Select your vehicle to find the exact plug-and-play parts that fit — no cutting or splicing.
This fits: 2009-2016 Volvo XC70 All
Whatever your task at hand -- whether it's launching that boat before daybreak, setting up your camper before the rush or getting a final load to the dump before close -- CURT class 3 trailer hitches offer the strength needed for serious towing. They make it easy to hitch up and Bring It, offering a vehicle-specific fit and the weight capacity to handle a variety of trailers. Custom class 3 hitches are the most common type of receiver hitch for pickup trucks and SUVs. Because of their weight range, they are also found on full-size cars, crossovers and minivans. Each custom-fit class 3 hitch package is made for vehicle-specific mounting. This particular kit fits certain years of the Volvo S60, V60, V70 and XC70 (see application info to verify vehicle compatibility). It provides a weight carrying capacity of 3,500 lbs. GTW and 350 lbs. TW. CURT class 3 trailer hitches are typically used to attach and haul utility trailers, boat trailers, campers, snowmobile or ATV haulers and more (NOTE: Never exceed the lowest-rated towing component). Each class 3 hitch has a 2" receiver tube and is tested in accordance with SAE J684 for safety. To ensure that CURT class 3 receiver hitches have what it takes for serious trailering, they are designed using a hands-on approach and are constructed with rugged, high-strength steel and precise welding. We also protect our class 3 hitches in a co-cured finish of liquid A-coat and black powder coat for superior resistance to rust, chipping and UV damage.
Trailer hitch weight ratings are limited to vehicle manufacturer's stated capacities
Not compatible for use with vertical hanging bicycles (bike racks that require the bicycles to be hung / mounted vertically)
Includes installation hardware
2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016 Volvo XC70 All Class 3 Trailer Hitch, 2" Receiver, Select Volvo S60, V60, V70, XC70
CURT offers a variety of high-quality trailer hitches and accessories for select vehicle models. Find the perfect fit for your towing needs at TowUniverse.
CURT, a Lippert brand, offers a complete line of towing products and is the leading manufacturer of custom-fit trailer hitches. We offer the broadest selection of custom-fit hitches, and each one is designed, welded, and coated in Wisconsin.
CURT is also a leader in flat towing products, as well as 5th wheel, gooseneck, and weight distribution hitches, ball mounts, electrical components, cargo solutions, and other towing accessories.
For everything from passenger cars and vans to full-size pickups and SUVs, CURT is 'The First Name in Towing Products®.'
Experts available to answer your questions
Call 888-634-9494Lifetime
1 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2009 - 2016 | Volvo XC70 | — |
The 2009-2016 Volvo XC70 All CURT Class 3 Trailer Hitch, 2" Receiver + 2" Ball + 1-7/8" Ball Kit (Part #CHD-13266-003) fits 2009-2016 Volvo XC70 models. The 2016 model year is the last year covered by this part number. For newer models, check for an updated version.
Yes, the 2009-2016 Volvo XC70 All CURT Class 3 Trailer Hitch, 2" Receiver + 2" Ball + 1-7/8" Ball Kit (Part #CHD-13266-003) is designed to fit the 2009-2016 Volvo XC70.
The 2009-2016 Volvo XC70 All CURT Class 3 Trailer Hitch, 2" Receiver + 2" Ball + 1-7/8" Ball Kit (Part #CHD-13266-003) fits the following vehicles: 2009-2016 Volvo XC70. Always verify your specific year, make, and model before ordering.
The 2009-2016 Volvo XC70 All CURT Class 3 Trailer Hitch, 2" Receiver + 2" Ball + 1-7/8" Ball Kit (Part #CHD-13266-003) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
Yes, the CURT 13266 is designed for Volvo S60, V60, V70, and XC70 models from 2008 to present, in both sedan and wagon configurations. The hitch is a weight-carrying type with a 3,500 lbs trailer weight capacity and 350 lbs tongue weight capacity. However, you must not exceed your vehicle manufacturer's recommended towing capacity.
Yes, the CURT 13266 fits 2008-present Volvo V70 models. Note that 2012 models have one muffler, whereas pre-2012 models have two mufflers. This difference is noted in the installation guide but does not affect fitment.
The CURT 13266 is rated for a maximum of 3,500 lbs trailer weight and 350 lbs tongue weight when used as a weight-carrying hitch. However, you must never exceed your vehicle manufacturer's recommended towing capacity, which may be lower.
You will need: T20 and T25 Torx drivers, 8mm, 10mm, 13mm, 14mm, and 17mm sockets, a 6-inch socket extension, a ratchet, a torque wrench, a rotary tool, and safety glasses. The manual lists these as required tools for proper installation.
The kit includes: two 0.375-inch spacers (CM-13266-SP), six M10x1.5 hex head cap screws, grade 10.9, zinc-plated (10-10414), six 7/16-inch conical tooth washers (30-00163), and two 0.375 x 1.25 x 2.00-inch round hole spacers (CM-SP56).
The manual does not specify battery disconnection. However, you will need to disconnect back-up sensor wiring if present when removing the rear bumper fascia.
Two people may be required to ease installation. The manual specifically recommends two persons to remove the fascia to prevent scratches or damage to the vehicle.
No, drilling is not required. The hitch uses existing holes in the bumper beam. However, trimming of the rear bumper fascia is required.
You must trim a 2 by 2.5-inch notch in the lower bumper fascia using a rotary tool. The trim outline is located at the bottom center of the fascia. Trim dimensions are 2.00 inches tall, 2.50 inches wide, and 1.25 inches from the center. Heat shield trimming around the receiver tube may also be required. Confirm fit prior to trimming, as dimensions are approximate.
All M10 fasteners must be torqued to 45 lb-ft. On V70 and XC70 models, the towing eye hook must also be retightened from inside the vehicle and torqued to 45 lb-ft.
On V70 and XC70 models only, you must loosen the towing eye (1 bolt) under the appearance panel on the rear passenger side to allow removal of the bumper beam. The towing eye is then reinstalled and sandwiched between the hitch and bumper beam. On S60 and V60 models, towing eye removal is not mentioned.
1. Remove rear bumper fascia and disconnect back-up sensor wiring if present. 2. On V70/XC70 models, loosen the towing eye. 3. Remove bumper beam using a 13mm socket. 4. Place hitch into bumper beam aligning holes. 5. Raise hitch and bumper beam into position, using supplied spacers if needed. 6. Install M10 bolts and conical tooth washers; hand tighten driver side and lower passenger side bolts. 7. Reinstall towing eye if applicable; hand tighten bolts. 8. Torque all M10 fasteners to 45 lb-ft. 9. On V70/XC70, retighten towing eye from inside vehicle to 45 lb-ft. 10. Replace appearance panel bolts on V70/XC70. 11. Trim fascia using rotary tool. 12. Reinstall fascia.
Hand tighten the driver side and lower passenger side bolts (or all bolts if the tow hook is non-removable) when first installing the hitch. After the hitch is positioned and the towing eye is reinstalled, torque all M10 fasteners to 45 lb-ft.
Yes, if the mounting surface on the rear face of the end panel has spot-welded plates with raised edges around the perimeter and center holes, you must use the supplied spacers. The CURT 13266 includes two 0.375-inch spacers (CM-13266-SP) and two 0.375 x 1.25 x 2.00-inch round hole spacers (CM-SP56) for this purpose.
Safety glasses must be worn at all times during installation. Two people are recommended to remove the fascia to prevent scratches or damage. Use proper tools to improve installation quality and reduce time. If you are hesitant to undertake this task, contact an authorized CURT installer for assistance.
All non-trailer loads applied to this hitch must be supported by CURT 18050 stabilizing straps. Failure to properly support non-trailer loads will void the product warranty.
After installation, ensure the fascia sits flat along the rear shelf of the trunk. Periodically check the receiver hitch to ensure all fasteners are tight and all structural components are sound. This ongoing maintenance is critical to safe operation.
The manual states you should periodically check the receiver hitch to ensure all fasteners are tight and all structural components are sound. A specific interval is not provided; consult the vehicle manufacturer's maintenance schedule or contact CURT technical support at 877-287-8634 for guidance.
CURT Manufacturing warrants this product to be free of defects in material and workmanship at the time of retail purchase by the original purchaser. If found defective, CURT may repair or replace the product at their option when returned prepaid with proof of purchase. Alteration, misuse, or improper installation voids the warranty. CURT's liability is limited to repair or replacement and excludes incidental or consequential loss or damage.
Yes, the CURT 13266 fits all Volvo S60, V60, V70, and XC70 models from 2008 to present in sedan and wagon configurations. Maximum capacity is 3,500 lbs trailer weight and 350 lbs tongue weight, but do not exceed your vehicle manufacturer's recommended towing capacity.
No drilling is required. However, you must trim a 2 by 2.5-inch notch in the lower bumper fascia using a rotary tool, and heat shield trimming around the receiver tube may be required.
You need T20 and T25 Torx drivers, 8mm/10mm/13mm/14mm/17mm sockets, 6-inch extension, ratchet, torque wrench, rotary tool, and safety glasses.
Two people may be required to ease installation and are specifically recommended to remove the fascia to prevent scratches or damage.
All M10 fasteners must be torqued to 45 lb-ft. On V70 and XC70 models, the towing eye hook must also be torqued to 45 lb-ft.
The CURT 13266 is rated for 3,500 lbs trailer weight and 350 lbs tongue weight. Never exceed your vehicle manufacturer's recommended towing capacity, which may be lower.
All non-trailer loads must be supported by CURT 18050 stabilizing straps. Failure to do so voids the warranty.
Continue to loosen the towing eye as needed to remove the bumper beam. The towing eye is located under the appearance panel on the rear passenger side and is retained by 1 bolt. Loosen this bolt incrementally as you work to remove the bumper beam.
Ensure that the trim dimensions are correct (2.00 inches tall, 2.50 inches wide, 1.25 inches from center) and that the notch is properly cut. Confirm fit prior to final trimming. Also check that all M10 fasteners are torqued to 45 lb-ft and that the hitch is properly aligned in the bumper beam. If heat shield trimming was required, verify that it does not interfere with fascia fit.
Check whether the mounting surface on the rear face of the end panel has spot-welded plates with raised edges. If so, you must use the supplied spacers (CM-13266-SP or CM-SP56) to ensure proper alignment. The manual notes that the Volvo S60 has this configuration and requires spacers.
