Custom Designed For Your Vehicle
Material: Steel
Color: Black
Finish: Powder Coat
Mounting Type: Bolt On
Mounting Hardware Included Yes/No: Yes
The Blue Ox BX2114 Tow Bar Bracket is your ideal companion for towing needs. Custom designed for each specific towed vehicle, this product ensures a perfect fit and seamless integration. It's made from durable steel with a powder coat finish, making it capable of resisting corrosion and ensuring long-term use. This black tow bar bracket features a bolt-on mounting type, providing a secure and sturdy connection for your vehicle. The package includes all the necessary hardware and instructions that enable a convenient do-it-yourself installation. Upgrade your towing setup with the Blue Ox BX2114 Tow Bar Bracket, a blend of strength, durability, and easy installation.
Blue Ox is known internationally for recreational and commercial towing products, manufacturing in Pender, Nebraska since 1925. The line covers tow bars and vehicle-specific baseplates for flat towing behind a motorhome, sway control and weight distributing hitches, supplemental braking accessories and towing wiring, backed by patented designs and long-standing customer service.
Blue Ox has manufactured since 1925 and is recognised internationally for towing products and customer service. The company operates from Pender, Nebraska, where it grew out of Automatic Manufacturing Co., a business that started with cattle oilers and developed into agricultural equipment, tractor accessories and trailer towing hardware. That agricultural engineering heritage still shows in how the towing products are built, and the company holds patents across weight distribution, fifth wheel and tow bar designs.
Flat towing is the discipline Blue Ox is best known for. Towing a car with all four wheels on the ground behind a motorhome demands a system that stays rigid under braking, articulates properly over uneven ground, and connects to the towed vehicle at points strong enough to take the load. Blue Ox tow bars handle the first two, with self-aligning arms that latch under tension and release without a struggle when the load is off them. Vehicle-specific baseplates handle the third, engineered per make and model to tie into structural mounting points behind the fascia.
The wider flat towing range covers supplemental braking systems, safety cables and the accessories that make a complete legal setup, along with baseplate wiring and dinghy towing harnesses that pass lighting signals to the towed vehicle without back-feeding its electrical system.
For conventional trailer towing, Blue Ox weight distributing hitches with integrated sway control transfer tongue load onto the tow vehicle's front axle and resist the yaw that crosswinds and passing trucks induce.
The company describes its foundation as customer service, designing around what owners actually ask for, and it runs an RV park adjacent to the factory where customers can stay. Sister operations at the same Nebraska site include Automatic grain roller mills and MAD-RAMPS pivoting ramp systems.
Experts available to answer your questions
Call 888-634-94943 Years
1 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 1989 | Ford Probe | No GT/GL Comes with Standard Attachment Tabs Install Rating 2 |
Yes, the BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select, FORD PROBE E13 (Part #FDRWBX2114) is designed to fit the 1989 Ford Probe.
The BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select, FORD PROBE E13 (Part #FDRWBX2114) fits the following vehicles: 1989 Ford Probe. Always verify your specific year, make, and model before ordering.
The BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select, FORD PROBE E13 (Part #FDRWBX2114) fits 1989 Ford Probe models. The 1989 model year is the last year covered by this part number. For newer models, check for an updated version.
The BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select, FORD PROBE E13 (Part #FDRWBX2114) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
Yes, the BX2114 is designed specifically for the 1989 Ford Probe. The baseplate bolts to the front underside of the car using eight supplied bolts and mounts to the frame via the tie-down bracket holes and front-to-back beam bolts.
The kit includes the baseplate weldment (61-4019), two upper mounts (one driver-side 61-4020, one passenger-side 61-4121), eight 10mm × 80mm bolts with lock washers for the end beam holes, four 12mm × 65mm bolts with lock washers for the back holes, two 10mm × 35mm bolts with lock washers for the upper mounts, two 3/8" × 1¾" bolts with nylon lock nuts for mounting upper mounts to the base tube, two 2" tall spacers, and four 1" tall spacers. Locktite Blue is required but must be supplied separately.
Yes. Step 10 explicitly states 'With help, hold the baseplate up under the car' when starting the bolts through the baseplate, spacers, and into the front-to-back beam holes. A helper is required to support the baseplate during this critical stage of installation.
Required tools are: 14mm socket, 17mm socket, 19mm socket, 9/16" socket, 9/16" wrench, Locktite Blue, and a long extension for sockets. The long extension is necessary to reach bolts in tight undercarriage locations.
Remove six bolts total: two bolts on the inside of each front-to-back beam (four bolts), and one bolt on the end of each front-to-back beam (two bolts). On the driver-side beam, use the bolt closest to the middle of the car if there are two bolts on the end. Also remove one forward-facing bolt from each tie-down bracket (two bolts). Set all eight removed bolts aside; they will not be reused for baseplate installation.
When properly installed, the flat tab on each upper mount must be parallel to the ground and the bent tab must angle up and out. The upper mounts bolt into the holes where the tie-down bolts were removed and run forward through the frame panel holes to the front of the car.
Two different spacer sizes are used: 2" tall spacers (part 104-0414) go between the baseplate and the front-to-back beam ends when using 10mm × 80mm bolts; 1" tall spacers (part 107-1655) go between the baseplate and the car when using 12mm × 65mm bolts for the four back holes. The 2" spacers are used on the end holes, and the 1" spacers on the back holes.
The upper mounts bolt to the base tube using 3/8" × 1¾" hex bolts (Grade 5) and 3/8"-16 nylon lock nuts through the holes near each end of the tube. Locktite must be applied even with the lock nuts. Two bolts and two lock nuts are supplied.
Two types of bolts are used: 10mm × 80mm hex bolts (Grade 8.8) with lock washers and 2" spacers for the end holes of the front-to-back beams (four bolts total, two per side); and 12mm × 65mm hex bolts (Grade 8.8) with lock washers and 1" spacers for the four back holes. All bolts require Locktite application.
The upper mounts bolt to the frame using 10mm × 35mm hex bolts (Grade 8.8) with lock washers. Two bolts are supplied (one per upper mount). Locktite must be applied to these bolts.
Do not tighten bolts completely until all bolts are started. Step 6 states to install upper mounts 'but do not tighten completely.' Step 10 states to apply Locktite 'but do not tighten yet.' Only after all bolts are started (Step 12) should you 'tighten completely.'
Yes. Locktite Blue must be applied to the 10mm × 35mm bolts for the upper mounts (Step 6), the 10mm × 80mm and 12mm × 65mm bolts for the baseplate-to-beam connection (Step 10), and the 3/8" × 1¾" bolts for the upper mount-to-base tube connection (Step 11), even though lock nuts are used on the latter.
The manual notes that dimensional variations between otherwise identical cars can be considerable. If a bolt does not clear, it may be necessary to file a hole slightly to allow the bolt to pass through. This is a normal part of the installation process for some vehicles.
During tow testing, it was found that the front wheels may remain in the turned position after the vehicle exits a sharp dip and straightens out. If the vehicle is towed any distance with the front wheels still turned, damage to the tires and/or front end may result. Watch for this condition during towing. For specific information, contact Automatic Equipment.
Do not substitute other devices if the tow bar pin and clip are lost. Use only the original tow bar pin and clip supplied with the product.
On the driver-side, the best access to the forward-facing tie-down bolt is from below. On the passenger-side, the air conditioning unit is in the way, so the best access is from above.
Yes, the BX2114 is designed specifically for the 1989 Ford Probe and bolts to the front underside using eight supplied bolts.
You need: 14mm, 17mm, and 19mm sockets; 9/16" socket and wrench; Locktite Blue; and a long socket extension.
Yes, a helper is required to hold the baseplate in position while you start the bolts.
Remove eight bolts total: six from the front-to-back beams (two inside each beam, one end bolt per beam) and two forward-facing bolts from the tie-down brackets.
Two types: 10mm × 80mm bolts (Grade 8.8) with 2" spacers for the end holes, and 12mm × 65mm bolts (Grade 8.8) with 1" spacers for the back holes. All require Locktite.
Front wheels may remain turned after exiting sharp dips. If towed any distance with wheels still turned, tire and front-end damage may result. Watch for this condition during towing.
