2016-2022 Honda HR-V All Class 1 Trailer Hitch, 1-1/4" Ball MountCURTOriginal price was $389.85. Current price is $292.92.In Stock
View productAsk a Question About This Product
Our in-house experts typically reply within one business day.
Our in-house experts typically reply within one business day.
CURT
Verify Fitment
Select your vehicle to confirm this part fits.
2016 - 2022 Honda HR-V
Confirmed to Fit
Always the correct part
We know our products
Quality Products
Free Shipping!
Always the correct part
We know our products
Quality Products
Free Shipping!
Select your vehicle to find the exact plug-and-play parts that fit — no cutting or splicing.
This fits: 2016-2022 Honda HR-V All
However you define adventure -- whether it's climbing onto the back of a mountain bike, hunting from the top of a tree stand or camping with the family a long way from nowhere -- CURT class 1 hitches provide a light-duty towing receiver to help you Bring It. Each is made to fit a specific vehicle, providing easier installation, a better fit and optimal towing capacity. Custom class 1 trailer hitches are available for a variety of smaller vehicle types, including the compact car, crossover, minivan and small SUV. This particular class 1 hitch is designed to be a custom hitch for certain years of the Honda HR-V (to verify vehicle compatibility, see the CURT application guide at curtmfg.com). Tested in accordance with SAE J684, it offers a weight carrying capacity of 2,000 lbs. GTW and 200 lbs. TW. It is equipped with 1-1/4" receiver tube opening to accept a ball mount shank or other hitch mount. This class 1 hitch also comes with all necessary mounting hardware. With its lightweight design and smaller receiver tube size, a class 1 hitch is especially useful for adding cargo space with a hitch-mounted bike rack or cargo carrier. They can also typically be used to tow small trailers such as a utility trailer, kayak trailer or teardrop camper (never exceed the lowest weight capacity of any towing component; i.e. the vehicle, hitch, trailer, etc). Though CURT class 1 trailer hitches are only intended for light-duty towing, we apply the same principles of quality as we do to the rest of our rear mount hitches. Each class 1 hitch is made with hands-on engineering, high-strength steel and precise welding. We use a co-cured finish of liquid A-coat, inside and out, and durable black powder coat to provide a lasting defense against rust, chips and UV rays.
Trailer hitch weight ratings are limited to vehicle manufacturer's stated capacities
Not compatible for use with vertical hanging bicycles (bike racks that require the bicycles to be hung / mounted vertically)
Includes installation hardware
2016, 2017, 2018, 2019, 2020, 2021, 2022 Honda HR-V All Class 1 Trailer Hitch, 1-1/4" Receiver, Select Honda HR-V
CURT offers a variety of high-quality trailer hitches and accessories for select vehicle models. Find the perfect fit for your towing needs at TowUniverse.
CURT, a Lippert brand, offers a complete line of towing products and is the leading manufacturer of custom-fit trailer hitches. We offer the broadest selection of custom-fit hitches, and each one is designed, welded, and coated in Wisconsin.
CURT is also a leader in flat towing products, as well as 5th wheel, gooseneck, and weight distribution hitches, ball mounts, electrical components, cargo solutions, and other towing accessories.
For everything from passenger cars and vans to full-size pickups and SUVs, CURT is 'The First Name in Towing Products®.'
Experts available to answer your questions
Call 888-634-94941 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2016 - 2022 | Honda HR-V | — |
Yes, the 2016-2022 Honda HR-V All Class 1 Trailer Hitch, 1-1/4" Receiver + 2" Ball + 1-7/8" Ball Kit (Part #CHD-11416-001) is designed to fit the 2016-2022 Honda HR-V.
The 2016-2022 Honda HR-V All Class 1 Trailer Hitch, 1-1/4" Receiver + 2" Ball + 1-7/8" Ball Kit (Part #CHD-11416-001) fits the following vehicles: 2016-2022 Honda HR-V. Always verify your specific year, make, and model before ordering.
The 2016-2022 Honda HR-V All Class 1 Trailer Hitch, 1-1/4" Receiver + 2" Ball + 1-7/8" Ball Kit (Part #CHD-11416-001) fits 2016-2022 Honda HR-V models. The 2022 model year is the last year covered by this part number. For newer models, check for an updated version.
The 2016-2022 Honda HR-V All Class 1 Trailer Hitch, 1-1/4" Receiver + 2" Ball + 1-7/8" Ball Kit (Part #CHD-11416-001) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
Yes, the CURT 11416 is designed for 2015-Present Honda HR-V Crossover models. It is a weight-carrying hitch with a maximum trailer weight capacity of 2,000 lbs and tongue weight capacity of 200 lbs. Always verify your vehicle's manufacturer-recommended towing capacity before towing, as you must never exceed it.
The CURT 11416 has a maximum trailer weight capacity of 2,000 lbs and a tongue weight capacity of 200 lbs when used as a weight-carrying hitch. However, you must never exceed your vehicle manufacturer's recommended towing capacity, which may be lower.
You will need: a ratchet, a torque wrench, an 11/16" socket, safety glasses, and aviation shears. The aviation shears are needed to trim the underbody panel on front-wheel-drive models.
No, drilling is not required. The hitch uses existing holes in the frame for installation. The installation uses fishwire hardware technique to secure carriage bolts through existing fore holes in the frame rails.
Two people may be required to ease installation. While one person may be able to complete the installation, having a second person will help with positioning and securing the hitch.
On front-wheel-drive models only, the lower underbody panel may need to be trimmed to install the hitch. The manual includes an underbody trim diagram showing the trim area. Rear-wheel-drive models do not require this modification.
Yes, on front-wheel-drive models, the exhaust heat shield will need to be bent approximately 3/4" to allow the hitch to rest flat against the frame. The manual shows this as a fold-up modification. If needed, fold the heat shield up so the hitch can rest flat on the frame rail.
The first step is to lower the exhaust by removing the two rear-most rubber isolators from the muffler. This provides clearance for the hitch installation and allows you to raise the exhaust back into position after the hitch is secured.
Fishwire is used to thread carriage bolts and spacers through existing holes in the frame rails without removing the frame. On the driver side, fishwire a 7/16-14 x 1 1/4" carriage bolt and CM-SP2 spacer through an existing fore hole. On the passenger side, fishwire a 7/16-14 x 1" carriage bolt and CM-SP2 spacer through an existing fore hole. Leave fishwires attached to prevent loss of hardware inside the frame rail.
The longer carriage bolt (7/16-14 x 1 1/4") must be installed on the driver side. The shorter carriage bolt (7/16-14 x 1") goes on the passenger side. Both bolts are secured with CM-SP2 spacers.
Insert the 7/16" U-bolt (part 10-10444) through the tow loop. Raise the hitch into position and loosely secure it to the U-bolt and frame rails using 7/16" flange nuts (part 20-00103). Do not fully tighten until all fasteners are in place.
All 7/16" carriage bolts must be torqued to 59 ft-lbs. This applies to both the driver-side 1 1/4" bolt and the passenger-side 1" bolt.
The 7/16" U-bolt must be torqued to 25 ft-lbs.
After torquing all 7/16" carriage bolts to 59 ft-lbs and the 7/16" U-bolt to 25 ft-lbs, raise and secure the exhaust back into position by reinstalling the rubber isolators on the muffler.
Periodically check the receiver hitch to ensure all fasteners are tight and all structural components are sound. This ongoing maintenance is important for safe towing and to maintain the product warranty.
Safety glasses must be worn at all times while installing this product.
All non-trailer (wheel-less) loads applied to this hitch must be supported by 18050 stabilizing straps. Failure to properly support non-trailer loads will void the product warranty. See the CURT catalog or visit www.curtmfg.com for further information on stabilizing straps.
The CURT 11416 is designed for use with ball mount 45521. Euro mount options are also available: 45571 (1 7/8" ball) and 45572 (2" ball).
The hitch includes: 1 U-bolt 7/16-14 UNC (part 10-10444), 2 square hole spacers 0.250 x 0.88 x 2.25" (part CM-SP2), 1 carriage bolt 7/16-14 UNC 1-1/4" (part 10-10281), 2 pieces of 7/16" fishwire (part 7_16 FISHWIRE), 4 serrated flange nuts 7/16-14 UNC (part 20-00103), and 1 carriage bolt 7/16-14 UNC 1" (part 10-10311).
Yes, it fits 2015-Present Honda HR-V Crossover models. Maximum capacity: 2,000 lbs trailer weight, 200 lbs tongue weight. Never exceed your vehicle manufacturer's recommended towing capacity.
No drilling required. The hitch uses existing frame holes and fishwire hardware technique for installation.
On FWD models only: trim the lower underbody panel and bend the exhaust heat shield approximately 3/4". The exhaust must be lowered by removing two rubber isolators, then raised back after installation.
Ratchet, torque wrench, 11/16" socket, safety glasses, and aviation shears (for FWD underbody panel trimming).
Carriage bolts: 59 ft-lbs. U-bolt: 25 ft-lbs. Use a torque wrench to ensure proper tightness.
2,000 lbs trailer weight, 200 lbs tongue weight. Never exceed your vehicle manufacturer's recommended towing capacity, which may be lower.
All non-trailer loads must be supported by 18050 stabilizing straps. Failure to do so voids the warranty.
Periodically check that all fasteners are tight and structural components are sound. Retorque fasteners if needed to maintain safe operation.
