This Bulldog 54 In. tall farm jack is designed to lift heavy loads and equipment. It is the perfect tool for tearing out stubborn stumps or pulling fence posts and poles. It also serves as an all-purpose hoist or winch. The dependable, rugged ratchet design has a durable, solid steel construction.
| BRAND: | BULLDOG |
| PART NUMBER: | 7060933 |
| WARRANTY: | LIMITED 1 YEAR WARRANTY |
| WEIGHT: | 35.2 LBS |
| CAPACITY: | 8,000 LBS. |
| TRAVEL: | 48 IN. |
| HANDLE LENGTH: | 37 IN. |
| FOOT PLATE SIZE: | 4 IN. X 7 IN. |
Founded in 1920, Bulldog has become the standard for heavy-duty trailer connection hardware in agricultural, military and utility service. The line covers gooseneck hitches and couplers, A-frame and channel-mount trailer couplers with the Wedge-Latch mechanism, and heavy-duty jacks, built for unmatched strength, reliability and safety under demanding loads.
Bulldog was founded in 1920 and has spent more than a century supplying the connection hardware that heavy trailers depend on. Its market has always been the demanding end: agricultural, military and utility applications where a coupler failure is not an inconvenience but a serious incident. The brand summarises its position as Tough and Tested, and it sits within the Horizon Global towing group alongside Reese, Draw-Tite, Fulton, Tekonsha, Bargman and Wesbar.
Gooseneck equipment is the brand's signature. Gooseneck hitches mount in the truck bed over the rear axle, which places the load where the chassis can carry it properly and allows far tighter turning than a receiver hitch permits. Matching gooseneck couplers attach at the trailer end, in round tube and square configurations across the capacity range used by livestock, equipment and flatbed trailers.
The conventional trailer coupler range is built around the Wedge-Latch mechanism, which uses a wedge to take up wear between coupler and ball rather than relying on a fixed clamp that loosens over time. That matters on a trailer accumulating hard miles, where slack in the coupling shows up as noise and shock loading. Couplers are offered in A-frame form for standard tongues and in channel-mount form for straight tongue and fabricated frames, with adjustable channel versions that let a coupler be positioned to suit the tongue height.
Heavy-duty jacks complete the line, sized for the tongue weights that gooseneck and equipment trailers generate. Across the range the emphasis is consistent: forged and heavy-section components, load ratings backed by testing, and hardware specified for agricultural, military and heavy-duty commercial use rather than occasional recreational towing.
Experts available to answer your questions
Call 888-634-94941 Year
The Farm Jack is a portable hydraulic jack manufactured by Horizon Global Americas Inc. It can be used to raise and lower stationary loads, and can also function as a winch or clamp. It is available in 2-ton, 4-ton, and 6-ton models. The jack is designed for farm and general utility applications where portable load handling is needed.
The Farm Jack is available in three models: 2-ton, 4-ton, and 6-ton. Never exceed the maximum rated capacity for your specific model. Refer to the stamped markings or decals on the product to obtain the rated capacity. If uncertain about the capacity before using the product, contact Horizon Global at the technical support number provided in the manual.
Place the base plate of the jack on a firm, level, and dry surface with the steel bar frame in a vertical position. If necessary, use the optional foot plate included with the jack to stabilize the base. Never use the jack on curved or tubular surfaces, as the load may slip off and cause serious bodily injury or death.
Lubricate the jack with a light penetrating oil or a Teflon or silicone spray at the locations shown in the manual. These locations include both climbing pins and associated springs, the shear pin in the handle pin, and front and back edges of the steel bar frame. The jack is not self-lubricating. Inspect the jack before use and lubricate when necessary. Using the jack without proper lubrication will result in poor performance and damage to the jack.
Inspect the jack carefully before each use. Check climbing pins for damage and wear. Make sure the steel bar frame is straight and nothing is blocking the steel bar frame holes. Ensure the jack is properly lubricated. Do not use the jack if it is damaged, worn, or out of alignment. Before every use, inspect the jack for missing or damaged components and ensure that the jack is clean and lubricated.
No. Never put your body under raised loads without properly immobilizing and supporting the load. The operator and bystanders must never position any part of their body under any portion of the product or the load being supported. Failure to follow this instruction may result in serious bodily injury or death.
If the jack is in a vertical position and unsupported, it may tip over and cause serious bodily injury or death. Always support the jack or lay it on its side when not in use.
No. Do not allow children to play on or around the product or the load being supported.
1. Place the base plate on a firm, level, dry surface with the steel bar frame vertical. Use the optional foot plate if needed to stabilize the base. 2. With the handle vertical and clipped to the steel bar frame, pull the reversing latch into the raise position until it locks. 3. Pull the handle away from the steel bar frame. 4. Using the handle, raise the lifting mechanism until the lower clamp is securely under the load. 5. While grasping the handle firmly with both hands, carefully move the handle up and down. As you push down, the upper climbing pin will disengage and engage in the next hole above. As you raise the handle, the lower climbing pin will repeat this process. The load is lifted on each downstroke of the handle. 6. Maintain controlled grip of the handle throughout the entire handle stroke. 7. While raising the load, ensure that the load remains stabilized and the jack remains secure and vertical. 8. When the load has been raised to the desired height, secure the handle in the vertical position by clipping it to the steel bar frame. 9. Stabilize and immobilize the load before lowering it onto any stabilizing blocks.
1. The jack must have a load of 500 lbs or greater before it can be lowered, or else the lifting mechanism will slide down the steel bar frame to the base plate. 2. Position the jack under the load and raise the load as described in the raising instructions in order to remove any blocks holding the load up. 3. Place the handle in the vertical position, clipped against the steel bar frame before attempting to lower the load. 4. Shift the reversing latch to the lower position. 5. While grasping the handle with both hands, carefully move the handle up and down. The load will be lowered on each upstroke of the handle. 6. Maintain controlled grip of the handle throughout the entire handle stroke.
1. Do not exceed the maximum load of 1,000 lbs. 2. Always use chains or tow straps that have a greater working strength capacity than the jack. 3. Loosen the top clamp bolt and rotate the clamp so that it is in-line with the steel bar frame. Retighten the bolt to ft-lbs. 4. Attach one end of a chain or tow strap securely to the load. Attach the other end securely to the top clamp opening. It is recommended to use a shackle (not included) for attachment. 5. Attach another chain or tow strap securely to a fixed object. Attach the other end securely to the lower clamp. It is recommended to use a shackle (not included) for attachment. 6. Operate the jack as if it were being used to raise a load.
1. Do not exceed the maximum load of 1,000 lbs. 2. The top clamp must be positioned perpendicular to the steel bar frame. 3. The top clamp can be moved to any position along the steel bar frame. Remove the top clamp bolt and reposition the top clamp to a new hole position on the steel bar frame. Retighten the bolt to ft-lbs. 4. Operate the jack as if it were being used to raise a load, clamping material between the top and lower clamps.
The top clamp bolt should be retightened to ft-lbs. This applies when repositioning the top clamp for winch or clamping operations.
When using the jack as a winch, the top clamp will support up to 1,000 lbs. Exceeding this limit will result in the top clamp bending or breaking, causing the load to move or the chain or tow strap to snap back, which may cause serious bodily injury or death.
When using the jack for clamping, do not exceed the maximum clamping force of 1,000 lbs. If you exceed this limit, the top clamp could bend or break, resulting in serious bodily injury or death.
During lifting and lowering, the load pushes up against the jack handle. If your hands slip, the jack handle may move rapidly or unexpectedly. Always keep your head and body out of the handle path of movement. If any part of your body is in the path of the handle, it may strike you and result in serious injury or death. Maintain a controlled grip of the handle throughout the entire handle stroke.
The jack handle may move rapidly when shifting the reversing latch. When shifting, ensure the handle is latched in the upright position against the steel bar frame and securely hold the bar in position. If the handle moves rapidly and strikes you, it will result in serious injury or death.
No. Never attempt to raise more than one tire at a time. Never raise an inflated tire more than 6 inches above the ground. Failure to follow these instructions may result in serious bodily injury or death.
The jack can be cleaned with water and a mild detergent if needed. Dry and lubricate immediately after cleaning.
Binding of the climbing pins may be due to dirt, corrosion, or a worn or bent steel bar frame. If binding occurs, clean and lubricate the jack. Test the jack by raising it without a load. If binding continues, do not use the jack.
No. Do not use the jack on curved or tubular surfaces. The load may slip off, causing serious bodily injury or death.
Always use chains or tow straps that have a greater working strength capacity than the jack. The tow strap or chain may break while winching, causing the load to move or the chain or tow strap to snap back, which may cause serious bodily injury or death.
No. Never perform maintenance on the jack while it is under load.
The Farm Jack is available in three models: 2-ton, 4-ton, and 6-ton. Refer to the stamped markings or decals on your product to identify which model you have.
The jack must have a load of 500 lbs or greater before it can be lowered. If the load is less than 500 lbs, the lifting mechanism will slide down the steel bar frame to the base plate.
Use a light penetrating oil or a Teflon or silicone spray. Apply at the climbing pins and associated springs, the shear pin in the handle pin, and front and back edges of the steel bar frame.
Do not exceed the maximum load of 1,000 lbs when raising a stationary load. Refer to the stamped markings or decals on your specific model to obtain the rated capacity.
The optional foot plate is included to stabilize the jack base as needed. Use it if the surface is uneven or if additional stability is required.
Do not use the jack if it is damaged, worn, or out of alignment. Inspect the jack carefully before each use and check climbing pins for damage and wear.
Check that the jack is properly lubricated. Using the jack without proper lubrication will result in poor performance. Inspect the climbing pins for damage and wear. Make sure the steel bar frame is straight and nothing is blocking the steel bar frame holes. If the jack still does not operate properly, do not use it.
Binding of the climbing pins may be due to dirt, corrosion, or a worn or bent steel bar frame. Clean and lubricate the jack. Test the jack by raising it without a load. If binding continues, do not use the jack.
This occurs when the jack does not have a load of 500 lbs or greater. The lifting mechanism will slide down the steel bar frame to the base plate if the load is insufficient. Ensure the load meets the minimum weight requirement before attempting to lower the jack.
| Part Number | Description | Capacity (lbs.) | Height (in.) | Travel (in.) | Finish |
|---|---|---|---|---|---|
| 7061000 | Farm Jack with Handle Holder | 8,000 | 54.00 | 48.00 | Red/Black |
| 7060933 | Farm Jack with Handle Holder | 8,000 | 54.00 | 48.00 | Red/Black |
| 7033500 | Farm Jack | 8,000 | 48.00 | 42.00 | Red/Black |
| 7033443 | Farm Jack | 7,000 | 48.00 | 37.00 | Red/Black |
| 7064300 | Farm Jack | 7,000 | 36.00 | 30.00 | Red/Black |
| 7064233 | Farm Jack | 7,000 | 36.00 | 30.00 | Red/Black |
| Accessories | |||||
| 7086500 | Farm Jack Truck Box Mount Kit, Horizontal or Vertical Mount | ||||
| 7048400 | Farm Jack Foot Plate, 10 in. x 10 in., 8,000 lbs. Capacity | ||||
| 7061520 | Farm Jack Handle Holder, Durable PVC, Eliminates Rattle | ||||
| 7088900 | Farm Jack Carry Handle | ||||
| 7064120 | Farm Jack Maintenance Kit, Includes (2) Climbing Pins, (2) Climbing Pin Springs, (2) Cross Pins and (1) Handle Pin and Clip | ||||
