These durable custom hitches are manufactured for 1984-2001 Jeep Cherokee, 1984-1990 Jeep Wagoneer and attach to your vehicle?s frame or bumper for a sleek, clean appearance. Each hitch also has a 2 inch square receiver tube opening ? the most common and versatile on the market - allowing you to attach accessories like a bike rack or cargo carrier, or hook up your pop-up, boat trailer, or utility trailer. The options are endless! DRAW-TITE Class 3 Custom Trailer Hitches come complete with all the mounting hardware needed for installation and are backed by a nationwide lifetime limited warranty. So, whether you are headed out to the campground, the lake, or the bike trails, or you are tackling a project at home and need to haul the materials home, choose DRAW-TITE and travel with confidence knowing your setup is connected with the security only DRAW-TITE can provide. DRAW-TITE: North America?s Favorite Hitch
Draw-Tite has designed custom-fit trailer hitches since 1946 and is one of North America's most widely fitted hitch brands. Receiver hitches use solid all-welded construction and low-profile designs that follow modern vehicle contours, install with minimal bumper cutting or drilling, meet or exceed V5 CSA and SAE J684 standards, and carry a limited lifetime warranty.
Draw-Tite has been leading custom-fit trailer hitch design and engineering since its founding in 1946, and it remains one of the most widely fitted hitch brands in North America. The company's stated approach is straightforward: every hitch is tested rigorously so that it performs well beyond published industry standards, a philosophy it markets as Tested Tough. It sits within the Horizon Global towing group alongside Reese, Fulton, Bulldog, Tekonsha, Bargman and Wesbar.
Custom fit is the defining characteristic. Rather than adapting a universal design, Draw-Tite engineers a trailer hitch for a specific make, model and model year, so it bolts to existing frame locations with minimal bumper cutting or drilling. Low-profile designs follow the rear contours and aerodynamic styling of modern vehicles, which matters more than it once did now that rear fascias are shaped and sensor-equipped. Construction is solid all-welded steel for maximum strength, and every hitch meets or exceeds V5 CSA and SAE J684 standards and is backed by a nationwide limited lifetime warranty.
The range spans receiver sizes and classes to suit different loads, from 1-1/4 inch receivers for bike racks, cargo carriers and light trailers up through 2 inch receivers for heavier towing. Front mount hitches add a receiver at the front of the vehicle for winch mounts, snow plows, spare carriers and precise trailer positioning.
The Hidden Hitch series takes concealment further by mounting behind the vehicle's rear fascia, so the vehicle keeps its factory appearance until a removable receiver is fitted. Each is custom designed per make and model for a no-drill installation that does not compromise ground clearance, rated for up to 3,500 pounds gross trailer weight and 350 pounds tongue weight. Matching plug-and-play wiring completes the towing system.
Experts available to answer your questions
Call 888-634-94941 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 1997 - 2001 | Jeep Cherokee | — |
The 1997-2001 Jeep Cherokee Draw-tite Class 3 Trailer Hitch, 2 Inch Square Receiver Bundle w/ Plug-n-Play T-One Wiring Harness (Part #DTB75054-118354) fits 1997-2001 Jeep Cherokee models. The 2001 model year is the last year covered by this part number. For newer models, check for an updated version.
The 1997-2001 Jeep Cherokee Draw-tite Class 3 Trailer Hitch, 2 Inch Square Receiver Bundle w/ Plug-n-Play T-One Wiring Harness (Part #DTB75054-118354) fits the following vehicles: 1997-2001 Jeep Cherokee. Always verify your specific year, make, and model before ordering.
Yes, the 1997-2001 Jeep Cherokee Draw-tite Class 3 Trailer Hitch, 2 Inch Square Receiver Bundle w/ Plug-n-Play T-One Wiring Harness (Part #DTB75054-118354) is designed to fit the 1997-2001 Jeep Cherokee.
The 1997-2001 Jeep Cherokee Draw-tite Class 3 Trailer Hitch, 2 Inch Square Receiver Bundle w/ Plug-n-Play T-One Wiring Harness (Part #DTB75054-118354) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
The T-Connector is a tail light wiring adapter that connects between your vehicle's existing tail light wiring harness and a trailer. It allows you to tap into the vehicle's tail light circuits without cutting or permanently modifying the factory wiring. The unit is rated for 4 amps per circuit.
The T-Connector is designed to work with vehicle tail light wiring harnesses that have white rectangular connectors matching the ends of the T-Connector. You will need to locate your vehicle's tail light wiring harness and verify that the connectors match before purchasing. If your vehicle's connectors do not match, this adapter will not be compatible.
You will need a drill with a 3/32" drill bit. The manual does not specify additional tools, but you may find it helpful to have a screwdriver for removing and reattaching the rear quarter panel trim and spare tire, and a test light or access to a trailer for testing the installation.
The T-Connector kit includes an eyelet and screw for securing the white ground wire, and either a screw or cable tie for securing the black box to the vehicle.
The manual does not specify whether battery disconnection is required. Contact the manufacturer or a professional installer for guidance on this safety step.
Open the rear door of your vehicle. Temporarily remove the spare tire and rear quarter panel trim located on the driver's side. These items will be reattached after installation.
Locate the vehicle's tail light wiring harness with white rectangular connectors. Separate the harness connectors carefully, being careful not to break the locking tabs. Insert the T-Connector between the harness connectors and lock it into place. Ensure that the connectors are fully inserted and the locking tabs are in place.
Yes. You must drill a 3/32" hole in a suitable grounding point near the adapter to secure the white ground wire using the eyelet and screw provided. Do not drill into the vehicle floor or bed.
Drill a 3/32" hole (2.4 mm) at a suitable grounding point near the adapter. Do not drill into the vehicle floor or bed. Clean dirt and rustproofing from the area before drilling.
Locate a suitable grounding point near the adapter. The manual specifies that you must not drill into the vehicle floor or bed. Clean dirt and rustproofing from the area before drilling the 3/32" hole.
The T-Connector is rated for 4 amps per circuit. Do not exceed this rating when connecting trailer lighting or other electrical loads.
The white wire is the ground wire and must be secured to a suitable grounding point using the eyelet and screw provided. The black box houses the connector and is secured to the vehicle using the screw or cable tie provided. The manual does not specify the function of other wire colors.
After installation, test the installation using a test light or trailer. This will verify that the tail light circuits are functioning correctly through the T-Connector before you reattach the rear quarter panel trim and spare tire.
After testing with a test light or trailer, secure the black box to the vehicle using the screw or cable tie provided. Then reattach the rear quarter panel trim and spare tire to their original positions.
Do not break the locking tabs on the harness connectors when separating them. Do not drill into the vehicle floor or bed when securing the ground wire. Do not exceed the 4 amp per circuit rating when connecting trailer loads.
The T-Connector works with vehicles that have tail light wiring harnesses with white rectangular connectors matching the T-Connector ends. Verify your vehicle's tail light connector type before purchasing.
Open the rear door and temporarily remove the spare tire and rear quarter panel trim on the driver's side.
Test the installation using a test light or trailer to verify that the tail light circuits are functioning correctly.
