{'1': 'Custom Designed: Each tow bar bracket is uniquely tailored to fit specific towed vehicles, ensuring a snug and secure fit.
Material: Steel
Color: Black
Finish: Powder Coat
Mounting Type: Bolt On
Mounting Hardware Included Yes/No: Yes
The Blue Ox BX2729 Tow Bar Bracket, a robust and reliable solution for your towing needs, is a product designed for long-lasting performance. Custom-built for each specific towed vehicle, it ensures seamless compatibility and a perfect fit. This tow bar bracket, made from high-grade steel and finished with a black powder coat, offers exceptional strength and durability, resisting corrosion and ensuring it can withstand the rigors of heavy-duty use. The bolt-on mounting type simplifies installation, and with all necessary hardware included, it allows for a convenient do-it-yourself setup. This product comes with comprehensive instructions to guide you through the installation process.
Blue Ox is known internationally for recreational and commercial towing products, manufacturing in Pender, Nebraska since 1925. The line covers tow bars and vehicle-specific baseplates for flat towing behind a motorhome, sway control and weight distributing hitches, supplemental braking accessories and towing wiring, backed by patented designs and long-standing customer service.
Blue Ox has manufactured since 1925 and is recognised internationally for towing products and customer service. The company operates from Pender, Nebraska, where it grew out of Automatic Manufacturing Co., a business that started with cattle oilers and developed into agricultural equipment, tractor accessories and trailer towing hardware. That agricultural engineering heritage still shows in how the towing products are built, and the company holds patents across weight distribution, fifth wheel and tow bar designs.
Flat towing is the discipline Blue Ox is best known for. Towing a car with all four wheels on the ground behind a motorhome demands a system that stays rigid under braking, articulates properly over uneven ground, and connects to the towed vehicle at points strong enough to take the load. Blue Ox tow bars handle the first two, with self-aligning arms that latch under tension and release without a struggle when the load is off them. Vehicle-specific baseplates handle the third, engineered per make and model to tie into structural mounting points behind the fascia.
The wider flat towing range covers supplemental braking systems, safety cables and the accessories that make a complete legal setup, along with baseplate wiring and dinghy towing harnesses that pass lighting signals to the towed vehicle without back-feeding its electrical system.
For conventional trailer towing, Blue Ox weight distributing hitches with integrated sway control transfer tongue load onto the tow vehicle's front axle and resist the yaw that crosswinds and passing trucks induce.
The company describes its foundation as customer service, designing around what owners actually ask for, and it runs an RV park adjacent to the factory where customers can stay. Sister operations at the same Nebraska site include Automatic grain roller mills and MAD-RAMPS pivoting ramp systems.
Experts available to answer your questions
Call 888-634-94943 Years
1 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2020 - 2022 | Kia Soul | With Dual Clutch Transmission No Fog Lights Vehicles With Adaptive Cruise Control & Turbo Comes with Removable Attachment Tabs Install Rating 3 Bumper Fascia Must Be Removed/Replaced During Install Requires Some Trimming of Bumper Fascia/Plastic/And/Or Grill Minor Drilling Required Requires Some Trimming of the Air Dam Baseplate Has Non 24 in. Spaced Attachment Tabs Requires Motorhome Mounted Tow Bar/Adapter To Utilize Car Mounted Tow Bar Tow Bar Adapters Not To Be Used On Vehicles Over 5000 lbs. |
The BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select, KIA SOUL GT W/DCT (Part #FDRWBX2729) fits 2020-2022 Kia Soul models. The 2022 model year is the last year covered by this part number. For newer models, check for an updated version.
The BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select, KIA SOUL GT W/DCT (Part #FDRWBX2729) fits the following vehicles: 2020-2022 Kia Soul. Always verify your specific year, make, and model before ordering.
Yes, the BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select, KIA SOUL GT W/DCT (Part #FDRWBX2729) is designed to fit the 2020-2022 Kia Soul.
The BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select, KIA SOUL GT W/DCT (Part #FDRWBX2729) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
The BX2729 baseplate is designed for 2020-2022 Kia Soul models with DCT transmission only, no fog lights in the grill, and with Adaptive Cruise Control and Turbo. If your vehicle does not match all these specifications, contact Blue Ox at (402) 385-3051 to confirm fitment. The manual notes that dimensional variations between otherwise identical vehicles can be considerable, so fit work may be necessary to tailor the baseplate to your specific vehicle.
No. The BX2729 is designed for Kia Soul models with no fog lights in the grill only. If your vehicle has fog lights in the grill, this baseplate is not compatible. Contact Blue Ox at (402) 385-3051 to find the correct baseplate for your vehicle.
No. The BX2729 is designed for DCT (dual-clutch transmission) models only. If your Kia Soul has a manual transmission, this baseplate is not compatible. Contact Blue Ox at (402) 385-3051 for the correct baseplate for your vehicle.
The attachment tab height is 14.5 inches and the width is 20 inches.
Required tools include: torque wrench, flat screwdriver, reciprocating saw, 10MM socket, 12MM socket, 13MM socket, 7/16" socket, 7/16" wrench, 3/4" socket, 3/4" wrench, and 5/16" nut drivers. You will also need Loctite Red for all bolt threads.
The kit includes: 2 attachment tab assemblies with holes, 1 electrical bracket with breakaway switch mount, 2 hex head bolts (1/2"-13 x 1-1/4"), 4 hex head bolts (1/4"-20 x 3/4"), 2 round slotted head screws (#10-32 1/2"), 8 hex bolts (8MM-1.25 x 30MM), 2 hex washer type F TCS bolts (1/4"-20 x 1/2"), 4 hex head bolts (1/2"-13 x 4"), 2 self-drilling screws (#12-14 x 1"), 2 hex nuts (#10-32), 4 hex nylon insert lock nuts (1/2"-13), 4 hex nylon nuts (1/4"-20), 8 flat washers (5/16"), 2 flat washers (7/16"), 8 flat washers (1/2"), 2 lock washers (1/2"), 2 lock washers (#10), 8 lock washers (8MM), 2 class III safety cables, 2 quicklinks (3/8"), 2 nylon cable ties (8"), and 2 black cap plug receivers.
The BX8848 Tail Light Wiring Kit is recommended for this vehicle, but the manual does not explicitly state whether it is required. Contact Blue Ox at (402) 385-3051 to confirm whether this kit is necessary for your installation.
Yes. The bumper must be removed during installation. Using a 12MM socket, remove the four bolts from the bumper, then using a 10MM socket, remove one bolt (located above the bumper on the driver side and below the bumper on the passenger side). The bumper is then set aside and will not be reinstalled.
Yes. Both the fascia and belly pan must be removed during installation and then reinstalled after the baseplate is installed. The fascia is removed by first popping out a plastic piece in the middle, removing push pins from the underside and wheel wells, and lifting and pulling to release clips. The belly pan is removed by taking out bolts, a plastic bolt, and push pins. Both components are set aside on a flat, sturdy surface and reinstalled after baseplate installation is complete.
No. The ACC bracket must be removed by taking out three bolts and letting it hang, but the manual explicitly states "DO NOT unplug ACC." The ACC is later reattached to the bracket on the baseplate using three 1/4" x 3/4" bolts with nylon lock nuts.
The manual does not explicitly state that drilling is required. However, it does note that "some drilling and trimming is required" in the Instruction Notes section. The manual specifies that a reciprocating saw is used to trim the plastic shroud on each side so the bottom is flush and the sides are removed. For specific drilling requirements, contact Blue Ox at (402) 385-3051.
The plastic shroud on each side of the vehicle must be trimmed using a reciprocating saw. The shroud should be trimmed so that the bottom is flush and the sides are removed as shown in the before/after diagram in Step 9. Additionally, the fascia must be trimmed around the convenience links and attachment tabs before reinstallation in Step 18.
Yes. The manual states: "Use a good quality paint to spray cut edges of frame to prevent rusting." This should be done after trimming the shroud to protect the exposed metal from corrosion.
Remove components in this order: 1) Fascia cover (pop out plastic piece, remove bolt, remove push pins); 2) Wheel well trim (remove push pins and bolts on both sides); 3) Adaptive Cruise Control bracket (remove three bolts, do not unplug); 4) Temperature sensor wire loom (unclip on driver side); 5) Bumper (remove bolts on both sides); 6) Belly pan (remove bolts, plastic bolt, and push pins); 7) Plastic shroud (remove four bolts, then trim with reciprocating saw).
Slide the baseplate into the frame with the hole towards the radiator on both sides of the vehicle. Start the two 1/2" bolts with hardware on the inside of the frame (accessible from the underside on the driver side and from above on the passenger side, though it is easier to access from the underside on the passenger side). Leave these loose. Then start the two 8MM bolts with hardware on both sides, leaving them loose. Set the cross tube onto the side brackets and place the four 1/2" bolts with flat washer and lock washer into holes without adding hardware to the bottom. Finally, tighten the two 1/2" frame bolts, the eight 8MM bolts on the front, and the four 1/2" cross member bolts.
Attach the ACC to the bracket on the baseplate using three 1/4" x 3/4" bolts with nylon lock nuts. Tighten these bolts to the appropriate torque specification for 1/4"-20 bolts (Grade 5: 10 foot-pounds, Grade 8: 14 foot-pounds) after applying Loctite Red to all bolt threads.
Using the provided zip ties, attach the temperature sensor loom to the baseplate on the driver side of the vehicle as shown in Step 16. The loom was unclipped from the bumper during removal and should be secured to the baseplate to prevent interference.
Attach the permanent baseplate safety cables to the provided convenience link on the baseplate. The cables should be secured to a solid piece of the frame of the vehicle on both sides. The manual recommends connecting the cables from the baseplate to the frame rail or cross member. Ensure the safety cables do not rub against any hoses or moving parts. Do not mount the cables against wires, hoses, or brake lines. Additional installation options are shown in the General Information sheet if the recommended mounting interferes with other components.
Hold the fascia as close to its original position as possible, then mark and trim the fascia around the convenience links and attachment tabs. After trimming, reinstall the fascia along with the belly pan. The manual notes that handling cosmetic parts may require protective covers, rags, or specialty tools to prevent damage.
Torque specifications for Grade 5 bolts are: 1/4" = 10 foot-pounds, 5/16" = 19 foot-pounds, 3/8" = 33 foot-pounds, 7/16" = 54 foot-pounds, 1/2" = 78 foot-pounds, 5/8" = 154 foot-pounds, 3/4" = 257 foot-pounds. Apply Loctite Red to all bolt threads before tightening.
Torque specifications for Grade 8 bolts are: 1/4" = 14 foot-pounds, 5/16" = 29 foot-pounds, 3/8" = 47 foot-pounds, 7/16" = 78 foot-pounds, 1/2" = 119 foot-pounds, 5/8" = 230 foot-pounds, 3/4" = 380 foot-pounds. Apply Loctite Red to all bolt threads before tightening.
Torque specifications for Grade 8.8 metric bolts are: 6MM = 6 foot-pounds, 8MM = 16 foot-pounds, 10MM = 31 foot-pounds, 12MM = 54 foot-pounds, 14MM = 89 foot-pounds, 16MM = 161 foot-pounds, 18MM = 222 foot-pounds. Apply Loctite Red to all bolt threads before tightening.
Torque specifications for Grade 10.9 metric bolts are: 6MM = 8 foot-pounds, 8MM = 22 foot-pounds, 10MM = 40 foot-pounds, 12MM = 70 foot-pounds, 14MM = 117 foot-pounds, 16MM = 230 foot-pounds, 18MM = 318 foot-pounds. Apply Loctite Red to all bolt threads before tightening.
The baseplate is computer tested to your vehicle's GVWR (Gross Vehicle Weight Rating). Exceeding this weight will void the manufacturer's warranty. You must reference your vehicle owner's manual for the manufacturer's towing specifications and ensure you do not exceed your vehicle's GVWR when towing.
If the baseplate is in an accident, it must be replaced. Do not use it again. An accident can cause unseen damage, and using it again could result in more damage or serious injury. Do not use the baseplate if it is damaged or missing parts.
When using a reciprocating saw, be aware of objects behind the cutting surface. The manual also advises being aware of the dangers of torque and drill bit length when using power drills. Take care to protect cosmetic parts during installation by using protective covers, rags, or specialty tools as needed.
Permanent baseplate safety cables are strongly recommended when towing a vehicle with a tow bar. The BX2729 kit includes two class III safety cables. These cables must be connected from the baseplate to the frame rail or cross member of the vehicle's frame and must remain installed as long as the baseplate is installed. The cables are to be used in conjunction with, and NOT as a replacement for, legally required safety cables attaching the towed vehicle to the towing vehicle.
Before reinstalling the fascia, ensure that all electrical connections are plugged in and accessories are functioning properly. This includes verifying that the Adaptive Cruise Control is working correctly and that the temperature sensor wire loom is properly secured.
Before each towing trip, inspect all towing equipment for cracked welds, missing or worn parts, and loose bolts. Ensure that Loctite Red is used on all bolts and that they are tightened to the recommended torque specifications. Check that the safety cables are secure and do not rub against any hoses or moving parts.
Yes. The manual states: "Remove the attachment tabs when not in use (if applicable)." This helps protect the tabs and the vehicle when the baseplate is not actively being used for towing.
Register your product online at www.blueox.com. It is crucial to register your product so that you may be alerted of product offerings, updates, upgrades, maintenance and safety bulletins, and/or recalls. The warranty is valid only if the customer warranty card is returned by the original purchaser within 30 days of purchase.
Blue Ox recommends that their towing products and accessories be installed by Blue Ox Dealers who are familiar with their products and have the equipment and knowledge necessary to do "fit work." Blue Ox Dealers can be found at www.blueox.com or by contacting the Technical Service Department at (402) 385-3051.
No. Use only genuine factory replacement parts on your baseplate. Do not substitute homemade or non-typical parts. If a bolt is lost or needs replacement, use a replacement bolt of the same grade (in most cases Grade 5). Replacement parts may be ordered through your nearest Blue Ox Dealer or Distributor. Failing to use genuine parts will void the manufacturer's warranty.
Blue Ox offers a three-year limited warranty from the date of delivery to the original retail purchaser. The warranty covers defects in material and workmanship under normal use and service. Warranty coverage is valid only if the customer warranty card is returned within 30 days of purchase and a copy of the original invoice accompanies any warranty claim. The warranty does not cover improper installation, improper use, modification, neglect, normal wear and tear, paint, or rust.
The BX2729 fits 2020-2022 Kia Soul with DCT transmission only, no fog lights in grill, and with Adaptive Cruise Control and Turbo. Confirm all specifications match before purchasing.
You need: torque wrench, flat screwdriver, reciprocating saw, 10MM/12MM/13MM/3/4" sockets, 7/16" socket and wrench, 3/4" wrench, 5/16" nut drivers, and Loctite Red.
Yes. The plastic shroud on each side must be trimmed with a reciprocating saw so the bottom is flush and sides are removed. The fascia must also be trimmed around the convenience links and attachment tabs. Cut frame edges should be painted to prevent rust.
Yes. The bumper is removed and not reinstalled. The fascia and belly pan are removed and then reinstalled after baseplate installation. The Adaptive Cruise Control bracket is removed but not unplugged.
Tighten 1/2" Grade 5 bolts to 78 foot-pounds. Apply Loctite Red to all bolt threads before tightening.
Tighten 8MM Grade 8.8 bolts to 16 foot-pounds. Apply Loctite Red to all bolt threads before tightening.
The baseplate is tested to your vehicle's GVWR. Do not exceed your vehicle's GVWR or the warranty will be voided. Check your vehicle owner's manual for towing specifications.
Yes. Two class III permanent baseplate safety cables are included. They must be attached to the frame and remain installed as long as the baseplate is on the vehicle. They supplement, not replace, legally required safety cables.
Hold the fascia as close to its original position as possible and mark the areas that need trimming around the convenience links and attachment tabs. Trim the fascia carefully and then reinstall. The manual notes that dimensional variations between otherwise identical vehicles can be considerable, and it may be necessary to tailor the baseplate slightly to compensate for vehicle manufacturer's tolerances.
Reposition the safety cables so they do not rub against any hoses or moving parts. The cables must be connected from the baseplate to the frame rail or cross member of the vehicle's frame. If the recommended mounting interferes with other components, secure the cables to a solid piece of the frame as described in the General Information sheet. Ensure the cables do not contact wires, hoses, or brake lines.
Ensure that Loctite Red is applied to all bolt threads before tightening. The manual states: "Be sure to use a sufficient amount of Loctite Red on all bolt threads before tightening." If bolts continue to loosen, verify that they are tightened to the correct torque specification for their size and grade, and reapply Loctite Red if necessary.
