Custom Designed: Each BX2169 Tow Bar Bracket is tailor-made for specific towed vehicles, ensuring a perfect fit and optimal performance.
Material: Steel
Color: Black
Finish: Powder Coat
Mounting Type: Bolt On
Mounting Hardware Included Yes/No: Yes
Take on the open road with the Blue Ox BX2169 Tow Bar Bracket. Custom-designed for each specific towed vehicle, this durable product gives peace of mind for all your towing needs. Constructed with a robust steel material and featuring a sleek black powder coat finish, it's built to resist corrosion and last for long-term use. For convenience, this tow bar bracket is easy to mount with its bolt-on mounting type and includes all necessary hardware. Designed with the end user in mind, it comes with comprehensive instructions for a hassle-free, do-it-yourself installation.
Blue Ox is known internationally for recreational and commercial towing products, manufacturing in Pender, Nebraska since 1925. The line covers tow bars and vehicle-specific baseplates for flat towing behind a motorhome, sway control and weight distributing hitches, supplemental braking accessories and towing wiring, backed by patented designs and long-standing customer service.
Blue Ox has manufactured since 1925 and is recognised internationally for towing products and customer service. The company operates from Pender, Nebraska, where it grew out of Automatic Manufacturing Co., a business that started with cattle oilers and developed into agricultural equipment, tractor accessories and trailer towing hardware. That agricultural engineering heritage still shows in how the towing products are built, and the company holds patents across weight distribution, fifth wheel and tow bar designs.
Flat towing is the discipline Blue Ox is best known for. Towing a car with all four wheels on the ground behind a motorhome demands a system that stays rigid under braking, articulates properly over uneven ground, and connects to the towed vehicle at points strong enough to take the load. Blue Ox tow bars handle the first two, with self-aligning arms that latch under tension and release without a struggle when the load is off them. Vehicle-specific baseplates handle the third, engineered per make and model to tie into structural mounting points behind the fascia.
The wider flat towing range covers supplemental braking systems, safety cables and the accessories that make a complete legal setup, along with baseplate wiring and dinghy towing harnesses that pass lighting signals to the towed vehicle without back-feeding its electrical system.
For conventional trailer towing, Blue Ox weight distributing hitches with integrated sway control transfer tongue load onto the tow vehicle's front axle and resist the yaw that crosswinds and passing trucks induce.
The company describes its foundation as customer service, designing around what owners actually ask for, and it runs an RV park adjacent to the factory where customers can stay. Sister operations at the same Nebraska site include Automatic grain roller mills and MAD-RAMPS pivoting ramp systems.
Experts available to answer your questions
Call 888-634-94943 Years
6 compatible vehicles
| Year | Make & Model | Style | Notes |
|---|---|---|---|
| 2007 | Ford F-150 | — | 4WD No Heritage Edition or FX2 Comes with Standard Attachment Tabs Height Deviation up to 4” higher on the Towing Vehicle Allowed When Used for Utility Applications Only with an Allure Tow Bar Be Sure to Confirm the Weight of Your Individual Vehicle Before Towing. Always Insure Both Your Tow Bar and Hitch are Adequately Rated for the Vehicle’s Overall Weight Tow Hooks Must be Removed and Remain off the Vehicle After Installation Minor Drilling Required Install Rating 2 |
| 2004 - 2005, 2008 | Ford F-150 | — | 4WD No Heritage Edition or FX2 Comes with Standard Attachment Tabs Install Rating 2 Minor Drilling Required Tow Hooks Must be Removed and Remain off the Vehicle After Installation Be Sure to Confirm the Weight of Your Individual Vehicle Before Towing. Always Insure Both Your Tow Bar and Hitch are Adequately Rated for the Vehicle’s Overall Weight Height Deviation up to 4” higher on the Towing Vehicle Allowed When Used for Utility Applications Only with an Allure Tow Bar |
| 2006 | Ford F-150 | — | Height Deviation up to 4” higher on the Towing Vehicle Allowed When Used for Utility Applications Only with an Allure Tow Bar Be Sure to Confirm the Weight of Your Individual Vehicle Before Towing. Always Insure Both Your Tow Bar and Hitch are Adequately Rated for the Vehicle’s Overall Weight Tow Hooks Must be Removed and Remain off the Vehicle After Installation Minor Drilling Required Install Rating 2 Comes with Standard Attachment Tabs No Heritage Edition or FX2 4WD |
| 2007 | Ford F-150 | Crew Cab Pickup | Comes with Standard Attachment Tabs Install Rating 2 Minor Drilling Required Tow Hooks Must be Removed and Remain off the Vehicle After Installation Be Sure to Confirm the Weight of Your Individual Vehicle Before Towing. Always Insure Both Your Tow Bar and Hitch are Adequately Rated for the Vehicle’s Overall Weight Height Deviation up to 4” higher on the Towing Vehicle Allowed When Used for Utility Applications Only with an Allure Tow Bar |
| 2008 | Ford F-150 | Extended Cab Pickup | Comes with Standard Attachment Tabs Install Rating 2 Height Deviation up to 4” higher on the Towing Vehicle Allowed When Used for Utility Applications Only with an Allure Tow Bar Be Sure to Confirm the Weight of Your Individual Vehicle Before Towing. Always Insure Both Your Tow Bar and Hitch are Adequately Rated for the Vehicle’s Overall Weight Tow Hooks Must be Removed and Remain off the Vehicle After Installation Minor Drilling Required |
| 2007 | Ford F-150 | Extended Cab Pickup | Comes with Standard Attachment Tabs Install Rating 2 Minor Drilling Required Tow Hooks Must be Removed and Remain off the Vehicle After Installation Be Sure to Confirm the Weight of Your Individual Vehicle Before Towing. Always Insure Both Your Tow Bar and Hitch are Adequately Rated for the Vehicle’s Overall Weight Height Deviation up to 4” higher on the Towing Vehicle Allowed When Used for Utility Applications Only with an Allure Tow Bar |
The BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select, FORD F150 4X4 (Part #FDRWBX2169) fits the following vehicles: 2004-2008 Ford F-150. Always verify your specific year, make, and model before ordering.
The BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select, FORD F150 4X4 (Part #FDRWBX2169) fits 2004-2008 Ford F-150 models. The 2008 model year is the last year covered by this part number. For newer models, check for an updated version.
Yes, the BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select, FORD F150 4X4 (Part #FDRWBX2169) is designed to fit the 2004-2008 Ford F-150.
The BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select, FORD F150 4X4 (Part #FDRWBX2169) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
The BX2169 baseplate is designed for 2004-2008 Ford F150 (4WD) models, excluding Heritage and FX2 variants. It also fits the 2007 F150 XLT Super Cab (4WD) and 2007 Ford Lariat Super Crew (4WD). If your vehicle does not match these specifications exactly, contact Blue Ox Technical Service at (402) 385-3051 before purchasing.
Yes, the BX2169 can be installed on 2006 models without factory tow hooks. However, you will be required to trim the fascia covering the tow hook openings. Wire nuts are inserted into the frame opening to align with existing holes on the bottom of the frame, and 1/2" bolts and lock washers are installed.
The BX2169 attachment tab height is 14-1/2" and the attachment tab width is 29-1/4".
Required tools include: large vise grip, torque wrench, drill, tape measure, 17/32" drill bit, 15MM socket, 3/4" socket, 3/4" wrench, and Loctite Red. A reciprocating saw may be needed for trimming. When using power drills, be aware of torque dangers and drill bit length. When using a reciprocating saw, be aware of objects behind the cutting surface.
The kit includes: 1 BX2169 DS baseplate, 1 BX2129 PS baseplate, 8 x 1/2"-13 nuts with 10" wire, 8 x 1/2"-13 x 1-3/4" hex head bolts (Grade 5, zinc plated), 8 x 1/2" lock washers, 1 electrical bracket, 1 x 1/4"-20 x 3/4" hex head bolt (Grade 5, zinc plated), 4 x 1/4" lock washers, 2 x 1/4" flat washers, 4 x 1/4"-20 hex whiz lock nuts, 2 x #10-32 1/2" round slotted head screws, 2 x #10 lock washers, 2 x #10-32 hex nuts, 2 x 4-way connector adapters, 2 x Class IV safety cables, and 2 x 1/2" quicklinks (zinc plated).
No. The factory tow hooks are removed and are not reinstalled for the baseplate installation. On 2006 models without tow hooks, the fascia covering the tow hook openings must be trimmed.
1. Remove the two bolts from the bottom side of tow hooks using a 15MM socket on both sides. 2. Align the baseplates with the holes for tow hooks and reinstall existing bolts using the existing nut plate (or insert wire nuts and 1/2" bolts if no tow hooks). 3. Using the baseplate as a template, drill remaining holes with the 17/32" drill bit, insert wire nuts, and install 1/2"-13 x 1-3/4" bolts and lock washers. 4. Attach permanent baseplate safety cables to the convenience link on the baseplate and secure to a solid frame piece on both sides.
Yes. Drilling is required. You must drill holes using a 17/32" drill bit, using the baseplate as a template. When using a power drill, be aware of the dangers of torque and drill bit length. Additionally, a hole must be drilled according to the tail light wiring kit instructions. Use a good quality paint to spray cut edges of frame to prevent rusting.
Yes, some trimming is required. On 2006 models without factory tow hooks, you must trim the fascia covering the tow hook openings. A reciprocating saw may be used; be aware of objects behind the cutting surface.
For 1/2" Grade 5 bolts, torque to 78 foot-pounds. For 1/2" Grade 8 bolts, torque to 119 foot-pounds. The BX2169 kit includes Grade 5 bolts. Always apply Loctite Red to all bolt threads before tightening. Tighten all bolts according to the torque chart provided unless otherwise specified in the instructions.
For 1/4" Grade 5 bolts, torque to 10 foot-pounds. For 1/4" Grade 8 bolts, torque to 14 foot-pounds. The BX2169 kit includes Grade 5 bolts. Always apply Loctite Red to all bolt threads before tightening.
The BX8869 Tail Light Wiring Kit is recommended for this vehicle. A hole must be drilled according to the tail light wiring kit instructions. Ensure all electrical connections are plugged in and accessories are functioning properly before reinstalling the fascia.
The baseplate is computer tested to your vehicle's GVWR. Exceeding this weight will void the manufacturer's warranty. Reference your vehicle owner's manual for manufacturer's towing specifications.
Permanent baseplate safety cables are strongly recommended when towing a vehicle with a tow bar. The BX2169 kit includes 2 Class IV safety cables. The cables must be connected from the baseplate to the frame rail or cross member of the vehicle's frame. The cables must not be mounted against wires, hoses, or brake lines. These cables should remain installed as long as the baseplate is installed and are to be used in conjunction with, not as a replacement for, legally required safety cables attaching the towed vehicle to the towing vehicle.
If the baseplate is in an accident, it must be replaced. Do not use it again. An accident can cause unseen damage, and using it again could result in more damage or serious injury. Do not use the baseplate if it is damaged or missing parts.
Before each towing trip, inspect all towing equipment for cracked welds, missing or worn parts, and loose bolts. Ensure all electrical connections are plugged in and accessories are functioning properly. Verify that safety cables do not rub against any hoses or moving parts. Check that all bolts are tightened to the recommended torque specifications and that Loctite Red is applied to all bolt threads.
It is the owner's responsibility to inspect all towing equipment for cracked welds, missing or worn parts, and loose bolts before each towing trip. Use Loctite Red on all bolts and tighten to the recommended specifications. Register your product online at www.blueox.com to be alerted of product offerings, updates, upgrades, maintenance and safety bulletins, and recalls. Remove the attachment tabs when not in use.
Always use the hardware supplied in the hardware kit and existing hardware as specified in the installation instructions. Do not assume factory bolts are adequate for baseplate mounting. If a bolt is lost or needs replacement, use a replacement bolt of the same grade. Most bolts in the BX2169 kit are Grade 5. Do not substitute homemade or non-typical parts. Replacement parts may be ordered through your nearest Blue Ox Dealer or Distributor.
Blue Ox offers a three-year limited warranty to the original retail purchaser. The warranty covers defects in material and workmanship under normal use and service. The warranty is valid only if the customer warranty card is returned within 30 days of purchase and a copy of the original invoice accompanies any warranty claim. The warranty does not cover incorrect or improper installation, improper use, modification, neglect, failure to maintain, misuse, accident, normal wear and tear, paint, or rust. The warranty is non-transferable. Register your warranty at http://blueox.com/warranty/
The BX2169 fits 2004-2008 Ford F150 (4WD) models excluding Heritage and FX2, plus 2007 F150 XLT Super Cab (4WD) and 2007 Ford Lariat Super Crew (4WD). Contact Blue Ox at (402) 385-3051 if your model is not listed.
Yes. You must drill holes using a 17/32" drill bit using the baseplate as a template. Some trimming is also required, particularly on 2006 models without factory tow hooks.
Required tools: torque wrench, drill with 17/32" bit, 15MM socket, 3/4" socket, 3/4" wrench, large vise grip, tape measure, and Loctite Red. A reciprocating saw may be needed for trimming.
Yes. The kit includes 2 Class IV permanent baseplate safety cables. These are strongly recommended and must be connected from the baseplate to the vehicle frame on both sides.
Torque 1/2" Grade 5 bolts to 78 foot-pounds. Apply Loctite Red to all bolt threads before tightening.
The BX8869 Tail Light Wiring Kit is recommended. A hole must be drilled according to the kit instructions, and all electrical connections must be tested before reinstalling the fascia.
No. Factory tow hooks are removed and not reinstalled. On 2006 models without tow hooks, the fascia covering the tow hook openings must be trimmed.
