Custom-Designed Fit: Each Blue Ox BX1747 base plate is specifically designed for each towed vehicle, ensuring a perfect fit and easy installation.
Material: Steel
Finish: Powder Coat
Color: Black
Mounting Type: Bolt On
Mounting Hardware Included Yes/No: Yes
The Blue Ox BX1747 Tow Bar Bracket is the perfect solution for your towing needs. This custom-designed, bolt-on base plate is crafted from high-quality steel, offering superior durability and resistance to wear and tear. Its sleek black powder coat finish not only adds to its aesthetic appeal but also provides an extra layer of protection against rust and corrosion. The base plate comes with all necessary mounting hardware and a comprehensive set of instructions, making it easy for you to install it on your own. With this Blue Ox base plate, you can ensure a secure and stress-free towing experience.
Blue Ox is known internationally for recreational and commercial towing products, manufacturing in Pender, Nebraska since 1925. The line covers tow bars and vehicle-specific baseplates for flat towing behind a motorhome, sway control and weight distributing hitches, supplemental braking accessories and towing wiring, backed by patented designs and long-standing customer service.
Blue Ox has manufactured since 1925 and is recognised internationally for towing products and customer service. The company operates from Pender, Nebraska, where it grew out of Automatic Manufacturing Co., a business that started with cattle oilers and developed into agricultural equipment, tractor accessories and trailer towing hardware. That agricultural engineering heritage still shows in how the towing products are built, and the company holds patents across weight distribution, fifth wheel and tow bar designs.
Flat towing is the discipline Blue Ox is best known for. Towing a car with all four wheels on the ground behind a motorhome demands a system that stays rigid under braking, articulates properly over uneven ground, and connects to the towed vehicle at points strong enough to take the load. Blue Ox tow bars handle the first two, with self-aligning arms that latch under tension and release without a struggle when the load is off them. Vehicle-specific baseplates handle the third, engineered per make and model to tie into structural mounting points behind the fascia.
The wider flat towing range covers supplemental braking systems, safety cables and the accessories that make a complete legal setup, along with baseplate wiring and dinghy towing harnesses that pass lighting signals to the towed vehicle without back-feeding its electrical system.
For conventional trailer towing, Blue Ox weight distributing hitches with integrated sway control transfer tongue load onto the tow vehicle's front axle and resist the yaw that crosswinds and passing trucks induce.
The company describes its foundation as customer service, designing around what owners actually ask for, and it runs an RV park adjacent to the factory where customers can stay. Sister operations at the same Nebraska site include Automatic grain roller mills and MAD-RAMPS pivoting ramp systems.
Experts available to answer your questions
Call 888-634-94943 Years
6 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2019 - 2021 | Chevrolet Silverado 1500 | All Models/Trims Comes with Removable Attachment Tabs Install Rating 3 Bumper Fascia Must Be Removed/Replaced During Install Requires Some Trimming of Bumper/Fascia/Plastic/And/Or Grill Minor Drilling Required Baseplate Has Non 24 in. Spaced Attachment Tabs Requires Motorhome Mounted Tow Bar/Adapter To Utilize Car Mounted Tow Bar Tow Bar Adapters Not To Be Used On Vehicles Over 5000 lbs. |
| 2022 | Chevrolet Silverado 1500 LTD | Limited All Models/Trims Comes with Removable Attachment Tabs Install Rating 3 Bumper Fascia Must Be Removed/Replaced During Install Requires Some Trimming of Bumper/Fascia/Plastic/And/Or Grill Minor Drilling Required Baseplate Has Non 24 in. Spaced Attachment Tabs Requires Motorhome Mounted Tow Bar/Adapter To Utilize Car Mounted Tow Bar Tow Bar Adapters Not To Be Used On Vehicles Over 5000 lbs. |
| 2021 - 2024 | Chevrolet Suburban | Vehicles With Adaptive Cruise Control & Shutters Comes with Removable Attachment Tabs Install Rating 3 Bumper Fascia Must Be Removed/Replaced During Install Requires Some Trimming of Bumper/Fascia/Plastic/And/Or Grill Baseplate Has Non 24 in. Spaced Attachment Tabs Requires Motorhome Mounted Tow Bar/Adapter To Utilize Car Mounted Tow Bar Tow Bar Adapters Not To Be Used On Vehicles Over 5000 lbs. |
| 2021 - 2024 | Chevrolet Tahoe | Vehicles With Adaptive Cruise Control & Shutters Comes with Removable Attachment Tabs Install Rating 3 Bumper Fascia Must Be Removed/Replaced During Install Requires Some Trimming of Bumper/Fascia/Plastic/And/Or Grill Baseplate Has Non 24 in. Spaced Attachment Tabs Requires Motorhome Mounted Tow Bar/Adapter To Utilize Car Mounted Tow Bar Tow Bar Adapters Not To Be Used On Vehicles Over 5000 lbs. |
| 2021 - 2024 | GMC Yukon | Only Vehicle Equipped with 4L Vehicles With Adaptive Cruise Control and Shutters Comes with Removable Attachment Tabs Install Rating 3 Bumper Fascia Must Be Removed/Replaced During Install Requires Some Trimming of Bumper/Fascia/Plastic/And/Or Grill Baseplate Has Non 24 in. Spaced Attachment Tabs Requires Motorhome Mounted Tow Bar/Adapter To Utilize Car Mounted Tow Bar Tow Bar Adapters Not To Be Used On Vehicles Over 5000 lbs. |
| 2021 - 2024 | GMC Yukon XL | Only Vehicle Equipped with 4L Vehicles With Adaptive Cruise Control and Shutters Comes with Removable Attachment Tabs Install Rating 3 Bumper Fascia Must Be Removed/Replaced During Install Requires Some Trimming of Bumper/Fascia/Plastic/And/Or Grill Baseplate Has Non 24 in. Spaced Attachment Tabs Requires Motorhome Mounted Tow Bar/Adapter To Utilize Car Mounted Tow Bar Tow Bar Adapters Not To Be Used On Vehicles Over 5000 lbs. |
The BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select, GMC YUKON XL AT4 (Part #FDRWBX1747) fits 2019-2021 Chevrolet Silverado 1500 models. The 2024 model year is the last year covered by this part number. For newer models, check for an updated version.
Yes, the BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select, GMC YUKON XL AT4 (Part #FDRWBX1747) is designed to fit the 2019-2021 Chevrolet Silverado 1500.
The BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select, GMC YUKON XL AT4 (Part #FDRWBX1747) fits the following vehicles: 2019-2021 Chevrolet Silverado 1500; 2022 Chevrolet Silverado 1500 LTD; 2021-2024 Chevrolet Suburban; 2021-2024 Chevrolet Tahoe; 2021-2024 GMC Yukon; 2021-2024 GMC Yukon XL. Always verify your specific year, make, and model before ordering.
The BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select, GMC YUKON XL AT4 (Part #FDRWBX1747) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
Yes, the BX1747 fits 2021-2024 GMC Yukon and Yukon XL AT4 models equipped with a 4L engine and adaptive cruise control with shutters. If your vehicle does not have these features or is a different model year or engine size, contact Blue Ox at (402) 385-3051 to confirm compatibility.
The BX1747 fits 2019-2021 Chevy Silverado 1500 New Style (all models) and 2022 Chevy Silverado 1500 Limited (all models). If your 2022 is not a Limited trim, or if it is a different model year, contact Blue Ox at (402) 385-3051 to confirm fitment.
Yes, the BX1747 fits 2021-2024 Chevy Tahoe Z71 models equipped with adaptive cruise control and shutters. Confirm your vehicle has these features before purchasing.
The BX1747 attachment tab height is 19.5" and the tab width is 30". Your tow bar must be compatible with the 30" tab width.
Required tools include: flat screwdriver, torque wrench, drill with 1/2" and 7MM drill bits, Loctite Red, and sockets in 7MM, 10MM, 18MM, 7/16", 3/4"; wrenches in 18MM, 7/16", and 3/4"; and a T15 Torx driver. A reciprocating saw may be needed for trimming.
The kit includes: 10 whiz nuts with 10" wire (61-4029), 2 baseplates (DS and PS, 61-8470 and 61-8471), 2 attachment tab assemblies (62-3468), 1 electrical bracket (101-6135), 10 hex head bolts 1/2"-13 x 1-1/2" Grade 5 (201-0051), 5 hex head bolts 1/4"-20 x 1" Grade 5 (201-0071), 2 round slotted head screws #10-32 1/2" (201-0192), 2 hex head bolts 1/2"-13 x 5" Grade 5 (201-0786), 2 hex nuts #10-32 (202-0047), 2 hex nylon insert lock nuts 1/2"-13 (202-0094), 5 hex nylon nuts 1/4"-20 (202-0102), 5 flat washers 1/4" (203-0001), 20 flat washers 1/2" (203-0005), 10 lock washers 1/2" (203-0012), 2 lock washers #10 (203-0054), 2 Class IV safety cables (226-0049), 2 quicklinks 1/2" (229-0512), and 2 black cap plug receivers (290-0437).
Yes. The BX8869 Tail Light Wiring Kit is recommended for vehicles without LED lights, and the BX8848 Tail Light Wiring Kit is recommended for vehicles with LED lights. These are not included in the baseplate kit.
Yes. The fascia and windshield washer fluid reservoir must be removed during installation and reinstalled after the baseplate is installed. Removal procedures differ by vehicle model: Chevy Silverado 1500 requires removal of handle bolts, push pins, grill bolts, and bumper components. GMC Yukon/Yukon XL AT4 and Chevy Suburban/Tahoe Z71 require removal of hood release handle bolts, fascia cover push pins, and fascia bolts from multiple locations.
Yes. The factory tow hooks must be removed and will not be reinstalled. For Chevy Silverado 1500, remove the two 18MM bolts from each tow hook. For GMC Yukon/Yukon XL AT4 and Chevy Suburban/Tahoe Z71, remove the two 18MM bolts from each tow hook.
The manual does not specify whether battery disconnection is required. Contact Blue Ox at (402) 385-3051 or consult your vehicle owner's manual before beginning installation.
Yes. Drilling is required. You must drill the top rear hole on the side of the baseplate and the bottom hole using a 1/2" drill bit and the baseplate as a template. This is done on both sides of the vehicle. Additionally, a hole must be drilled according to the tail light wiring kit instructions.
Yes. The fascia must be trimmed around the convenience links and attachment tabs to fit properly after baseplate installation. The manual states to hold the fascia as close to its original position, mark and trim the fascia around these components.
Yes. The manual states: "Use a good quality paint to spray cut edges of frame to prevent rusting." This is a required maintenance step to prevent corrosion.
1/2"-13 Grade 5 bolts should be torqued to 78 foot-pounds. All bolts must have Loctite Red applied to the threads before tightening.
1/4"-20 Grade 5 bolts should be torqued to 10 foot-pounds. All bolts must have Loctite Red applied to the threads before tightening.
10MM Grade 8.8 metric bolts should be torqued to 31 foot-pounds. All bolts must have Loctite Red applied to the threads before tightening.
For Chevy Silverado 1500: unplug the camera in the center of the grill (white connector) and the main wiring harness on the passenger side. For GMC Yukon/Yukon XL AT4 and Chevy Suburban/Tahoe Z71: unplug the electrical connections behind the wheel well liner on the passenger side. All connections must be reconnected before reinstalling the fascia.
The baseplate is computer tested to your vehicle's GVWR. Exceeding this weight will void the manufacturer's warranty. Refer to your vehicle owner's manual for your specific GVWR.
Yes. Two Class IV safety cables are included with the baseplate and must be installed. The cables attach from the baseplate to the frame rail or cross member of the vehicle's frame using the provided quicklinks. The cables must not rub against hoses or moving parts. These permanent baseplate safety cables are in addition to, not a replacement for, legally required safety cables attaching the towed vehicle to the towing vehicle.
If the baseplate is in an accident, it must be replaced. Do not use it again. An accident can cause unseen damage and using it again could result in more damage or serious injury. Do not use the baseplate if it is damaged or missing parts.
Before reinstalling the fascia, ensure all electrical connections are plugged in and accessories are functioning properly. After installation, verify that all bolts are tightened to the correct torque specifications with Loctite Red applied. Check that safety cables do not rub against hoses or moving parts. Before each towing trip, inspect all towing equipment for cracked welds, missing or worn parts, and loose bolts.
It is the owner's responsibility to inspect all towing equipment for cracked welds, missing or worn parts, and loose bolts before each towing trip. Use Loctite Red on all bolts and tighten to the recommended torque specifications. Ensure safety cables remain installed as long as the baseplate is installed and do not rub against wires, hoses, or brake lines. Remove the attachment tabs when not in use.
Yes. Blue Ox towing products are intended to be installed by Blue Ox dealers who are familiar with the products and have the equipment and knowledge necessary to do "fit work." Blue Ox dealers can be found at www.blueox.com or by contacting the Technical Service Department at (402) 385-3051.
Blue Ox offers a three-year limited warranty from the date of delivery to the original retail purchaser. The warranty covers defects in material and workmanship under normal use and service. The warranty card must be returned within 30 days of purchase, and a copy of the original invoice must accompany any warranty claim. The warranty does not cover improper installation, improper use, modification, neglect, failure to maintain, misuse, accident, normal wear and tear, paint, or rust. The warranty is non-transferable. Register your product at www.blueox.com/warranty/ to activate coverage.
BX1747 fits 2021-2024 GMC Yukon/Yukon XL AT4 (4L only with ACC & Shutters), 2021-2024 Chevy Suburban/Tahoe Z71 (with ACC & Shutters), 2019-2021 Chevy Silverado 1500 New Style, and 2022 Chevy Silverado 1500 Limited. Confirm your exact model year, trim, engine size, and features before purchasing.
You must purchase a tail light wiring kit separately: BX8869 for non-LED vehicles or BX8848 for LED vehicles. You will also need Loctite Red (not included) for all bolt threads.
Yes. You must drill the top rear and bottom holes on each side of the baseplate using a 1/2" drill bit. You must also drill a hole for the tail light wiring kit. Fascia trimming around the convenience links and attachment tabs is also required.
Use the torque chart on page 2: 1/2"-13 Grade 5 bolts = 78 ft-lbs, 1/4"-20 Grade 5 bolts = 10 ft-lbs, 10MM Grade 8.8 bolts = 31 ft-lbs. Apply Loctite Red to all bolt threads before tightening. Refer to the full torque table for other bolt sizes.
Yes. Two Class IV safety cables with quicklinks are included and must be installed from the baseplate to the vehicle frame. They are required in addition to legally required safety cables between the towing and towed vehicles.
Yes. Factory tow hooks must be removed and will not be reinstalled. They are removed during the fascia removal process before baseplate installation.
The attachment tab width is 30". Your tow bar must be compatible with this width. The tab height is 19.5".
Verify all electrical connections are plugged in and functioning. Ensure all bolts are tightened to correct torque with Loctite Red applied. Check that safety cables do not rub against hoses or moving parts. Before each towing trip, inspect for cracked welds, missing parts, worn parts, and loose bolts.
The back lower bolt may need to be switched to the other slotted hole to allow proper alignment. After making this adjustment, reinstall the back lower bolt with Loctite Red and tighten to the correct torque specification.
Reposition the safety cables so they do not rub against any hoses or moving parts. The cables must be secured to a solid piece of the frame. Refer to the Permanent Baseplate Safety Cable Installation section for recommended mounting options, or contact Blue Ox at (402) 385-3051 for assistance.
