Draw-Tite Hardware Kit For Class 3 Trailer Hitch, 2 Inch 76555 For 2022-2026 Hyundai Santa Cruz Draw-tite$55.49Out of Stock
View productAsk a Question About This Product
Our in-house experts typically reply within one business day.
Our in-house experts typically reply within one business day.
Draw-tite
Verify Fitment
Select your vehicle to confirm this part fits.
2022 - 2026 Hyundai Santa Cruz
Confirmed to Fit
Select your vehicle to find the exact plug-and-play parts that fit — no cutting or splicing.
Always the correct part
We know our products
Always the correct part
We know our products
Quality Products
Free Shipping!
Quality Products
Free Shipping!
DRAW-TITE Class 3 trailer hitches are the perfect mix of style and stability for those times when youre working on a home project or heading out on an adventure. This DRAW-TITE Class 3 receiver hitch is rated for up to 5,000 lbs. gross trailer weight (GTW) and up to 750 lbs. tongue weight (TW). No weight distribution kits can be used on this specific trailer hitch. DRAW-TITE hitches are designed to provide top towing performance, with solid-all-welded construction and a black powder coat finish to resist rust and corrosion. The Class 3 trailer hitch has a 2 inch square receiver tube opening so you can easily attach accessories like a bike rack or cargo carrier, or a utility trailer. Includes all the mounting hardware needed for installation and are backed by a nationwide lifetime limited warranty. DRAW-TITE trailer hitches are tested to exceed V-5 and SAE J684 standards. DRAW-TITE: North Americas Favorite Hitch.
| BRAND: | DRAW-TITE |
| PART NUMBER: | 76555 |
| WARRANTY: | LIMITED LIFETIME WARRANTY |
| WEIGHT: | 39.541 LBS |
| GROSS TOWING WEIGHT: | 5,000 LBS. |
| GROSS TONGUE WEIGHT: | 750 LBS. |
| RECEIVER SIZE: | 2 IN. |
| HITCH CLASS: | III |
| DRILLING REQUIRED: | NO |
| MOUNTING HARDWARE INCLUDED: | YES |
| ATTACHMENT LOCATION: | REAR |
| HITCH VISIBILITY: | CONCEALED |
| CROSS-TUBE TYPE: | SQUARE TUBE |
| BALL MOUNT INCLUDED: | NO |
| COLOR: | BLACK |
| FINISH: | BLACK POWDER COAT OVER E-COAT |
| MATERIAL: | STEEL |
| MOUNTING LOCATION: | VEHICLE FRAME |
| MOUNTING TYPE: | BOLT-ON |
| GROSS TOWING WEIGHT WITH WEIGHT DISTRIBUTION: | 7,500 LBS. |
| GROSS TONGUE WEIGHT WITH WEIGHT DISTRIBUTION: | 1,125 LBS. |
Draw-Tite has designed custom-fit trailer hitches since 1946 and is one of North America's most widely fitted hitch brands. Receiver hitches use solid all-welded construction and low-profile designs that follow modern vehicle contours, install with minimal bumper cutting or drilling, meet or exceed V5 CSA and SAE J684 standards, and carry a limited lifetime warranty.
Draw-Tite has been leading custom-fit trailer hitch design and engineering since its founding in 1946, and it remains one of the most widely fitted hitch brands in North America. The company's stated approach is straightforward: every hitch is tested rigorously so that it performs well beyond published industry standards, a philosophy it markets as Tested Tough. It sits within the Horizon Global towing group alongside Reese, Fulton, Bulldog, Tekonsha, Bargman and Wesbar.
Custom fit is the defining characteristic. Rather than adapting a universal design, Draw-Tite engineers a trailer hitch for a specific make, model and model year, so it bolts to existing frame locations with minimal bumper cutting or drilling. Low-profile designs follow the rear contours and aerodynamic styling of modern vehicles, which matters more than it once did now that rear fascias are shaped and sensor-equipped. Construction is solid all-welded steel for maximum strength, and every hitch meets or exceeds V5 CSA and SAE J684 standards and is backed by a nationwide limited lifetime warranty.
The range spans receiver sizes and classes to suit different loads, from 1-1/4 inch receivers for bike racks, cargo carriers and light trailers up through 2 inch receivers for heavier towing. Front mount hitches add a receiver at the front of the vehicle for winch mounts, snow plows, spare carriers and precise trailer positioning.
The Hidden Hitch series takes concealment further by mounting behind the vehicle's rear fascia, so the vehicle keeps its factory appearance until a removable receiver is fitted. Each is custom designed per make and model for a no-drill installation that does not compromise ground clearance, rated for up to 3,500 pounds gross trailer weight and 350 pounds tongue weight. Matching plug-and-play wiring completes the towing system.
Experts available to answer your questions
Call 888-634-9494Lifetime
Equip your vehicle for towing and hitch-mounted accessories with a dependable CURT 2" trailer hitch. Designed for a vehicle-specific fit, CURT receiver hitches provide a strong and secure connection point for towing trailers, carrying bikes, transporting cargo and using other compatible 2-inch hitch accessories.
Our selection of CURT 2-inch receiver hitches includes options for trucks, SUVs, crossovers, vans and passenger vehicles. Each hitch is engineered to match specific vehicle mounting points, helping provide a clean installation and dependable performance. Depending on the vehicle application, available options may include Class 3, Class 4 and heavy-duty receiver hitches with different gross trailer weight and tongue weight capacities.
A 2" x 2" receiver opening is one of the most common hitch sizes and works with a wide range of towing accessories, including ball mounts, bike racks, cargo carriers, hitch steps and tow hooks. When towing a trailer, you may also need a properly rated trailer ball, hitch pin, wiring harness, brake controller or weight distribution system.
CURT trailer hitches feature a durable black finish designed to help protect against rust, scratches and exposure to road conditions. Many models install using existing holes in the vehicle frame, although drilling, trimming or temporary removal of vehicle components may be required for certain applications.
Use our vehicle fitment tools to find the correct CURT 2" trailer hitch for your year, make and model. Always compare the hitch rating with your vehicle’s towing capacity and the ratings of every component in your towing setup. The maximum towing capacity is determined by the lowest-rated component.
Shop CURT 2-inch trailer hitches at TowUniverse for vehicle-specific fitment, trusted towing performance and access to the accessories needed to complete your towing setup.
1 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2022 - 2026 | Hyundai Santa Cruz | Class 3 Trailer Hitch: 5000 lbs 750/5,000 lbs. Weight Carrying (tongue weight/gross trailer weight) Uses all existing holes. No Drilling required Install Time is 40 minutes |
The Draw-tite Class 3 Trailer Hitch, 2" Square Receiver, Black for Select Hyundai Santa Cruz 76555 (Part #DT76555) fits the following vehicles: 2022-2026 Hyundai Santa Cruz. Always verify your specific year, make, and model before ordering.
Yes, the Draw-tite Class 3 Trailer Hitch, 2" Square Receiver, Black for Select Hyundai Santa Cruz 76555 (Part #DT76555) is designed to fit the 2022-2026 Hyundai Santa Cruz.
The Draw-tite Class 3 Trailer Hitch, 2" Square Receiver, Black for Select Hyundai Santa Cruz 76555 (Part #DT76555) fits 2022-2026 Hyundai Santa Cruz models. The 2026 model year is the last year covered by this part number. For newer models, check for an updated version.
The Draw-tite Class 3 Trailer Hitch, 2" Square Receiver, Black for Select Hyundai Santa Cruz 76555 (Part #DT76555) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
Yes, part numbers 76555, 84555, and CQT76555 are designed for 2022-current Hyundai Santa Cruz models. Visit the Horizon Global website for the most up-to-date information regarding specific application years and trim levels.
The maximum gross trailer weight is 5000 lb. (2267 kg) and the maximum tongue weight is 750 lb. (340 kg). Do not exceed the lower of your towing vehicle manufacturer's rating or these limits.
The 76555 is a weight-carrying hitch with a maximum gross trailer weight of 5000 lb. (2267 kg) and maximum tongue weight of 750 lb. (340 kg). Weight-distributing capability is listed as N/A for this model.
Fastener kit 76555F includes 6 hex bolts (M12×1.25×40 CL10.9) and 6 conical washers (1/2 inch). The conical washers have a teeth side that faces against the hitch.
Required tools include: ratchet, 19 mm sockets, 6-inch socket extension, torque wrench, safety glasses, plastic trim tools, wire brush, exhaust hanger removal tool, pliers for exhaust removal, and soapy water or lubricant spray. The manual also recommends having the vehicle owner's manual available for spare tire lowering procedures.
Yes. Step 2 of the installation requires lowering the spare tire according to the vehicle owner's manual before installing the hitch. The spare tire must be reinstalled in step 6 after the hitch is secured.
Yes. Step 1 requires lowering the exhaust muffler by removing the 3 rearmost rubber hangers using an exhaust hanger removal tool. Applying lubricant or soapy water to the rubber hangers makes removal easier. Ensure the exhaust is properly supported before removing the hangers. The exhaust must be reinstalled in step 6 after the hitch is secured.
Yes. Step 3 requires using a plastic trim tool to remove 1 electric harness clip from the bottom of the frame rail on the driver side. This must be done before installing the hitch.
Install the fasteners loosely initially. Step 4 states to 'loosely install conical washers and hex bolts to the hitch.' Only after all fasteners are in place should they be tightened to the specified torque in step 5.
All M12×1.25×40 CL10.9 fasteners must be tightened to 76 ft.lb. (103 N·m) using a torque wrench. Proper torque is essential to keep the hitch secure to the vehicle when towing.
The conical washers have a teeth side that must face against the hitch. Install the washers with the teeth side pointing toward the hitch receiver.
Yes. Step 4 recommends using a wire brush to clean the weldnuts if needed before raising the hitch into position and installing the fasteners.
The maximum tongue weight is 750 lb. (340 kg). Do not exceed this limit or the lower of your towing vehicle manufacturer's rating.
If excess sway occurs, remove your foot from the gas pedal and hold the steering wheel as steady as possible. Do not apply your brakes and do not speed up. Reduce speed and maintain steady steering control.
Yes. Always wear safety glasses when installing the hitch. The manual also recommends wearing eye protection when working beneath the vehicle.
Check all fasteners periodically to ensure they are tight and the hitch is securely mounted to your vehicle. The manual emphasizes checking the hitch frequently to ensure all fasteners and the ball are properly tightened.
No. Do not cut, weld, or modify the receiver. The manual explicitly prohibits these modifications. Do not cut access or attachment holes with a torch.
If the hitch or ball is damaged, it must be removed and replaced. Do not continue using a damaged hitch.
If the hitch is removed, plug all holes in the trunk pan or other body panels to prevent entry of water and exhaust fumes.
Load the trailer heavier in front. This helps maintain proper weight distribution and towing stability.
Slow down when towing and never exceed any posted speed limit. Always wear your seatbelt while towing.
Yes, part numbers 76555, 84555, and CQT76555 fit 2022-current Hyundai Santa Cruz models. Check the Horizon Global website for the most current trim level compatibility.
Maximum gross trailer weight: 5000 lb. (2267 kg). Maximum tongue weight: 750 lb. (340 kg). Do not exceed the lower of your vehicle manufacturer's rating or these limits.
Ratchet, 19 mm sockets, 6-inch socket extension, torque wrench, safety glasses, plastic trim tools, wire brush, exhaust hanger removal tool, and lubricant or soapy water. Installation time: approximately 40 minutes for professional installers.
Yes. Both must be lowered before installation and reinstalled afterward. The exhaust is lowered by removing 3 rubber hangers; the spare tire is lowered per the vehicle owner's manual.
All M12×1.25×40 CL10.9 hex bolts must be tightened to 76 ft.lb. (103 N·m) using a torque wrench. Proper torque is critical for safe towing.
Install fasteners loosely first, then tighten all to 76 ft.lb. (103 N·m) with a torque wrench in the final step.
Always wear your seatbelt, slow down, never exceed posted speed limits, load the trailer heavier in front, and do not exceed the hitch's 5000 lb. gross trailer weight or 750 lb. tongue weight limits.
Check all fasteners periodically to ensure they remain tight and the hitch is securely mounted. Verify the ball is properly tightened before each tow.
Yes, a compatible bike rack, cargo carrier or other accessory with a 2" x 2" shank can generally be used. Make sure the accessory does not exceed the hitch’s tongue weight rating, the vehicle’s limits or the accessory manufacturer’s capacity. Account for the combined weight of the carrier and everything loaded onto it.
