw with nut is available in the vehicle frame near the taillight connector for the ground wire. Before drilling, check for miscellaneous items hidden behind or under surfaces to avoid damage and personal injury.
The battery connection must be fuse-protected with a 10-amp maximum fuse. Exceeding this rating can cause loss of warranty, overheating and potential fire.
Signal Circuits are rated at 3.0 amps per side. Tail/Running Circuits are rated at 6.0 amps total. Do not exceed these ratings or the tow vehicle lamp load rating, whichever is lower.
The manual does not specify a maximum tow vehicle lamp load rating. Check your vehicle owner's manual or contact the vehicle manufacturer for this information. You must not exceed the product rating or tow vehicle lamp load rating, whichever is lower.
Before drilling, check for miscellaneous items that may be hidden behind or under any surface to avoid damage and personal injury.
Test for proper function by using a test light or connecting a properly wired trailer. All steps must be followed to ensure the wiring harness will function properly.
Yes, the Curt 56158 is designed for the Honda CR-V.
The Curt 56158 requires a 10-amp maximum fuse. Do not exceed this rating as it can cause overheating and potential fire.
Signal Circuits: 3.0 amps per side. Tail/Running Circuits: 6.0 amps total. Do not exceed these ratings or the tow vehicle lamp load rating, whichever is lower.
