96-99 GMC Savana 2500 CURT 4-flat Plug and Play Trailer WiringCURTOriginal price was $81.90. Current price is $80.76.In Stock
View productAsk a Question About This Product
Our in-house experts typically reply within one business day.
Our in-house experts typically reply within one business day.
CURT
Verify Fitment
Select your vehicle to confirm this part fits.
1996 - 1999 GMC Savana 1500
Confirmed to Fit
Always the correct part
We know our products
Quality Products
Free Shipping!
Always the correct part
We know our products
Quality Products
Free Shipping!
| Side Application Type Description | Blank |
| T-Connector Location | S3,S4 |
| Tail Light Circuits | 7.5 Amps |
| Turn and Brake Circuits | 3.0 Amps |
| Warranty | One-Year Limited Warranty |
| Converter Type | Circuit Protected |
| Electrical System Type | 3W |
| Finish | N/A |
| Material | Blank |
| Mount Type Description | Blank |
| Output Type | 4-Way Flat |
CURT offers a variety of high-quality trailer hitches and accessories for select vehicle models. Find the perfect fit for your towing needs at TowUniverse.
CURT, a Lippert brand, offers a complete line of towing products and is the leading manufacturer of custom-fit trailer hitches. We offer the broadest selection of custom-fit hitches, and each one is designed, welded, and coated in Wisconsin.
CURT is also a leader in flat towing products, as well as 5th wheel, gooseneck, and weight distribution hitches, ball mounts, electrical components, cargo solutions, and other towing accessories.
For everything from passenger cars and vans to full-size pickups and SUVs, CURT is 'The First Name in Towing Products®.'
Experts available to answer your questions
Call 888-634-94941 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 1996 - 1999 | GMC Savana 1500 | — |
The 96-99 GMC Savana 1500 CURT 4-flat Plug and Play Trailer Wiring (Part #CTW1126) fits the following vehicles: 1996-1999 GMC Savana 1500. Always verify your specific year, make, and model before ordering.
Yes, the 96-99 GMC Savana 1500 CURT 4-flat Plug and Play Trailer Wiring (Part #CTW1126) is designed to fit the 1996-1999 GMC Savana 1500.
The 96-99 GMC Savana 1500 CURT 4-flat Plug and Play Trailer Wiring (Part #CTW1126) fits 1996-1999 GMC Savana 1500 models. The 1999 model year is the last year covered by this part number. For newer models, check for an updated version.
The 96-99 GMC Savana 1500 CURT 4-flat Plug and Play Trailer Wiring (Part #CTW1126) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
Yes, Curt part number 55335 is designed for GMC Savana and Chevy Express vehicles. The installation involves connecting to the vehicle's existing taillight wiring harnesses on both the driver's and passenger's sides.
Yes. You must open the rear doors and remove the rear scuff panel to access the vehicle's taillight wiring harnesses on both the driver's and passenger's sides.
Locate the vehicle's taillight wiring harness on the inside of the vehicle directly behind the driver's side taillight. Separate the vehicle's wiring harness connectors carefully, being sure not to damage the locking tabs. Insert the T-connector end with the yellow wire in-between the separated connectors.
Route the T-connector end with the green wire down to the floor and across to the passenger's side under the removed scuff panel, then up to the vehicle's taillight wiring harness on the passenger's side. Repeat the connection process on the passenger's side using the green wire, separating the connectors carefully and inserting the green wire T-connector between them.
Drilling is optional. On the driver's side, locate a suitable existing grounding point such as an existing screw with nut in the vehicle's frame. If no suitable grounding point is available, drill a 3/32" hole and secure the white wire using the eyelet and screw provided.
If you need to drill a grounding hole, drill a 3/32" hole on the driver's side near the connector. Secure the white wire using the eyelet and screw provided in the kit.
Adhere the black converter box to the frame of the vehicle using the double-sided tape provided in the kit.
The kit includes: a T-connector with yellow and green wires, a white ground wire, a black converter box, double-sided tape for securing the converter box, cable ties for securing loose parts of the T-connector, an eyelet, and a screw for the optional ground wire installation.
When in use, route the 4-flat wire to the center of the vehicle and out the rear cargo doors. When not in use, roll up the wire and store it in an out-of-the-way location in the rear cargo area.
Before drilling, verify that miscellaneous items hidden behind or under any surface will not be damaged. Drilling without checking can cause damage to hidden components and/or personal injury.
When separating the vehicle's wiring harness connectors, be sure not to damage the locking tabs. The locking tabs hold the connectors together and must remain intact for proper operation.
Yes. After connecting the T-connector, secure any loose parts of the T-connector with the cable ties provided in the kit.
GMC Savana and Chevy Express.
Drilling is optional. A 3/32" hole is only needed if no suitable existing grounding point (screw with nut) is available on the vehicle's frame.
The manual does not specify required tools. A drill may be needed if you must create a 3/32" grounding hole, and basic hand tools are likely needed to separate connectors and secure fasteners.
Yes, you must open the rear doors and remove the rear scuff panel to access the taillight wiring harnesses.
