Custom-designed: The Blue Ox BX1958 Tow Bar Bracket is specifically designed for each towed vehicle, ensuring a perfect fit and seamless integration.
Material: Steel
Color: Black
Finish: Powder Coat
Mounting Type: Bolt On
Mounting Hardware Included Yes/No: Yes
The Blue Ox BX1958 Tow Bar Bracket is a top-tier towing solution, designed to fit your specific vehicle. It's constructed from durable steel, ensuring long-lasting performance and reliability. The black powder coat finish not only enhances its aesthetic appeal but also provides a robust defense against corrosion and wear. This base plate includes all necessary hardware, making it easy for a DIY installation, eliminating the need for professional assistance. Its bolt-on mounting type ensures a secure fit and stable towing experience.
Blue Ox is known internationally for recreational and commercial towing products, manufacturing in Pender, Nebraska since 1925. The line covers tow bars and vehicle-specific baseplates for flat towing behind a motorhome, sway control and weight distributing hitches, supplemental braking accessories and towing wiring, backed by patented designs and long-standing customer service.
Blue Ox has manufactured since 1925 and is recognised internationally for towing products and customer service. The company operates from Pender, Nebraska, where it grew out of Automatic Manufacturing Co., a business that started with cattle oilers and developed into agricultural equipment, tractor accessories and trailer towing hardware. That agricultural engineering heritage still shows in how the towing products are built, and the company holds patents across weight distribution, fifth wheel and tow bar designs.
Flat towing is the discipline Blue Ox is best known for. Towing a car with all four wheels on the ground behind a motorhome demands a system that stays rigid under braking, articulates properly over uneven ground, and connects to the towed vehicle at points strong enough to take the load. Blue Ox tow bars handle the first two, with self-aligning arms that latch under tension and release without a struggle when the load is off them. Vehicle-specific baseplates handle the third, engineered per make and model to tie into structural mounting points behind the fascia.
The wider flat towing range covers supplemental braking systems, safety cables and the accessories that make a complete legal setup, along with baseplate wiring and dinghy towing harnesses that pass lighting signals to the towed vehicle without back-feeding its electrical system.
For conventional trailer towing, Blue Ox weight distributing hitches with integrated sway control transfer tongue load onto the tow vehicle's front axle and resist the yaw that crosswinds and passing trucks induce.
The company describes its foundation as customer service, designing around what owners actually ask for, and it runs an RV park adjacent to the factory where customers can stay. Sister operations at the same Nebraska site include Automatic grain roller mills and MAD-RAMPS pivoting ramp systems.
Experts available to answer your questions
Call 888-634-94943 Years
Yes, the BX1958 is designed for 2003-04 Mitsubishi Montero vehicles. The attachment tabs are 17 inches center to center with a height of 21½ inches.
The front fascia and windshield washer reservoir must be removed. You will also need to remove the plastic cover on top of the fascia, the grille, the metal bumper bolts, push pins, belly pan, and disconnect the washer reservoir's electrical connections and water lines.
Yes, drilling is required. You will drill one 1¼" hole in the frame on the outer side next to the sensor on both sides using a 1¼" hole saw, and two 13/32" holes on the top of the frame rails on each side using a 13/32" drill bit. Trimming of the air dam is also required.
A 1¼" hole saw is required to drill one hole in the frame on the outer side next to the sensor on both sides of the vehicle.
A 13/32" drill bit is required to drill two holes on the top of the frame rails on each side, using the baseplate as a template.
Required tools are: 10MM socket, 12MM socket, 9/16" socket, 13/32" drill bit, 1¼" hole saw, hack saw, flat screwdriver, Phillips screwdriver, vise grips, and Loctite. A piece of pipe or deep socket is also recommended to protect the coolant line while drilling.
Yes, Loctite must be used on all bolts before tightening. The manual specifies using Loctite Red on all bolts and tightening to recommended specifications.
1. Remove plastic cover and clips from fascia. 2. Release grille. 3. Remove bumper bolts and push pins. 4. Remove belly pan bolts. 5. Remove fascia bolts. 6. Remove washer reservoir bolts and disconnect electrical/water lines. 7. Cut alignment pin from reservoir. 8. Bend brackets up. 9. Drill 1¼" hole next to sensor on both sides. 10. Position baseplate on frame rails. 11. Drill two 13/32" holes on each side using baseplate as template. 12. Insert nut plates and tighten 3/8" bolts with lock washers using Loctite. 13. Reinstall washer reservoir, fascia, and belly pan. 14. Install tow bar and safety cables per their instructions.
Remove three metric bolts from the reservoir using a 10MM socket. Lift the reservoir to release the alignment pin from the top of the frame. Unplug electrical connections and disconnect water lines. Using a hack saw, cut the alignment pin from the bottom of the reservoir tank. After baseplate installation, reinstall the reservoir, ensuring all electrical components and hoses are plugged in properly before installing the fascia.
The manual notes that dimensional variations between otherwise identical vehicles can be considerable. While the baseplate holes were designed for easy installation, it may be necessary to file a hole slightly to allow a bolt to clear.
Be cautious of the coolant line on the passenger's side when drilling the lower hole. Insert the drill bit into a piece of pipe or deep socket while drilling to protect the coolant line from damage.
The manual references a Torque Chart in the General Instruction Sheet, which is not provided in this document. Contact Blue Ox at 402-385-3051 or consult the General Instruction Sheet that should accompany your baseplate for specific torque values.
The baseplate uses 3/8-16 x 1½ bolts (Grade 5, zinc plated) with 3/8 lock washers, and 13/32" drill holes with nut plates. The assembly also includes 1/4-20 x ¾ hex bolts, #10-16 self-drilling screws, and #10-32 slot round head screws. All bolts should be Grade 5 or equivalent.
Yes. The windshield washer reservoir has electrical connections that must be unplugged before removal and plugged back in properly before reinstalling the fascia. The baseplate includes an electrical bracket (part 101-6135) and 4-way connector adapters (part 101-5822) for wiring integration.
Permanent baseplate safety cables are strongly recommended when towing a vehicle with a tow bar. The cables must be connected from the baseplate to the frame rail or cross member of the vehicle's frame. The BX1958 includes two 36" Class III safety cables (part 226-0046) and two 3/8" quicklinks (part 229-0359). These cables are not a replacement for legally required safety cables attaching the towed vehicle to the towing vehicle.
Permanent baseplate safety cables must be connected from the baseplate to the frame rail or cross member of the vehicle's frame. Do not mount the cables against wires, hoses, or brake lines, as improper installation could cause fluid leaks or electrical shorts.
Before each towing trip, inspect all towing equipment for cracked welds, missing or worn parts, and loose bolts. Ensure all bolts are tightened to recommended specifications using Loctite Red.
Yes, the attachment tabs should be removed when not in use.
If a bolt is lost or needs replacement, use a replacement bolt of the same grade (usually Grade 5). Repair parts may be ordered through your nearest Blue Ox dealer or distributor. Do not substitute homemade or nontypical parts, as this could affect safety and baseplate preservation.
Yes, it is crucial to register your product online at www.blueox.com so that you may be alerted of product offerings, updates, upgrades, maintenance and safety bulletins, and/or recalls.
The dealer or installer must be certain the user receives the instruction sheet. This is critical for proper operation and maintenance of the baseplate.
Yes, the BX1958 is designed for 2003-04 Mitsubishi Montero with attachment tabs 17 inches center to center and 21½ inches height.
Yes. Drilling is required: one 1¼" hole on each side next to the sensor, and two 13/32" holes on each side on the frame rails. Air dam trimming is also required.
10MM and 12MM sockets, 9/16" socket, 13/32" drill bit, 1¼" hole saw, hack saw, screwdrivers, vise grips, and Loctite. A piece of pipe or deep socket is recommended to protect the coolant line while drilling.
Front fascia, windshield washer reservoir, grille, plastic cover, metal bumper bolts, push pins, and belly pan must be removed or disconnected.
Yes, two 36" Class III safety cables and two 3/8" quicklinks are included. Permanent safety cables are strongly recommended and must be connected from baseplate to frame rail or cross member, not against wires or hoses.
3/8-16 x 1½ Grade 5 bolts with 3/8 lock washers are primary fasteners. Torque specifications are in the General Instruction Sheet (not provided). Use Loctite on all bolts before tightening.
Before each towing trip, inspect for cracked welds, missing or worn parts, and loose bolts. Tighten all bolts to recommended specifications using Loctite Red. Remove attachment tabs when not in use.
1 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2003 | Mitsubishi Montero | LTD Comes with Removable Attachment Tabs Install Rating 3 Bumper Fascia Must Be Removed/Replaced During Install Minor Drilling Required Use only w/Motorhome Mount Tow Bars Or PN BX8833/BX88151 Adapters Only Use Acclaim w/23”: 30” Spaced Removable Tab Baseplates Only Use Adventurer with 18”: 41” Spaced Removable Tab Baseplates Removable Tabs w/Only 1 Hole Will Not Attach to Car Mount Tow Bars or Adapters Due to the Design of the Baseplate, the Adventurer Tow Bar Cannot be Used With the Baseplate |
