Select your vehicle to find the exact plug-and-play parts that fit — no cutting or splicing.
This fits: 2011-2017 Volkswagen Touareg All
Whatever your task at hand -- whether it's launching that boat before daybreak, setting up your camper before the rush or getting a final load to the dump before close -- CURT class 3 trailer hitches offer the strength needed for serious towing. They make it easy to hitch up and Bring It, offering a vehicle-specific fit and the weight capacity to handle a variety of trailers. Custom class 3 hitches are the most common type of receiver hitch for pickup trucks and SUVs. Because of their weight range, they are also found on full-size cars, crossovers and minivans. Each custom-fit class 3 hitch package is made for vehicle-specific mounting. This particular kit fits certain years of the Porsche Cayenne and Volkswagen Touareg (see application info to verify vehicle compatibility). It provides a weight carrying capacity of 7,500 lbs. GTW and 750 lbs. TW. CURT class 3 trailer hitches are typically used to attach and haul utility trailers, boat trailers, campers, snowmobile or ATV haulers and more (NOTE: Never exceed the lowest-rated towing component). Each class 3 hitch has a 2" receiver tube and is tested in accordance with SAE J684 for safety. To ensure that CURT class 3 receiver hitches have what it takes for serious trailering, they are designed using a hands-on approach and are constructed with rugged, high-strength steel and precise welding. We also protect our class 3 hitches in a co-cured finish of liquid A-coat and black powder coat for superior resistance to rust, chipping and UV damage.
Trailer hitch weight ratings are limited to vehicle manufacturer's stated capacities
Not compatible for use with vertical hanging bicycles (bike racks that require the bicycles to be hung / mounted vertically)
Uses pre-existing vehicle hardware for installation
2011, 2012, 2013, 2014, 2015, 2016, 2017 Volkswagen Touareg All Class 3 Trailer Hitch, 2" Receiver, Select Porsche Cayenne, Volkswagen Touareg
CURT offers a variety of high-quality trailer hitches and accessories for select vehicle models. Find the perfect fit for your towing needs at TowUniverse.
CURT, a Lippert brand, offers a complete line of towing products and is the leading manufacturer of custom-fit trailer hitches. We offer the broadest selection of custom-fit hitches, and each one is designed, welded, and coated in Wisconsin.
CURT is also a leader in flat towing products, as well as 5th wheel, gooseneck, and weight distribution hitches, ball mounts, electrical components, cargo solutions, and other towing accessories.
For everything from passenger cars and vans to full-size pickups and SUVs, CURT is 'The First Name in Towing Products®.'
Experts available to answer your questions
Call 888-634-9494Lifetime
1 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2011 - 2017 | Volkswagen Touareg | — |
The 2011-2017 Volkswagen Touareg All CURT Class 3 Trailer Hitch, 2" Receiver + 2" Ball + 1-7/8" Ball Kit (Part #CHD-13116-002) fits the following vehicles: 2011-2017 Volkswagen Touareg. Always verify your specific year, make, and model before ordering.
Yes, the 2011-2017 Volkswagen Touareg All CURT Class 3 Trailer Hitch, 2" Receiver + 2" Ball + 1-7/8" Ball Kit (Part #CHD-13116-002) is designed to fit the 2011-2017 Volkswagen Touareg.
The 2011-2017 Volkswagen Touareg All CURT Class 3 Trailer Hitch, 2" Receiver + 2" Ball + 1-7/8" Ball Kit (Part #CHD-13116-002) fits 2011-2017 Volkswagen Touareg models. The 2017 model year is the last year covered by this part number. For newer models, check for an updated version.
The 2011-2017 Volkswagen Touareg All CURT Class 3 Trailer Hitch, 2" Receiver + 2" Ball + 1-7/8" Ball Kit (Part #CHD-13116-002) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
Yes. CURT part number 13116 is designed for 2011-present Volkswagen Touareg and Porsche Cayenne SUVs. The hitch replaces the factory bumper beam and requires removal of the bumper cover, mud flaps, wheel well trim, and tail lights.
Yes. CURT part number 13116 fits 2011-present Porsche Cayenne SUVs. The installation procedure for tail light removal differs from the Volkswagen Touareg: on the Cayenne, you remove a panel on the left side of the light, then remove the panel cover to access the nuts inside the tail light.
The CURT 13116 is rated for a maximum trailer weight of 7,500 lbs and a tongue weight of 750 lbs when used as a weight-carrying hitch. However, you must never exceed your vehicle manufacturer's recommended towing capacity, which may be lower than these ratings.
You will need: T-15, T-25, and T-30 Torx bit sockets; 11mm and 18mm sockets; a ratchet; a torque wrench; a small punch; a flat head screwdriver; and safety glasses. The manual notes that using proper tools will greatly improve the quality of the install and reduce the time required.
No. The CURT 13116 requires no drilling. The hitch replaces the factory bumper beam and uses the existing M12 bolt holes from the vehicle frame.
Two people may be required to ease installation. The manual lists this as an installation tip and rates the difficulty level as challenging, so having a second person available is recommended.
Yes. The manual rates the installation difficulty as challenging. It requires removal of the bumper cover, mud flaps, wheel well trim, and tail lights before the factory bumper beam can be removed and replaced with the hitch. The manual recommends reading all instructions thoroughly before beginning and suggests contacting an authorized CURT installer if you are hesitant to undertake the task.
The first step is to remove the four torx head fasteners that attach the bottom rear portion of the bumper cover to the vehicle. Before beginning any work, the manual requires that you read all instructions thoroughly and wear safety glasses at all times.
Remove the mud flap from behind each rear tire by unfastening five torx head screws from each flap. Note that the underside fasteners have a nut attached, so you will need to account for these when removing the flap.
First, remove the fastener that holds the wheel well trim to the fascia. Then carefully pop off the wheel well trim. Note that only the rear half of the trim needs to be removed. After this, remove four torx head fasteners from under the wheel well trim.
On a VW Touareg, remove the vehicle tail lights by loosening the nut from inside the vehicle using an 11mm socket. The driver side nut is accessible through a circular plastic clip and the passenger side through a rectangular clip. Carefully slide the light out and unfasten the electrical clip.
On a Porsche Cayenne, remove the panel on the left side of the light. Then remove the panel cover to reveal the nuts on the inside of the tail light. Remove the nuts and carefully slide out the light and unfasten the electrical clip.
After tail light removal, remove two torx head fasteners and one push fastener from each side. To remove the push fastener, use a small punch or equivalent to push the center of the push fastener down, then pry it up.
Carefully remove the bumper cover by popping the sides off first, then pulling it straight back. This step comes after all the fasteners and trim pieces have been removed.
Remove the foam insert first. Then remove the bumper beam by unfastening eight M12 bolts. These bolts will be reused to install the hitch. The foam insert can be discarded or trimmed and reinstalled if desired.
Install the hitch using the M12 bolts removed in step 8. The foam insert can be discarded or trimmed and reinstalled. If reinstalling the foam, trim it so it loosely fits into position. Do not torque the fasteners at this stage.
Torque all M12 fasteners to 82 ft-lbs. This is the final step after the hitch is installed and all components removed in steps 1-7 have been reinstalled.
The final step is to torque all M12 fasteners to 82 ft-lbs and reinstall all components that were removed in steps 1-7. This includes the bumper cover, mud flaps, wheel well trim, and tail lights.
Safety glasses should be worn at all times while installing this product. Additionally, never exceed your vehicle manufacturer's recommended towing capacity when using the hitch.
All non-trailer loads applied to this hitch must be supported by auxiliary stabilizing straps. Failure to properly support non-trailer loads will void the product warranty.
Periodically check the receiver hitch to ensure that all fasteners are tight and that all structural components are sound. This inspection should be performed regularly throughout the life of the product.
CURT Manufacturing warrants this product to be free of defects in material and/or workmanship at the time of retail purchase by the original purchaser. If the product is found to be defective, CURT may repair or replace the product at their option when returned prepaid with proof of purchase. Alteration to, misuse, or improper installation voids the warranty.
Yes. This product complies with safety specifications and requirements for connecting devices and towing systems of the state of New York, V.E.S.C. Regulation V-5 and SAE J684.
Yes. The CURT 13116 is designed for 2011-present Volkswagen Touareg and Porsche Cayenne SUVs. It replaces the factory bumper beam with no drilling required.
Maximum 7,500 lbs trailer weight and 750 lbs tongue weight. Never exceed your vehicle manufacturer's recommended towing capacity.
T-15, T-25, T-30 Torx sockets; 11mm and 18mm sockets; ratchet; torque wrench; small punch; flat head screwdriver; and safety glasses.
No. The CURT 13116 requires no drilling. It uses existing M12 bolt holes from the factory bumper beam location.
Torque all M12 fasteners to 82 ft-lbs. This is performed as the final installation step after all components are reinstalled.
Wear safety glasses at all times during installation. Never exceed vehicle manufacturer's towing capacity. All non-trailer loads must be supported by auxiliary stabilizing straps.
Periodically check that all fasteners are tight and all structural components are sound. Retorque fasteners as needed.
