| Side Application Type Description | Blank |
| T-Connector Location | S1,S2 |
| Tail Light Circuits | 7.5 Amps |
| Turn and Brake Circuits | 3.0 Amps |
| Warranty | One-Year Limited Warranty |
| Converter Type | Circuit Protected |
| Electrical System Type | 3W |
| Finish | N/A |
| Material | Blank |
| Mount Type Description | Blank |
| Output Type | 4-Way Flat |
CURT offers a variety of high-quality trailer hitches and accessories for select vehicle models. Find the perfect fit for your towing needs at TowUniverse.
CURT, a Lippert brand, offers a complete line of towing products and is the leading manufacturer of custom-fit trailer hitches. We offer the broadest selection of custom-fit hitches, and each one is designed, welded, and coated in Wisconsin.
CURT is also a leader in flat towing products, as well as 5th wheel, gooseneck, and weight distribution hitches, ball mounts, electrical components, cargo solutions, and other towing accessories.
For everything from passenger cars and vans to full-size pickups and SUVs, CURT is 'The First Name in Towing Products®.'
Experts available to answer your questions
Call 888-634-94941 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 1998 - 2002 | Honda Passport | With door mounted spare tire |
The 98-02 HONDA Passport With door mounted spare tire CURT 4-flat Plug and Play Trailer Wiring (Part #CTW1378) fits 1998-2002 Honda Passport models. The 2002 model year is the last year covered by this part number. For newer models, check for an updated version.
The 98-02 HONDA Passport With door mounted spare tire CURT 4-flat Plug and Play Trailer Wiring (Part #CTW1378) fits the following vehicles: 1998-2002 Honda Passport. Always verify your specific year, make, and model before ordering.
Yes, the 98-02 HONDA Passport With door mounted spare tire CURT 4-flat Plug and Play Trailer Wiring (Part #CTW1378) is designed to fit the 1998-2002 Honda Passport.
The 98-02 HONDA Passport With door mounted spare tire CURT 4-flat Plug and Play Trailer Wiring (Part #CTW1378) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
Yes, the Curt 55360 is designed for Honda Passport. It is also compatible with Isuzu Amigo, Isuzu Rodeo, and Isuzu Rodeo Sport. The harness is categorized for SUVs, mini and full-sized vans.
Yes, the Curt 55360 is compatible with Isuzu Rodeo Sport. It is designed for the SUV, mini and full-sized van category.
The Curt 55360 has two amperage ratings: Signal Circuits are rated at 3.0 amps per side, and Tail/Running Circuits are rated at 6.0 amps total. Do not exceed these ratings or your tow vehicle's lamp load rating, whichever is lower, as exceeding the rating can cause loss of warranty, overheating and potential fire.
You will need a Phillips screwdriver, a flat blade screwdriver, and a panel trim removal tool.
The kit includes the custom wiring harness with yellow and green wire ends, a white ground wire with ring terminal, a black converter box, a provided screw for grounding, double-sided tape for mounting the converter box, cable ties for securing loose wires, and a 4-flat dust cover.
The yellow wire end connects on the driver side behind the taillight housing (location S1), and the green wire end connects on the passenger side behind the taillight housing (location S2). Each harness end inserts between the separated vehicle taillight wiring harness connectors.
Remove the three Phillips screws securing the taillight assembly. The third screw is hidden between the taillight assembly and the bumper. Take care when removing the assembly to avoid damage.
Locate the vehicle taillight wiring harness connectors behind the removed taillight. Separate the connectors from the taillight housing, taking care not to damage the locking tabs. The custom wiring harness end inserts between these separated connectors, and the connectors must be fully inserted with locking tabs in place.
You may not need to drill. First, locate a suitable grounding point near the connector, such as an existing screw with nut in the vehicle frame. If no existing point is available, you can drill a 3/32" pilot hole. The area should be free of rust, dirt and paint before securing the white ground wire using the ring terminal and provided screw. Always check for hidden items before drilling to avoid damage and personal injury.
Locate a flat spot inside the vehicle near the taillight. Adhere the black converter box using the provided double-sided tape. Ensure the surface is clean and flat for proper adhesion.
When in use, route the 4-flat to the center of the vehicle and out of the trunk. When not in use, roll up and store in a convenient, out-of-the-way location inside the trunk. Secure any loose wires with the provided cable ties.
All installation steps must be followed to ensure the wiring harness functions properly. Test for proper function by using a test light or by connecting a properly wired trailer. Reinstall all items removed during installation and install the provided 4-flat dust cover to help prevent corrosion.
Do not exceed the Curt 55360 product rating (Signal Circuits 3.0 amps per side, Tail/Running Circuits 6.0 amps total) or your tow vehicle's lamp load rating, whichever is lower. Exceeding the rating can cause loss of warranty, overheating and potential fire. Check your vehicle owner's manual or contact the vehicle manufacturer for your specific lamp load rating.
The manual does not specify whether the battery must be disconnected. For safety, consult your vehicle owner's manual or contact the vehicle manufacturer before beginning installation.
Yes, the Curt 55360 is designed for these vehicles in the SUV, mini and full-sized van category.
Phillips screwdriver, flat blade screwdriver, and panel trim removal tool.
Drilling is optional. A 3/32" pilot hole is needed only if no existing screw with nut is available for the ground wire connection.
Signal Circuits: 3.0 amps per side. Tail/Running Circuits: 6.0 amps total. Do not exceed these ratings or your vehicle's lamp load rating, whichever is lower.
Do not exceed 3.0 amps per side (Signal) or 6.0 amps total (Tail/Running), or your vehicle's lamp load rating, whichever is lower. Exceeding the rating can cause overheating and fire.
