These dependable custom hitches are manufactured for 2019-2020 Hyundai Santa Fe, 2016-2020 KIA Sorento and attach to your vehicle?s frame or bumper for a sleek, clean appearance. Each hitch also has a 1-1/4 inch square receiver tube opening so you can easily attach accessories like a bike rack or cargo carrier, or a utility trailer. DRAW-TITE Class 2 custom trailer hitches come complete with all the mounting hardware needed for installation and are backed by a nationwide lifetime limited warranty. So, whether you are headed out to the campground and need a place for the cooler, taking the bikes to hit the trails in the park, or you are tackling a DIY project (maybe some landscaping or a home repair), choose DRAW-TITE and travel with confidence knowing your setup is connected with the security only DRAW-TITE can provide. DRAW-TITE: North America?s Favorite Hitch.
Draw-Tite has designed custom-fit trailer hitches since 1946 and is one of North America's most widely fitted hitch brands. Receiver hitches use solid all-welded construction and low-profile designs that follow modern vehicle contours, install with minimal bumper cutting or drilling, meet or exceed V5 CSA and SAE J684 standards, and carry a limited lifetime warranty.
Draw-Tite has been leading custom-fit trailer hitch design and engineering since its founding in 1946, and it remains one of the most widely fitted hitch brands in North America. The company's stated approach is straightforward: every hitch is tested rigorously so that it performs well beyond published industry standards, a philosophy it markets as Tested Tough. It sits within the Horizon Global towing group alongside Reese, Fulton, Bulldog, Tekonsha, Bargman and Wesbar.
Custom fit is the defining characteristic. Rather than adapting a universal design, Draw-Tite engineers a trailer hitch for a specific make, model and model year, so it bolts to existing frame locations with minimal bumper cutting or drilling. Low-profile designs follow the rear contours and aerodynamic styling of modern vehicles, which matters more than it once did now that rear fascias are shaped and sensor-equipped. Construction is solid all-welded steel for maximum strength, and every hitch meets or exceeds V5 CSA and SAE J684 standards and is backed by a nationwide limited lifetime warranty.
The range spans receiver sizes and classes to suit different loads, from 1-1/4 inch receivers for bike racks, cargo carriers and light trailers up through 2 inch receivers for heavier towing. Front mount hitches add a receiver at the front of the vehicle for winch mounts, snow plows, spare carriers and precise trailer positioning.
The Hidden Hitch series takes concealment further by mounting behind the vehicle's rear fascia, so the vehicle keeps its factory appearance until a removable receiver is fitted. Each is custom designed per make and model for a no-drill installation that does not compromise ground clearance, rated for up to 3,500 pounds gross trailer weight and 350 pounds tongue weight. Matching plug-and-play wiring completes the towing system.
Experts available to answer your questions
Call 888-634-94941 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2001 - 2003 | Kia Sorento | w/I4 Engine |
Yes, the 2016-2020 KIA Sorento w/I4 Engine Draw-tite Class 2 Trailer Hitch, 1-1/4 Inch Square Receiver Bundle w/ Plug-n-Play T-One Wiring Harness (Part #DTB37132-118583) is designed to fit the 2001-2003 Kia Sorento.
The 2016-2020 KIA Sorento w/I4 Engine Draw-tite Class 2 Trailer Hitch, 1-1/4 Inch Square Receiver Bundle w/ Plug-n-Play T-One Wiring Harness (Part #DTB37132-118583) fits the following vehicles: 2001-2003 Kia Sorento. Always verify your specific year, make, and model before ordering.
The 2016-2020 KIA Sorento w/I4 Engine Draw-tite Class 2 Trailer Hitch, 1-1/4 Inch Square Receiver Bundle w/ Plug-n-Play T-One Wiring Harness (Part #DTB37132-118583) fits 2001-2003 Kia Sorento models. The 2003 model year is the last year covered by this part number. For newer models, check for an updated version.
The 2016-2020 KIA Sorento w/I4 Engine Draw-tite Class 2 Trailer Hitch, 1-1/4 Inch Square Receiver Bundle w/ Plug-n-Play T-One Wiring Harness (Part #DTB37132-118583) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
Yes, part number 37132 is designed for 2016-Current Kia Sorento models. Visit the Horizon Global website for the most up-to-date information regarding specific application years and trim levels.
No, part number 37132 is designed for 2016-Current Kia Sorento models only. Check the Horizon Global website for fitment information on earlier model years.
The 37132 is a weight-carrying hitch with a maximum gross trailer weight of 3500 lb (1587 kg) and a maximum tongue weight of 350 lb (158 kg). Do not exceed the lower of your towing vehicle manufacturer's rating or these limits.
No, the 37132 is a weight-carrying hitch only. Weight-distributing capability is listed as NA (not available) for this model.
Required tools include: ratchet, torque wrench, safety glasses, sockets (3/4", 14 mm, 16 mm, 17 mm, 18 mm, 19 mm), 6" socket extension, and Phillips screwdriver. Lubricant or soapy water is also recommended to help with exhaust hanger removal.
The fastener kit 37132F includes: (2) hex bolts ½-13 x 4.50 GR5, (5) conical washers ½", (2) hex nuts ½-13, (1) bolt M12x1.75x120 CL8.8, (1) flat washer ½" hardened, (1) hex nut M12x1.75 CL8, (4) bolts M10x1.25x30 CL10.9, and (4) conical washers 7/16".
Yes, the spare tire must be lowered and removed before installation. The tire release is located underneath the storage compartment in the back of the vehicle. The spare tire is reinstalled after the hitch installation is complete.
Yes, the exhaust must be lowered by removing the rear and side hangers before hitch installation. Support the exhaust to prevent damage. Spraying lubricant or soapy water on the metal hanger rod and rubber isolator helps with removal. The exhaust is raised back into position after the hitch is secured.
The driver side rear plastic cover, located underneath the vehicle, must be removed using a small Phillips head screwdriver. Also remove (5) plastic push pins and (2) nuts. This cover is reinstalled after the hitch installation is complete.
The bumper locator pin may interfere with the hitch hardware. If necessary, use an angle grinder to trim the locator pin at the shoulder to allow proper hardware clearance. This is a conditional modification required only if interference is present.
No drilling is required. The hitch uses existing weldnuts in the frame rail. The installation involves removing rubber plugs from the bottom of the frame rail and inserting bolts into existing weldnuts.
M10 CL10.9 fasteners must be tightened to 40 Lb.-Ft. (54 N·M) using a torque wrench.
Both ½ GR5 fasteners must be tightened to 75 Lb.-Ft. (102 N·M) using a torque wrench.
M12 GR8.8 fasteners must be tightened to 68 Lb.-Ft. (92 N·M) using a torque wrench.
1. Lower and remove spare tire. 2. Remove driver side rear plastic cover, push pins, and nuts. 3. Lower exhaust by removing hangers and support it. Remove rubber plugs from frame rail. 4. Run M10 bolts into existing weldnuts to remove debris, then remove bolts. 5. Raise hitch into position and insert items 1 & 2 (driver side) and items 4 & 5 (passenger side). 6. Insert M10 bolts (items 8 & 7) and hand tighten. 7. Install conical washers and hex nuts. 8. Torque all fasteners to specification. 9. Raise exhaust back into position. 10. Reinstall plastic cover. 11. Reinstall spare tire.
Yes, M10 bolts (items 8 & 7) should be hand-tightened first (Step 6), then conical washers and hex nuts are installed (Step 7), and finally all fasteners are torqued to specification using a torque wrench (Step 8).
Items 1 & 2 (hex bolts ½-13 x 4.50 GR5 and conical washers ½") are inserted on the driver's side during Step 5.
Items 4 & 5 (bolt M12x1.75x120 CL8.8 and flat washer ½" hardened) are inserted on the passenger's side during Step 5.
Conical washers should be installed with the teeth side against the hitch or frame. Sort hardware prior to installation to confirm conical washers are kept with coordinated bolts.
Always wear safety glasses during installation. Observe safety precautions when working beneath a vehicle. Do not cut access or attachment holes with a torch. Support the exhaust system to prevent damage during removal. Wear eye protection.
If the hitch is removed, plug all holes in the trunk pan or other body panels to prevent entry of water and exhaust fumes.
The maximum tongue weight is 350 lb (158 kg). Do not exceed the lower of your towing vehicle manufacturer's rating or this limit.
After installation, make sure the spare tire is seated properly. Check the hitch frequently to ensure all fasteners and ball are properly tightened. Periodically verify that all fasteners remain tight and the hitch is securely mounted to the vehicle.
Check the hitch frequently, making sure all fasteners and ball are properly tightened. Periodically verify that all fasteners remain tight and the hitch is securely mounted to the vehicle.
A hitch or ball which has been damaged should be removed and replaced. Do not continue to use a damaged hitch.
The authorized drawbar kit is 36071 (sold separately). The drawbar must be used in the RISE position only.
The average installation time for professional installers is 40 minutes. If you do not feel comfortable performing this installation on your own or are in need of assistance, please contact a professional installer.
Yes, part 37132 fits 2016-Current Kia Sorento. Check the Horizon Global website for specific trim level compatibility.
Maximum gross trailer weight is 3500 lb (1587 kg) and maximum tongue weight is 350 lb (158 kg). Do not exceed the lower of your vehicle manufacturer's rating or these limits.
You need a ratchet, torque wrench, safety glasses, sockets (3/4", 14 mm, 16 mm, 17 mm, 18 mm, 19 mm), 6" socket extension, and Phillips screwdriver. Lubricant or soapy water is recommended.
Yes, both must be removed. The spare tire is lowered and removed first, and the exhaust is lowered by removing rear and side hangers. Both are reinstalled after the hitch is secured.
M10 CL10.9: 40 Lb.-Ft. (54 N·M); ½ GR5: 75 Lb.-Ft. (102 N·M); M12 GR8.8: 68 Lb.-Ft. (92 N·M). Use a torque wrench for all fasteners.
Use an angle grinder to trim the locator pin at the shoulder to allow proper hardware clearance. This will resolve the interference and allow the hitch to be properly positioned.
The T-Connector is a trailer wiring harness system for Kia Sorento vehicles. It provides a connection point between your vehicle's electrical system and a trailer, allowing you to control trailer lights (brake, turn, and running lights) from your vehicle's electrical system.
Yes, the T-Connector 118583-037 is designed for the Kia Sorento. The manual does not specify model years or trim variations, so contact the manufacturer or your installer to confirm your specific vehicle year and configuration are compatible.
You will need: trim panel remover, 10mm socket & ratchet or 10mm wrench, drill with 3/32" bit, 1/4" socket, wire crimpers, wire cutters, Phillips head screwdriver, and a test probe.
Yes. You must disconnect the vehicle's negative (-) battery cable before beginning installation. The manual specifies this in step 9, and you will reconnect it after the fuse holder is properly installed in step 10.
Open the rear tailgate. Using a Phillips head screwdriver, remove the screws holding the taillights on both the driver and passenger side. Carefully pull the taillight away from the vehicle, being careful not to damage the alignment pins.
The T-Connector has two ends: one with a yellow wire for the driver's side and one with a green wire for the passenger side. The yellow wire end is inserted between the vehicle wiring connectors on the driver's side taillight. The manual does not specify the individual function of each wire color.
Beginning at the driver's side taillight pocket, route the 4-flat harness and the harness containing the green and red wires down on the interior side of the bumper brace. Then route the harness and 4-flat across and underneath the vehicle behind the bumper fascia. Route the 4-flat to the center of the vehicle and secure with the provided cable ties. Continue routing the harness containing the green wire up through the opening behind the passenger's side taillight.
Route the wires carefully to avoid hot pipes, heat shields, the fuel tank, or any other points that may pinch or break the wire. Also avoid areas that would pinch, cut, or melt the wire when securing with cable ties. The manual warns that improper routing can cause damage to the vehicle and personal injury.
Mount the T-Connector black box using the double-sided tape provided onto the bottom of the bumper support channel.
Yes. You must drill a 3/32" hole on the driver's side near the connectors to secure the white grounding wire with an eyelet using the provided screw. Before drilling, verify what is behind the surface to avoid damage to the vehicle or personal injury. Do not drill into any exposed surfaces.
Drill a 3/32" hole on the driver's side near the connectors. Verify what is behind the surface before drilling and do not drill into any exposed surfaces.
On the driver's side, locate the black 12 gauge power wire from the T-Connector box. Attach the black 12 gauge wire provided. Route the remaining wire through the opening in the taillight socket, behind the bumper. Route the black wire along the exterior frame or follow the existing wiring along the thresholds into the engine compartment up to the battery, avoiding areas that may pinch or break the wire.
The T-Connector uses a 15 amp fuse. The fuse is installed in the yellow fuse holder provided and connects between the black 12 gauge power wire and the vehicle's positive (+) battery cable.
Disconnect the vehicle's negative (-) battery cable. Remove the fuse from the yellow fuse holder if present. Cut the fuse holder wire, attach the ring terminal, and secure it to the vehicle's positive (+) battery cable. Connect the other end of the fuse holder to the black 12 gauge wire using the yellow butt connector provided. Reconnect the negative battery cable and install the 15 amp fuse.
The T-Connector uses the following wire colors: yellow wire (driver's side connector end), green wire (passenger's side connector end), red wire (in the harness with the green wire), black 12 gauge wire (power wire from the T-Connector box), and white wire (grounding wire). The manual does not specify the individual function of each wire color.
After all connections are complete, secure the remainder of the T-Connector harness with the cable ties provided to prevent damage or rattling, being careful to avoid any areas that would pinch, cut, or melt the wire. Then reinstall the taillight assemblies and other items removed during installation, being careful not to pinch or cut the wires.
All connections must be complete for the T-Connector to function properly. Test and verify the installation with a test light or trailer once installed. For the initial test, reset the vehicle electrical system by temporarily removing the key from the ignition.
Do not exceed the lower of the towing manufacturer's rating (including in your vehicle owner's manual) or the specific amperage ratings stated on the product. The T-Connector uses a 15 amp fuse. Overloading circuits can cause fires.
Always wear safety glasses and use all safety precautions during installation. Read and follow all warnings and instructions included with the product and printed on the tow vehicle's battery. Verify what is behind any surface before drilling. Do not drill into exposed surfaces. Route wires carefully to avoid hot pipes, heat shields, fuel tank, or pinch points.
Before inserting the T-Connector ends, disconnect the vehicle wiring harness from the taillight socket. Separate the connector carefully, being careful not to break the locking tabs. All connector surfaces should be clean and free of dirt. When inserting the T-Connector end, be careful not to damage the locking tabs and ensure that connectors are fully inserted with locking tabs in place.
