Tekonsha
Verify Fitment
Select your vehicle to confirm this part fits.
2007 - 2009 Chrysler Aspen
Confirmed to Fit
2004 - 2009 Dodge Durango
Confirmed to Fit
Always the correct part
We know our products
Quality Products
Free Shipping!
Always the correct part
We know our products
Quality Products
Free Shipping!
Tekonsha T-One connector (also referred to as T-Connector) wiring harnesses are the fastest and easiest way to add an electrical connector to the back of your vehicle. These connectors are used to link the wiring from your vehicle to the trailer when towing. Tekonsha T-One connectors feature custom designs to fit each vehicle make and model based on manufacturer specifications. Plus, the Plug & Play connectors on the end of the wires make it easy to install. No cutting or splicing!
Tekonsha offers the largest, most complete line of T-One connectors. To install a Tekonsha T-One wiring harness, simply locate your vehicle's wiring harness connector typically behind the vehicle taillight - unplug the connection and insert the T-Connector into the vehicle's harness. It's that easy! So what are you waiting for? Hit the road with the peace of mind only Tekonsha can provide. Life's a Journey. Stop Often.
| BRAND: | TEKONSHA |
| PART NUMBER: | 118390 |
| WARRANTY: | LIMITED 1 YEAR WARRANTY |
| WEIGHT: | 2 LBS |
| UNIVERSAL OR SPECIFIC FIT: | SPECIFIC |
| CIRCUIT PROTECTED: | YES |
| HARNESS TYPE: | MALE FEMALE |
| TERMINAL QUANTITY: | 4 |
| WIRE COLORS: | BROWN, GREEN, YELLOW, WHITE |
| WIRE QUANTITY: | 4 |
| WIRE GAUGE: | 16 GA. |
| POWER LEAD REQUIRED: | YES |
| ELECTRICAL SYSTEM TYPE: | 3-WIRE SYSTEM |
| HARDWARE INCLUDED: | YES |
Tekonsha is a leading manufacturer of electronic trailer brake controllers, pioneering the category in the 1970s. The lineup spans proportional units such as the Prodigy P3 and Prodigy iD, time-delayed controllers, the wireless Prodigy RF, plus vehicle-specific wiring harnesses, adapters and trailer brake components engineered for smooth, predictable stopping at any speed.
Tekonsha Engineering Company began in 1964 building RV steps and mirrors. Within a few years it had found its real calling, and by the 1970s Tekonsha was pioneering the manufacture of electronic trailer brake controllers, the product category that still defines the brand. More than half a century later it remains the reference name in trailer braking and is part of the Horizon Global group alongside Reese, Draw-Tite, Fulton, Bulldog and Wesbar.
A brake controller is the component that tells a trailer's electric brakes how hard to work and when, and getting that right is the difference between a controlled stop and a shove from behind. Tekonsha builds both major types. Proportional controllers use an internal accelerometer to sense how quickly the tow vehicle is slowing and apply trailer braking to match, so light braking stays light and hard braking is immediate. Time-delayed controllers ramp to a preset output over a fixed interval, a simpler and more economical approach that suits occasional towing.
The current brake controller range covers most of that ground. The Prodigy iD pairs with a phone through Tekonsha's EDGE technology for setup and monitoring, the P3 offers storable settings for multiple trailers and a trilingual colour LED display, the Prodigy P2 adds a dimmable display and boost mode for heavier loads, and the Voyager keeps operation simple and dependable. The Prodigy RF mounts to the trailer itself and controls wirelessly, which suits rental fleets and drivers who swap tow vehicles.
Installation is supported by vehicle-specific brake control harnesses that plug into a factory connector rather than requiring cut-and-splice wiring, along with mounting brackets and adapters. Matched controller bundles pair a unit with the correct harness. Products are tested to meet and often exceed published industry standards.
Experts available to answer your questions
Call 888-634-94941 Year
Yes, the 2007-2009 Chrysler Aspen, 2004-2009 Dodge Durango Tekonsha Plug & Play T-Connector Adapter Trailer Wiring 118390 (Part #TK118390) is designed to fit the 2007-2009 Chrysler Aspen.
The 2007-2009 Chrysler Aspen, 2004-2009 Dodge Durango Tekonsha Plug & Play T-Connector Adapter Trailer Wiring 118390 (Part #TK118390) fits the following vehicles: 2007-2009 Chrysler Aspen; 2004-2009 Dodge Durango. Always verify your specific year, make, and model before ordering.
The 2007-2009 Chrysler Aspen, 2004-2009 Dodge Durango Tekonsha Plug & Play T-Connector Adapter Trailer Wiring 118390 (Part #TK118390) fits 2007-2009 Chrysler Aspen models. The 2009 model year is the last year covered by this part number. For newer models, check for an updated version.
The 2007-2009 Chrysler Aspen, 2004-2009 Dodge Durango Tekonsha Plug & Play T-Connector Adapter Trailer Wiring 118390 (Part #TK118390) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
The T-Connector is a vehicle taillight integration harness that allows a trailer to receive brake, turn, and tail light signals from your vehicle's existing taillight system. It plugs between your vehicle's taillight wiring and the taillight housing, and connects to a 4-flat trailer connector mounted under the vehicle. The system includes a fused power supply that draws from the vehicle's battery.
The T-Connector is designed for vehicles with dual taillight assemblies that can be accessed and removed from the rear. The manual does not specify vehicle makes, models, years, bed lengths, cab styles, or drivetrains. Contact the manufacturer or your retailer with your vehicle's year, make, model, and body style to confirm fitment before purchase.
You will need: trim panel remover, wire crimpers, wire cutters, and pliers. These are standard electrical and panel removal tools.
The T-Connector kit includes: two T-Connector ends (one with yellow wire, one with green wire), a 4-flat connector, a black 12 gauge wire, a yellow fuse holder with 10 amp fuse, yellow butt connectors, double-sided tape for mounting the black box, and cable ties for securing the harness. A bracket for the 4-flat connector is not included.
Yes. You must disconnect the vehicle's negative (−) battery cable before beginning installation. This is required in step 5 before working with the fuse holder and power connections. Reconnect the negative battery cable only after the fuse holder is properly connected and the 10 amp fuse is installed (step 8).
Open the tailgate and remove the right side taillight assembly first by removing the two clips holding it in place. Carefully pry the housing away from the vehicle, being careful not to break the alignment tabs. Repeat the same process for the left side taillight assembly. Then slide the red locking tab on the vehicle wiring harness connectors to the unlocked position and disconnect the vehicle wiring harness from both taillight sockets.
The T-Connector end with the yellow wire plugs in between the mating plugs on the driver's side taillight socket and vehicle wiring harness. This allows the T-Connector to tap into the driver's side taillight circuit.
On the driver's side, route the T-Connector end with the green wire and the wire with the 4-flat connector down through the opening between the vehicle bumper and body. Route the T-Connector end with green wire to the passenger's side and route the 4-flat connector underneath the bumper. Route the T-Connector end with green wire up through the opening on the passenger side. Avoid hot pipes, heat shields, the fuel tank, or any other points that may pinch or break the wire. Repeat the connection for the passenger side T-Connector end with the green wire.
The T-Connector uses a 10 amp fuse. The fuse is installed in the yellow fuse holder provided with the kit. The fuse must be removed before cutting the fuse holder wire during installation (step 5) and reinstalled after all connections are complete (step 8).
Disconnect the vehicle's negative (−) battery cable. Remove the fuse from the yellow fuse holder. Cut the fuse holder wire and attach the ring terminal to the vehicle's positive (+) battery cable. Connect the other end of the fuse holder to the black 12 gauge wire using the yellow butt connector provided. This creates a fused power supply from the battery to the T-Connector system.
Beginning from the front of the vehicle, route the black 12 gauge wire rearward along the frame rail, avoiding hot pipes, heat shields, the fuel tank, or any other points that may pinch or break the wire. Continue to the rear driver's side. Locate the opening between the vehicle rear bumper and body and route the wire up through this hole. Attach the black 12 gauge wire to the red wire from the T-Connector black box using the supplied yellow butt connector.
Mount the T-Connector black box behind the taillight assembly on the driver's side. Clean a flat area using a mixture of rubbing alcohol and water, then mount the black box using the double-sided tape provided. Ensure all wiring is secured before reinstalling the taillight housing.
Mount the 4-flat connector in a suitable location under the vehicle. The manual does not provide a specific mounting location or bracket. A bracket is not included with the kit, so you will need to source an appropriate mounting solution separately.
Secure all loose wiring before reinstalling the taillight assemblies. When reinstalling the taillight housing, position the vehicle wiring harness between the housing and the vehicle body. Secure the remainder of the T-Connector harness under the bumper with the cable ties provided, being careful to avoid any areas that would cut or pinch the wire.
After installation is complete, test and verify the installation with a test light or by connecting an actual trailer. All connections must be complete for the T-Connector to function properly. This ensures that brake, turn, and tail light signals are being transmitted correctly to the trailer connector.
Do not exceed the lower of your towing manufacturer's rating or these limits: maximum 1 stop/turn light per side at 2.1 amps each; maximum tail lights at 4.2 amps total. Overloading the circuit can cause fires. Consult your vehicle's owner's manual and instruction sheet for additional information about your specific towing capacity.
When routing wires under the vehicle, avoid hot pipes, heat shields, the fuel tank, or any other points that may pinch or break the wire. Route wires carefully through openings between the bumper and body. Secure all wiring with the provided cable ties and avoid areas that could cut or pinch the harness. Proper routing prevents wire damage and potential electrical or fire hazards.
The T-Connector fits vehicles with dual taillight assemblies accessible from the rear. Confirm fitment with the manufacturer or retailer using your vehicle's year, make, model, and body style.
Trim panel remover, wire crimpers, wire cutters, and pliers.
Yes, disconnect the negative battery cable before installation and reconnect it only after the fuse holder is connected and the 10 amp fuse is installed.
10 amp fuse, installed in the yellow fuse holder provided.
Maximum 1 stop/turn light per side (2.1 amps each) and maximum tail lights (4.2 amps total). Do not exceed your vehicle's towing manufacturer rating.
Test with a test light or by connecting a trailer to verify all brake, turn, and tail light signals are working correctly.
The manual states that all connections must be complete for the T-Connector to function properly. Verify: (1) both T-Connector ends (yellow and green wire) are fully plugged into their respective taillight sockets; (2) the black 12 gauge power wire is connected to the red wire from the black box using a yellow butt connector; (3) the fuse holder is properly connected to the vehicle's positive battery terminal with a ring terminal; (4) the 10 amp fuse is installed in the fuse holder; (5) the negative battery cable is reconnected. Test with a test light or trailer to confirm all brake, turn, and tail light signals are present.
2 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2007 - 2009 | Chrysler Aspen | Tow Harness T: Connector Assembly Uses all existing holes. No Drilling required Install Time is 60 minutes |
| 2004 - 2009 | Dodge Durango | Tow Harness T: Connector Assembly Uses all existing holes. No Drilling required Install Time is 60 minutes |
