Air Lift AIR LIFT 1000 REPLACEMENT BAG (60818HD). 60318HDAir LiftOriginal price was $139.99. Current price is $137.64.In Stock
View productAsk a Question About This Product
Our in-house experts typically reply within one business day.
Our in-house experts typically reply within one business day.
Air Lift
Verify Fitment
Select your vehicle to confirm this part fits.
2009 - 2010 Dodge Ram 1500
Confirmed to Fit
2011 - 2018 Ram 1500
Confirmed to Fit
2024 Ram 1500 Classic
Confirmed to Fit
2019 - 2023 Ram 1500 Classic
Confirmed to Fit
Always the correct part
We know our products
Quality Products
Free Shipping!
Always the correct part
We know our products
Quality Products
Free Shipping!
MN-1072.pdf
AD-938 LS user guide.pdf
AD-985-ALC-Warranty- Flyer.pdf
Air Lift 1000
Coil spring insert kit
The new Air Lift 1000 HD from Air Lift is a heavy-duty version of the air suspension specialist's debut product, the Air Lift 1000 system. After nearly 70 years, the staple product has been upgraded to offer up to 2,500 lbs. of load-leveling capabilities. Specifically designed for drivers of RAM 1500 pickups, these custom-molded polyurethane air springs are simply inserted in the rear coil springs, no vehicle modifications required. Working with the vehicle's existing suspension, Air Lift 1000 HD does away with many of the problems frequently faced when towing or hauling heavy loads, including squat, poor headlight aim, unresponsive steering, trailer sway, body roll, and bottoming out. By properly leveling the load, squat is eliminated, braking is improved, and the vehicle is returned to a level and stable state, allowing users to tow and haul with safety and comfort. Installing the kit is a simple process, requiring only common hand tools and no frame drilling. The Air Lift 1000 HD kit comes with a clear, easy-to-follow installation manual for you to use as you add air bags to the existing suspension. As the leader in air suspension products for more than 70 years, Air Lift is committed to delivering quality load support parts that last. The key suspension components have all been torture-tested to ensure the highest quality, longevity, and customer satisfaction. With a limited-lifetime warranty, you can purchase this kit with peace of mind. Take your existing air suspension solution to the next level of safety and comfort with the Air Lift 1000 HD today!
Air Lift Company has developed dependable air spring suspension products since our inception in 1949. Our original product, a rubber air spring inserted into a car’s factory coil spring, was created and patented in 1950. We’ve come a long way since 1949 and are proud to be a dedicated suspension specialist company.
Today, Air Lift load support products are sold worldwide and are engineered to fit over 540 vehicles. Our extensive product line offers air helper springs for trucks, RVs, SUVs, CUVs, and vans, as well as the most technologically advanced on-board air compressor systems for on-the-go air spring control.
Air Lift leads the industry in no-drill applications – kits that bolt onto your vehicle’s frame, speeding the installation process. Our teams work constantly to bring innovative products to you and upgrade existing products with the latest technology.
All of our efforts are spent ensuring your safety and comfort by designing, engineering, and manufacturing the highest quality suspension products. We are a family-owned business based in Lansing, Michigan, and make your family and cargo’s safety our top priority.
Experts available to answer your questions
Call 888-634-9494Limited Lifetime
4 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2009 - 2010 | Dodge Ram 1500 | Does not fit if vehicle is equipped with factory air suspension. |
| 2011 - 2018 | Ram 1500 | Does not fit if vehicle is equipped with factory air suspension. |
| 2024 | Ram 1500 Classic | — |
| 2019 - 2023 | Ram 1500 Classic | Does not fit if vehicle is equipped with factory air suspension. |
The Air Lift AIR LIFT 1000 60818HD (Part #BBCG60818HD) fits the following vehicles: 2009-2010 Dodge Ram 1500; 2011-2018 Ram 1500; 2019-2024 Ram 1500 Classic. Always verify your specific year, make, and model before ordering.
Yes, the Air Lift AIR LIFT 1000 60818HD (Part #BBCG60818HD) is designed to fit the 2009-2010 Dodge Ram 1500.
The Air Lift AIR LIFT 1000 60818HD (Part #BBCG60818HD) fits 2009-2010 Dodge Ram 1500 models. The 2024 model year is the last year covered by this part number. For newer models, check for an updated version.
The Air Lift AIR LIFT 1000 60818HD (Part #BBCG60818HD) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
Yes, the Air Lift 1000HD Kit 60818HD is designed for Dodge 1500 Pickup in both 2WD and 4WD configurations. The manual does not specify model years or cab styles, so contact Air Lift customer service at (800) 248-0892 to confirm fitment for your specific vehicle.
The kit includes: 2 air springs (part 48179), 2 air spring protectors (09960), 1 air line assembly (20937), 6 zip ties (10466), 2 valve caps (21230), 4 hex nuts 5/16" (21233), 2 rubber washers (21234), 2 star washers (18411), 2 M8 flat washers (18501), 1 tee fitting (21236), 2 Schrader valves (21455), 6 air line clamps (10638), and 2 straight pump connectors (21455).
Required tools are: hoist or floor jack, 2 safety stands, safety glasses, spoon-type tire iron, pliers, sharp knife, air compressor or compressed air source, and spray bottle with dish soap/water solution.
Some Dodge 1500 models have a rubber isolator at the top of the passenger's side coil spring. If present, it must be removed and can be discarded. This is done during the Getting Started phase before inserting the air spring.
First, remove the plastic cap from the barbed stem on the air spring. Exhaust the air by rolling the spring up toward the stem, then replace the cap to hold it flat. Fold the air spring into a 'hot dog bun' shape. Insert it through the lowest opening of the coil spring with the stem at the top. Push it up by hand or with a blunt instrument such as a spoon-type tire iron. Do not use a sharp object. Once fully inside, remove the cap and allow the air spring to assume its molded shape. Push the cylinder to the bottom of the coil so the stem is accessible.
Single-path routing is recommended for vehicles with even weight distribution. It uses one tee fitting to supply both air springs from a single air line. Dual-path routing is used when weight varies from side to side and unequal pressures are needed to level the load. In dual-path installation, the tee fitting is eliminated and separate air lines are routed to each air spring.
Yes. You must drill a 5/16" (8mm) hole to mount the Schrader valve. The valve is mounted on the vehicle body or bumper, typically inside the fuel tank filler door, inside rear wheel wells, or in the license plate/rear bumper area.
Use the air line clamp (part L) and follow this procedure: (1) Slide the air line clamp onto the air line. (2) Push the air line and clamp over the barbed stem so the air line covers all the barbs. (3) Compress the ears on the clamp with pliers and slide it forward to fully cover the barbs. This procedure applies to all air line connections.
Select a location for the Schrader valve that will be protected and accessible with an air hose. Recommended locations include inside the fuel tank filler door, inside rear wheel wells, or in the license plate or rear bumper area. Drill a 5/16" (8mm) hole and mount the valve with the rubber washer (part G) serving as an outside weather seal. Install the air line on the Schrader valve first.
Leave sufficient air line slack to prevent any strain on the fittings during axle motions. This applies when routing the tee fitting to the air springs and when routing from the tee to the Schrader valve.
Maintain at least 6" (152mm) clearance from the exhaust system to the air line to prevent the air line from melting.
After the air lines are installed and the suspension is adjusted so the air spring just touches the top and bottom of the upper and lower spring mounts, inflate the air springs to 5 PSI (0.34 BAR). This is the minimum recommended pressure.
Four checks are required: (1) Clearance test—inflate to 25-35 PSI and ensure at least 1/2" (13mm) clearance from anything that might rub the air spring. (2) Leak test—inflate to 25-35 PSI and use soapy water solution to check all connections for leaks; all leaks must be eliminated before road testing. (3) Heat test—ensure at least 6" (152mm) clearance from heat sources; install a heat shield if included. (4) Road test—after preceding tests, inflate to level the vehicle, drive 10 miles, and recheck for clearance, loose fasteners, and air leaks.
The maximum inflation pressure is 50 PSI (3.5 BAR). However, the actual air pressure needed depends on load and gross vehicle weight rating. Never inflate beyond 50 PSI.
No. For safety and to prevent possible damage to the vehicle, do not exceed the maximum gross vehicle weight rating (GVWR) or payload rating as indicated by the vehicle manufacturer. The air springs support the load but do not change the vehicle's weight capacity limits.
Check air pressure weekly. Always maintain normal ride height and never inflate beyond 50 PSI (3.5 BAR).
Use a soapy water solution to check all air line connections and the inflation valve core. Spray the solution on all connections while the system is pressurized; bubbles will indicate a leak location. All leaks must be eliminated before road testing. If the system develops a leak, check connections first before deflating and removing the air spring.
No. Attach the straight pump connector (part M) to the air line and then to the air spring fitting. Do not use any tools to tighten the fitting.
Use a sharp knife to cut the air line to length. Cut after routing the air line from the tee, along the top of the frame on both sides, down through the top spring seats, and through the air spring protector to the air springs.
Yes, the Air Lift 1000HD Kit 60818HD is designed for Dodge 1500 Pickup in both 2WD and 4WD. For specific model year confirmation, contact Air Lift at (800) 248-0892.
You need a hoist or floor jack, safety stands, safety glasses, spoon-type tire iron, pliers, sharp knife, air compressor, and spray bottle with soapy water solution.
Yes, you must drill a 5/16" (8mm) hole to mount the Schrader valve on the vehicle body or bumper.
Perform four checks: (1) clearance test at 25-35 PSI with 1/2" minimum clearance, (2) leak test using soapy water, (3) heat test ensuring 6" clearance from heat sources, and (4) road test after 10 miles to recheck clearance and fasteners.
Check air pressure weekly. Always maintain normal ride height and never exceed 50 PSI (3.5 BAR).
No. Do not exceed the maximum GVWR or payload rating indicated by the vehicle manufacturer. The air springs support the load but do not increase weight capacity limits.
Bubbles indicate an air leak at that connection. Identify the location of the leak using the soapy water solution. Check all air line connections and the inflation valve core. Tighten or reseat the connection as needed. All leaks must be eliminated before road testing the vehicle.
After inserting the flattened air spring into the coil and removing the plastic cap from the barbed stem, the air spring should assume its 'as-molded shape' automatically. If it does not, push the cylinder down to the bottom of the coil spring to ensure the stem is fully accessible and the spring can expand properly. If the spring still does not expand, contact Air Lift customer service at (800) 248-0892.
