Tekonsha Tow Harnesses are the replacement for your factory electrical connector to the back of your vehicle. These harnesses are used to link the wiring from your vehicle to the trailer when towing. Tekonsha Tow Harnesses feature custom designs to fit each vehicle make and model based on manufacturer specifications. Plus, the Plug & Play connectors on the end of the wires make it easy to install. No cutting or splicing!
Tekonsha offers the largest, most complete line of Replacement Tow Harnesses. Hit the road with the peace of mind only Tekonsha can provide. Life's a Journey. Stop Often.
| BRAND: | TEKONSHA |
| PART NUMBER: | 118261 |
| WARRANTY: | LIMITED 1 YEAR WARRANTY |
| WEIGHT: | 1.25 LBS |
| UNIVERSAL OR SPECIFIC FIT: | SPECIFIC |
| CIRCUIT PROTECTED: | NO |
| HARNESS TYPE: | MALE FEMALE |
| TERMINAL QUANTITY: | 7 |
| WIRE COLORS: | BROWN, GREEN, YELLOW, WHITE |
| WIRE QUANTITY: | 7 |
| WIRE GAUGE: | 18 AWG, .85 AVSS |
| POWER LEAD REQUIRED: | NO |
| ELECTRICAL SYSTEM TYPE: | 2-WIRE SYSTEM |
| HARDWARE INCLUDED: | YES |
| AMPERAGE: | 30 A |
Tekonsha is a leading manufacturer of electronic trailer brake controllers, pioneering the category in the 1970s. The lineup spans proportional units such as the Prodigy P3 and Prodigy iD, time-delayed controllers, the wireless Prodigy RF, plus vehicle-specific wiring harnesses, adapters and trailer brake components engineered for smooth, predictable stopping at any speed.
Tekonsha Engineering Company began in 1964 building RV steps and mirrors. Within a few years it had found its real calling, and by the 1970s Tekonsha was pioneering the manufacture of electronic trailer brake controllers, the product category that still defines the brand. More than half a century later it remains the reference name in trailer braking and is part of the Horizon Global group alongside Reese, Draw-Tite, Fulton, Bulldog and Wesbar.
A brake controller is the component that tells a trailer's electric brakes how hard to work and when, and getting that right is the difference between a controlled stop and a shove from behind. Tekonsha builds both major types. Proportional controllers use an internal accelerometer to sense how quickly the tow vehicle is slowing and apply trailer braking to match, so light braking stays light and hard braking is immediate. Time-delayed controllers ramp to a preset output over a fixed interval, a simpler and more economical approach that suits occasional towing.
The current brake controller range covers most of that ground. The Prodigy iD pairs with a phone through Tekonsha's EDGE technology for setup and monitoring, the P3 offers storable settings for multiple trailers and a trilingual colour LED display, the Prodigy P2 adds a dimmable display and boost mode for heavier loads, and the Voyager keeps operation simple and dependable. The Prodigy RF mounts to the trailer itself and controls wirelessly, which suits rental fleets and drivers who swap tow vehicles.
Installation is supported by vehicle-specific brake control harnesses that plug into a factory connector rather than requiring cut-and-splice wiring, along with mounting brackets and adapters. Matched controller bundles pair a unit with the correct harness. Products are tested to meet and often exceed published industry standards.
Experts available to answer your questions
Call 888-634-94941 Year
3 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2009 - 2012 | Ford E-150 Econoline | Tow Harness Wiring Package Uses all existing holes. No Drilling required Install Time is 10 minutes With Factory 7: Way (Prepped Class II Towing Package) |
| 2009 - 2012 | Ford E-250 Econoline | Tow Harness Wiring Package Uses all existing holes. No Drilling required Install Time is 10 minutes With Factory 7: Way (Prepped Class II Towing Package) |
| 2009 - 2012 | Ford E-350 Econoline Super Duty | Tow Harness Wiring Package Uses all existing holes. No Drilling required Install Time is 10 minutes With Factory 7: Way (Prepped Class II Towing Package) |
The Tekonsha Tow Harness, 7-Way TK118261 (Part #TK118261) fits 2009-2012 Ford E-150 Econoline models. The 2012 model year is the last year covered by this part number. For newer models, check for an updated version.
The Tekonsha Tow Harness, 7-Way TK118261 (Part #TK118261) fits the following vehicles: 2009-2012 Ford E-150 Econoline; 2009-2012 Ford E-250 Econoline; 2009-2012 Ford E-350 Econoline Super Duty. Always verify your specific year, make, and model before ordering.
Yes, the Tekonsha Tow Harness, 7-Way TK118261 (Part #TK118261) is designed to fit the 2009-2012 Ford E-150 Econoline.
The Tekonsha Tow Harness, 7-Way TK118261 (Part #TK118261) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
Yes, the T-Connector is designed for the Ford E-150. However, your vehicle must have both a 16-Pin and 4-Pin factory wiring harness connector located in the rear underneath the vehicle inside the driver's side frame rail. If only the 16-Pin housing is present, this product will not work; you will need a Class I wiring harness instead.
If only the 16-Pin housing is present, you cannot use the T-Connector (118261-037). You must discontinue installation and consult the application guide for a Class I wiring harness instead, which is designed for vehicles with only the 16-Pin connector.
The T-Connector kit includes the T-Connector harness, a 7-way socket, and a Trailer Tow Battery Charge Relay. A bracket or electrical box to mount and secure the harness is not included and must be obtained separately.
Only a test-probe is listed as a required tool. You will also need access to your vehicle's owner's manual to locate the Trailer Tow Battery Charge Relay position in the fuse/relay box.
The factory wiring harness with the 16-Pin and 4-Pin connectors is located in the rear of the vehicle, underneath it, inside the driver's side frame rail.
The fuse/relay box is located on the driver's side of the vehicle near the firewall. You must consult your vehicle's owner's manual to locate the specific Trailer Tow Battery Charge Relay position within the box.
Yes. Remove the factory tow harness protective caps and check that the mating surface is clean and free of dirt. Clean the surface if necessary before inserting the tow plugs.
Insert the tow plugs carefully into the connectors, being careful not to damage the locking tabs. Ensure that the connectors are fully inserted with the locking tabs in place. Do not force the connection.
Open the vehicle's hood and locate the fuse/relay box on the driver's side near the firewall. Consult your vehicle's owner's manual to find the Trailer Tow Battery Charge Relay location. Insert the relay (provided with the kit) into that position.
Route the T-Connector harness along the inside of the bumper toward the center of the vehicle. Route the wire carefully to avoid any hot pipes, heat shields, the fuel tank, or any other points that may pinch or break the wire.
Plug the 7-way socket (provided) into the Trailer Tow Harness after routing the harness to its final location.
Wear safety glasses and use all safety precautions during installation. Route the harness carefully to avoid hot pipes, heat shields, the fuel tank, or any other points that may pinch or break the wire. Secure all loose wires and mount the harness in an accessible location with a bracket or electrical box (not included).
Overloading the circuit can cause fires. Do not exceed the manufacturer's fuse rating. Consult your vehicle's owner's manual and instruction sheet for the correct fuse rating and additional information.
All connections must be complete for the T-Connector to function properly. Test and verify the installation with a test light or trailer once installed. This ensures all connections are working correctly before towing.
Yes. Secure all loose wires and mount the Trailer Tow Harness in an accessible location with a bracket or electrical box. These mounting items are not included with the kit and must be obtained separately.
Yes, if your vehicle has both 16-Pin and 4-Pin factory wiring harness connectors in the rear underneath the vehicle inside the driver's side frame rail. If only the 16-Pin connector is present, you need a Class I wiring harness instead.
You need a test-probe and access to your vehicle's owner's manual to locate the Trailer Tow Battery Charge Relay position.
The kit includes the T-Connector harness, a 7-way socket, and a Trailer Tow Battery Charge Relay. A mounting bracket or electrical box is not included.
Do not exceed the manufacturer's fuse rating, as overloading the circuit can cause fires. Wear safety glasses during installation and route the harness away from hot pipes, heat shields, and the fuel tank.
Test and verify the installation with a test light or trailer once all connections are complete. This ensures the T-Connector is functioning properly before towing.
Yes. Secure all loose wires and mount the harness in an accessible location with a bracket or electrical box (not included). This prevents damage to the wiring during vehicle operation.
