Select your vehicle to find the exact plug-and-play parts that fit — no cutting or splicing.
This fits: 2017-2020 Nissan Pathfinder All
Whatever your task at hand -- whether it's launching that boat before daybreak, setting up your camper before the rush or getting a final load to the dump before close -- CURT class 3 trailer hitches offer the strength needed for serious towing. They make it easy to hitch up and Bring It, offering a vehicle-specific fit and the weight capacity to handle a variety of trailers. Custom class 3 hitches are the most common type of receiver hitch for pickup trucks and SUVs. Because of their weight range, they are also found on full-size cars, crossovers and minivans. Each custom-fit class 3 hitch package is made for vehicle-specific mounting. This particular kit fits certain years of the Nissan Pathfinder (see application info to verify vehicle compatibility). It provides a weight carrying capacity of 6,000 lbs. GTW and 900 lbs. TW. It is also compatible with a weight distribution hitch for level towing and a rating of 6,000 lbs. WD and 900 lbs. WDTW. CURT class 3 trailer hitches are typically used to attach and haul utility trailers, boat trailers, campers, snowmobile or ATV haulers and more (NOTE: Never exceed the lowest-rated towing component). Each class 3 hitch has a 2" receiver tube and is tested in accordance with SAE J684 for safety. To ensure that CURT class 3 receiver hitches have what it takes for serious trailering, they are designed using a hands-on approach and are constructed with rugged, high-strength steel and precise welding. We also protect our class 3 hitches in a co-cured finish of liquid A-coat and black powder coat for superior resistance to rust, chipping and UV damage.
Installation requires minor fascia trimming and removal of tow hooks
Trailer hitch weight ratings are limited to vehicle manufacturer's stated capacities
Not compatible for use with vertical hanging bicycles (bike racks that require the bicycles to be hung / mounted vertically)
2017, 2018, 2019, 2020 Nissan Pathfinder All Class 3 Trailer Hitch, 2" Receiver, Select Nissan Pathfinder
CURT offers a variety of high-quality trailer hitches and accessories for select vehicle models. Find the perfect fit for your towing needs at TowUniverse.
CURT, a Lippert brand, offers a complete line of towing products and is the leading manufacturer of custom-fit trailer hitches. We offer the broadest selection of custom-fit hitches, and each one is designed, welded, and coated in Wisconsin.
CURT is also a leader in flat towing products, as well as 5th wheel, gooseneck, and weight distribution hitches, ball mounts, electrical components, cargo solutions, and other towing accessories.
For everything from passenger cars and vans to full-size pickups and SUVs, CURT is 'The First Name in Towing Products®.'
Experts available to answer your questions
Call 888-634-9494Lifetime
1 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2017 - 2020 | Nissan Pathfinder | — |
The 2017-2020 Nissan Pathfinder All CURT Class 3 Trailer Hitch, 2" Receiver + 2" Ball + 1-7/8" Ball Kit (Part #CHD-13309-001) fits 2017-2020 Nissan Pathfinder models. The 2020 model year is the last year covered by this part number. For newer models, check for an updated version.
The 2017-2020 Nissan Pathfinder All CURT Class 3 Trailer Hitch, 2" Receiver + 2" Ball + 1-7/8" Ball Kit (Part #CHD-13309-001) fits the following vehicles: 2017-2020 Nissan Pathfinder. Always verify your specific year, make, and model before ordering.
Yes, the 2017-2020 Nissan Pathfinder All CURT Class 3 Trailer Hitch, 2" Receiver + 2" Ball + 1-7/8" Ball Kit (Part #CHD-13309-001) is designed to fit the 2017-2020 Nissan Pathfinder.
The 2017-2020 Nissan Pathfinder All CURT Class 3 Trailer Hitch, 2" Receiver + 2" Ball + 1-7/8" Ball Kit (Part #CHD-13309-001) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
The part number is 13309. This hitch is designed for 2017-present Nissan Pathfinder SUVs.
Yes, part number 13309 is designed for 2017-present Nissan Pathfinder SUVs. Confirm your vehicle year and model match before purchasing.
2017-present models.
As a weight-carrying hitch, the 13309 supports 6,000 lbs trailer weight and 900 lbs tongue weight. As a weight-distribution hitch, it also supports 6,000 lbs trailer weight and 900 lbs tongue weight. Never exceed your vehicle manufacturer's recommended towing capacity.
900 lbs.
The hitch weight is 40 lbs.
Required tools are: ratchet, marker, masking tape, 12mm socket, 18mm socket, 19mm socket, 21mm socket, tape measure, torque wrench, rotary tool, and safety glasses. The manual notes that using proper tools will greatly improve the quality of the install and reduce the time required.
Yes. All M12 fasteners must be torqued to 86 ft-lbs, which requires a torque wrench.
The hitch includes 6 M12 x 1.25 x 30mm hex cap screws (part number 10-10419) and 6 1/2" conical toothed washers (part number 30-00149). These fasteners secure the hitch to the existing weldnuts on the frame rails.
Yes. The tow hook must be removed from the driver side frame rail using an 18mm socket to remove 4 bolts. Return the tow hook and fasteners to the vehicle owner after removal.
Yes. The spare tire must be lowered using a tire lug wrench or ratchet with a 21mm socket before installation. It is raised back into position after the hitch is installed.
You do not need to fully remove the fascia, but you must remove the fascia mounting brackets. First remove the plastic clips on the bottom of the fascia, then unbolt the brackets from the bumper using a 12mm socket. Retain the brackets for reinstallation after hitch installation.
No drilling is required. The hitch uses existing weldnuts on the frame rails.
Yes, minor fascia trimming is required. You must trim the center of the vehicle fascia to approximately 3 1/4" wide by 1 3/8" tall. The manual notes that dimensions are approximate and you should confirm fit prior to trimming. A rotary tool is recommended for this task.
The trim area is approximately 3 1/4" wide by 1 3/8" tall, centered on the vehicle fascia. The manual notes that dimensions are approximate and you should confirm fit prior to trimming.
All M12 fasteners must be torqued to 86 ft-lbs. These are M12 x 1.25 x 30mm hex cap screws secured with 1/2" conical toothed washers into the existing weldnuts on the frame rails.
86 ft-lbs for all M12 fasteners.
Two people may be required to ease installation. The manual recommends reading all instructions thoroughly before beginning and notes that the installation difficulty level is moderate.
Professional installation time is approximately 80 minutes. Novice (DIY) installation time is approximately 31 minutes. Actual time may vary based on experience and familiarity with the vehicle.
1. Remove the tow hook from the driver side frame rail using an 18mm socket (4 bolts). 2. Lower the spare tire using a 21mm socket. 3. Remove fascia mounting brackets by removing plastic clips and unbolting with a 12mm socket. 4. Mark and trim the fascia approximately 3 1/4" x 1 3/8" at the center. 5. Raise the hitch into position and secure with M12 x 1.25 x 30mm hex bolts and 1/2" conical toothed washers using a 19mm socket; torque to 86 ft-lbs. 6. Reinstall fascia mounting brackets. 7. Raise the spare tire back into position.
Safety glasses must be worn at all times while installing this product. If you are hesitant to undertake this task on your own, contact an authorized CURT installer for additional assistance. Never exceed your vehicle manufacturer's recommended towing capacity when using the hitch.
Safety glasses must be worn at all times during installation.
After installation, periodically check that all fasteners are tight and all structural components are sound. The manual recommends regular inspection to ensure the hitch remains in proper working condition.
The manual recommends periodically checking the receiver hitch to ensure all fasteners are tight and all structural components are sound. No specific interval is provided; inspect regularly based on usage frequency and towing conditions.
CURT Manufacturing warrants this product to be free of defects in material and/or workmanship at the time of retail purchase by the original purchaser. If the product is found to be defective, CURT may repair or replace the product at their option when returned prepaid with proof of purchase. Alteration to, misuse of, or improper installation voids the warranty. CURT's liability is limited to repair or replacement of defective products and excludes liability for incidental or consequential loss or damage.
Yes. This product complies with safety specifications and requirements for connecting devices and towing systems of the state of New York, V.E.S.C. Regulation V-5 and SAE J684.
