| Battery-Powered | Yes |
| Converter Type | Circuit Protected, Powered, Potted |
| Electrical System Type | 3W |
| Finish | N/A |
| Material | Blank |
| Mount Type Description | Blank |
| Output Type | 4-Way Flat |
| Side Application Type Description | Blank |
| T-Connector Location | T1,T2 |
| Tail Light Circuits | 6.0 Amps |
| Turn and Brake Circuits | 3.0 Amps |
| Warranty | One-Year Limited Warranty |
CURT offers a variety of high-quality trailer hitches and accessories for select vehicle models. Find the perfect fit for your towing needs at TowUniverse.
CURT, a Lippert brand, offers a complete line of towing products and is the leading manufacturer of custom-fit trailer hitches. We offer the broadest selection of custom-fit hitches, and each one is designed, welded, and coated in Wisconsin.
CURT is also a leader in flat towing products, as well as 5th wheel, gooseneck, and weight distribution hitches, ball mounts, electrical components, cargo solutions, and other towing accessories.
For everything from passenger cars and vans to full-size pickups and SUVs, CURT is 'The First Name in Towing Products®.'
Experts available to answer your questions
Call 888-634-94941 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2016 - 2023 | Toyota Tacoma | Excluding factory receiver |
Yes, the 16-23 Toyota Tacoma Excluding factory receiver CURT 4-flat Plug and Play Trailer Wiring (Part #CTW2446) is designed to fit the 2016-2023 Toyota Tacoma.
The 16-23 Toyota Tacoma Excluding factory receiver CURT 4-flat Plug and Play Trailer Wiring (Part #CTW2446) fits the following vehicles: 2016-2023 Toyota Tacoma. Always verify your specific year, make, and model before ordering.
The 16-23 Toyota Tacoma Excluding factory receiver CURT 4-flat Plug and Play Trailer Wiring (Part #CTW2446) fits 2016-2023 Toyota Tacoma models. The 2023 model year is the last year covered by this part number. For newer models, check for an updated version.
The 16-23 Toyota Tacoma Excluding factory receiver CURT 4-flat Plug and Play Trailer Wiring (Part #CTW2446) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
Yes, the 56349 Custom Wiring Harness is designed for Toyota Tacoma pickup trucks. Confirm your vehicle model matches before purchasing.
You will need: ratchet, 10mm socket, panel trim removal tool, wire stripper, wire crimper, and cutting tool.
Yes. The first step is to locate the vehicle battery on the driver side under the hood and disconnect the negative battery terminal.
The battery connection must be fuse-protected with a 10-amp maximum. Exceeding this rating can cause loss of warranty, overheating and potential fire.
Drilling may be required. If a suitable existing grounding point (screw with nut in vehicle frame) is not available, you will need to drill a 3/32" pilot hole for the provided ground screw.
Mount the black converter box on a flat, clean surface that is out of the path of spray and debris from the rear wheels and road. Use the provided double-sided tape. Failure to mount in a protected area can cause loss of warranty, product failure, overheating and potential fire.
The kit includes a custom wiring harness with yellow, brown, red, green and white wires; a black converter box; a ground screw with ring terminal; double-sided tape for mounting the converter box; cable ties for securing loose wires; and a 4-flat dust cover. The kit also references an included CME-PCL-INS sheet for battery power wire routing instructions.
Signal circuits are rated at 3.0 amps per side. Tail and running circuits are rated at 6.0 amps total. Do not exceed these product ratings or the tow vehicle lamp load rating, whichever is lower.
The 56349 is specifically designed for Toyota Tacoma pickup trucks. The manual does not list compatibility with other models or brands. Contact the manufacturer or check the vehicle fitment database to confirm compatibility with other vehicles.
After removing the taillight and separating the vehicle taillight wiring harness connectors, insert the custom wiring harness end with yellow, brown and red wires between the separated connectors. Make sure the connectors are fully inserted with locking tabs in place. Repeat on both driver and passenger sides.
The taillight is secured with 10mm screws. Use a 10mm socket and ratchet to remove them. Take care when prying the taillight out to avoid damaging the alignment tabs.
Locate a suitable grounding point near the taillight connector, such as an existing screw with nut in the vehicle frame. If none is available, drill a 3/32" pilot hole. The area must be free of rust, dirt and paint. Secure the white ground wire using the ring terminal and provided screw. Before drilling, check for hidden items behind or under any surface to avoid damage or personal injury.
Route the custom wiring harness end with the green wire out through the hole between the vehicle bumper and body, to the passenger side, and up through the hole. Insert the housings into the vehicle connectors.
When not in use, roll up the 4-flat connector and store it in a convenient, out-of-the-way location. When in use, route it to the center of the vehicle. Secure any loose wires with the provided cable ties.
After installation, reinstall all items removed during installation and reconnect the negative battery terminal. Install the provided 4-flat dust cover to help prevent corrosion. Test for proper function by using a test light or connecting a properly wired trailer.
If a suitable existing grounding point is not available, drill a 3/32" pilot hole for the provided ground screw. Before drilling, check for hidden items behind or under any surface to avoid damage or personal injury.
Do not exceed the product rating (signal circuits 3.0 amps per side, tail/running circuits 6.0 amps total) or the tow vehicle lamp load rating, whichever is lower. Exceeding the rating can cause loss of warranty, overheating and potential fire. The battery connection must be fuse-protected with a 10-amp maximum. The converter box must be mounted in a protected area away from spray and debris; failure to do so can cause loss of warranty, product failure, overheating and potential fire. Before drilling, check for hidden items to avoid damage or personal injury.
Test for proper function by using a test light or connecting a properly wired trailer. All steps must be followed to ensure the wiring harness will function properly.
