Select your vehicle to find the exact plug-and-play parts that fit — no cutting or splicing.
Trailer hitch weight ratings are limited to vehicle manufacturer's stated capacities
Includes installation hardware
Includes installation hardware
Warranty: Limited Lifetime Warranty (One-Year Finish, One-Year Parts)
Main Body Shape: Round
Receiver Tube Size (Inches): 2 IN
Finish: GLOSS BLACK POWDER COAT
WC / TW (Pounds): 250 LBS / 2,500 LBS
Weight Carrying Capacity (Pounds): 2,500 LBS
WC Tongue Weight (Pounds): 250 LBS
Installation Difficulty: Advanced
Installation Time Exact (Minutes): 60
Whatever your task at hand -- whether it's launching that boat before daybreak, setting up your camper before the rush or getting a final load to the dump before close -- CURT class 3 trailer hitches offer the strength needed for serious towing. They make it easy to hitch up and Bring It, offering a vehicle-specific fit and the weight capacity to handle a variety of trailers. Custom class 3 hitches are the most common type of receiver hitch for pickup trucks and SUVs. Because of their weight range, they are also found on full-size cars, crossovers and minivans. Each custom-fit class 3 hitch package is made for vehicle-specific mounting. This particular kit fits certain years of the Hyundai Ioniq 5 (see application info to verify vehicle compatibility). It provides a weight carrying capacity of 2,500 lbs. GTW and 250 lbs. TW. CURT class 3 trailer hitches are typically used to attach and haul utility trailers, boat trailers, campers, snowmobile or ATV haulers and more (NOTE: Never exceed the lowest-rated towing component). Each class 3 hitch has a 2" receiver tube and is tested in accordance with SAE J684 for safety. To ensure that CURT class 3 receiver hitches have what it takes for serious trailering, they are designed using a hands-on approach and are constructed with rugged, high-strength steel and precise welding. We also protect our class 3 hitches in a co-cured finish of liquid A-coat and black powder coat for superior resistance to rust, chipping and UV damage.
CURT offers a variety of high-quality trailer hitches and accessories for select vehicle models. Find the perfect fit for your towing needs at TowUniverse.
CURT, a Lippert brand, offers a complete line of towing products and is the leading manufacturer of custom-fit trailer hitches. We offer the broadest selection of custom-fit hitches, and each one is designed, welded, and coated in Wisconsin.
CURT is also a leader in flat towing products, as well as 5th wheel, gooseneck, and weight distribution hitches, ball mounts, electrical components, cargo solutions, and other towing accessories.
For everything from passenger cars and vans to full-size pickups and SUVs, CURT is 'The First Name in Towing Products®.'
Experts available to answer your questions
Call 888-634-9494Equip your vehicle for towing and hitch-mounted accessories with a dependable CURT 2" trailer hitch. Designed for a vehicle-specific fit, CURT receiver hitches provide a strong and secure connection point for towing trailers, carrying bikes, transporting cargo and using other compatible 2-inch hitch accessories.
Our selection of CURT 2-inch receiver hitches includes options for trucks, SUVs, crossovers, vans and passenger vehicles. Each hitch is engineered to match specific vehicle mounting points, helping provide a clean installation and dependable performance. Depending on the vehicle application, available options may include Class 3, Class 4 and heavy-duty receiver hitches with different gross trailer weight and tongue weight capacities.
A 2" x 2" receiver opening is one of the most common hitch sizes and works with a wide range of towing accessories, including ball mounts, bike racks, cargo carriers, hitch steps and tow hooks. When towing a trailer, you may also need a properly rated trailer ball, hitch pin, wiring harness, brake controller or weight distribution system.
CURT trailer hitches feature a durable black finish designed to help protect against rust, scratches and exposure to road conditions. Many models install using existing holes in the vehicle frame, although drilling, trimming or temporary removal of vehicle components may be required for certain applications.
Use our vehicle fitment tools to find the correct CURT 2" trailer hitch for your year, make and model. Always compare the hitch rating with your vehicle’s towing capacity and the ratings of every component in your towing setup. The maximum towing capacity is determined by the lowest-rated component.
Shop CURT 2-inch trailer hitches at TowUniverse for vehicle-specific fitment, trusted towing performance and access to the accessories needed to complete your towing setup.
Rediscover "Us" Time | Tested. Proven. Safe. Towing Products
1 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2022 - 2024 | Hyundai Ioniq 5 | No Drilling Required Visibility: Concealed Installation Time: 60-90 minutes Undercar trimming (not fascia) required |
Yes, the CURT Class 3 Trailer Hitch, 2" Receiver, Select Hyundai Ioniq 5 Trailer Hitch (Part #BKDK13520) is designed to fit the 2022-2024 Hyundai Ioniq 5.
The CURT Class 3 Trailer Hitch, 2" Receiver, Select Hyundai Ioniq 5 Trailer Hitch (Part #BKDK13520) fits the following vehicles: 2022-2024 Hyundai Ioniq 5. Always verify your specific year, make, and model before ordering.
The CURT Class 3 Trailer Hitch, 2" Receiver, Select Hyundai Ioniq 5 Trailer Hitch (Part #BKDK13520) fits 2022-2024 Hyundai Ioniq 5 models. The 2024 model year is the last year covered by this part number. For newer models, check for an updated version.
The CURT Class 3 Trailer Hitch, 2" Receiver, Select Hyundai Ioniq 5 Trailer Hitch (Part #BKDK13520) Drilling is not required for installation. Typical installation time is 60-90 minutes. Basic hand tools are typically all you need.
The CURT 13520 has a gross trailer weight (GTW) capacity of 2,500 lbs and a tongue weight (TW) capacity of 250 lbs. Never exceed your vehicle manufacturer's recommended towing capacity.
The manual does not specify the vehicle make, model, year, cab style or bed length. Contact CURT product support at 877-287-8634 or visit curtmfg.com to confirm fitment for your specific vehicle before purchasing.
Required tools: ratchet, Phillips screwdriver, flathead screwdriver, socket set (10mm, 19mm, 3/4"), tape measure, torque wrench, shears, and 4 fishwire tools (included). A tools reference guide is available at curtmfg.com/trailer-hitch-installation.
The kit includes: 1 trailer hitch, 2 mounting brackets (driver and passenger side), 6 hex bolts M12 x 1.25" x 35, 6 carriage bolts 1/2"-13 x 1.25", 6 conical-toothed washers 1/2", 6 serrated-flange nuts 1/2"-13, and 4 fishwire tools.
Yes. You must remove the rearmost lower bumper panel (10 clips) and set it aside for reinstallation. The manual notes that removing the large underbody panel may ease installation. Two electrical cables routed along the driver-side frame rail must be carefully dislodged.
The manual states that removing the large underbody panel "may ease installation" but does not explicitly require it. However, the installation does require removal and trimming of underbody material. Consult the trim diagram on page 4 for the specific areas to trim.
The manual does not specify whether the battery must be disconnected. Contact CURT product support at 877-287-8634 for guidance specific to your vehicle.
1. Remove the rearmost lower bumper panel (10 clips). 2. Dislodge the two electrical cables on the driver-side frame rail. 3. Loosely install the driver-side mounting bracket using M12 hex bolts and conical-toothed washers; repeat on passenger side. 4. Raise the hitch into position between the side plates and secure with 1/2" carriage bolts installed from center outward and serrated-flange nuts. 5. Torque all M12 hardware to 86 ft-lbs and all 1/2" hardware to 90 ft-lbs. 6. Trim and reinstall the underbody panel.
The fishwire tool (4 included) is used to guide bolts through the vehicle frame rail. Insert the coiled end of the fishwire through the hitch mounting hole in the frame rail and out the access hole. Pass the coiled end through the spacer and thread the bolt into the coil. Kink the wire to keep the spacer separate from the bolt. Pull the fishwire, spacer and bolt through the frame and out the mounting hole. This prevents loss of bolts or spacers inside the frame rail.
No. In Step 3, the driver-side and passenger-side mounting brackets are installed "loosely" using M12 hex bolts and conical-toothed washers. They are fully tightened only in Step 5 after the hitch is raised into position and secured with carriage bolts.
The 1/2" carriage bolts should be installed from the center of the vehicle outward. Use fishwires as needed to install the bolts.
The manual does not mention drilling. The installation uses existing weldnuts in the vehicle frame rail. However, the installation does require trimming of the underbody panel using the trim diagram provided on page 4.
The underbody panel must be trimmed using the trim diagram on page 4 as reference. The diagram shows trim lines at 1-1/2" from the hitch on two sides and 3-3/4" on another section. The trimmed panel is then reinstalled.
The underbody panel trimming is permanent. The bumper panel removal is not permanent—it is removed and then reinstalled after the hitch is mounted and the underbody is trimmed.
Torque all M12 hex bolts to 86 ft-lbs. Torque all 1/2" carriage bolts and serrated-flange nuts to 90 ft-lbs.
The conical-toothed washer should be oriented with the conical (pointed) side facing the vehicle frame. The diagram on page 2 shows the washer positioned between the hex bolt and the hitch side plate, with the conical teeth pointing toward the frame.
The M12 hex bolts are M12 x 1.25" x 35 (6 qty). They are torqued to 86 ft-lbs and used with conical-toothed washers to secure the mounting brackets to the vehicle frame.
The carriage bolts are 1/2"-13 x 1.25" (6 qty). They are installed from the center of the vehicle outward to secure the hitch between the mounting brackets and are torqued to 90 ft-lbs.
The conical-toothed washers (1/2", 6 qty) are used with the M12 hex bolts to secure the mounting brackets to the vehicle frame. The conical teeth grip the frame surface to prevent loosening and ensure a secure connection.
To remove debris from weldnuts in the frame, spray lubricant or compressed air into the hole. For heavy debris, use a wire brush. Take care not to damage the threads.
Safety glasses must be worn at all times while installing this product. Never exceed the vehicle manufacturer's recommended towing capacity. Proper tools will improve installation quality and reduce time required.
Periodic inspection of the trailer hitch should be performed to ensure all mounting hardware remains tight and structural components are secure. The manual does not specify the inspection interval or detailed checklist.
The manual states that periodic inspection should be performed to ensure all mounting hardware remains tight and structural components are secure, but does not specify the inspection interval. Contact CURT product support at 877-287-8634 for recommended maintenance intervals.
The manual does not specify a retorque interval. Contact CURT product support at 877-287-8634 for guidance on whether the hitch should be retorqued after the first use or at specific intervals.
Visit www.curtmfg.com for a full-color copy of the instruction manual, as well as helpful videos, guides and additional resources. You can also contact CURT product support at 877-287-8634.
To register your purchase, get copies of product warranties, or provide feedback, visit warranty.curtgroup.com/surveys.
The installation difficulty is rated as Moderate. Installation difficulty levels are based on time and effort involved and may vary depending on the installer's level of expertise, condition of the vehicle, and proper tools and equipment.
The manual rates the installation as Moderate difficulty but does not explicitly require professional installation. The manual recommends reading all instructions thoroughly and using proper tools. Contact CURT product support at 877-287-8634 if you have concerns about your ability to complete the installation.
The manual does not specify whether extra people or lifting equipment are required. Contact CURT product support at 877-287-8634 for guidance on installation assistance and equipment needs.
Yes, a compatible bike rack, cargo carrier or other accessory with a 2" x 2" shank can generally be used. Make sure the accessory does not exceed the hitch’s tongue weight rating, the vehicle’s limits or the accessory manufacturer’s capacity. Account for the combined weight of the carrier and everything loaded onto it.
