Draw-tite Class 4 Trailer Hitch, 2" Square Receiver, Black 41001Draw-titeOriginal price was $352.50. Current price is $223.95.Out of Stock
View productAsk a Question About This Product
Our in-house experts typically reply within one business day.
Our in-house experts typically reply within one business day.
Draw-tite
1999 - 2002 Chevrolet Silverado 1500
Confirmed to Fit
2003 - 2013 Chevrolet Silverado 1500
Confirmed to Fit
2001 - 2003, 2005 - 2007 Chevrolet Silverado 1500 HD
Confirmed to Fit
1999 - 2004 Chevrolet Silverado 2500
Confirmed to Fit
1999 - 2013 GMC Sierra 1500
Confirmed to Fit
2001 - 2003, 2005 - 2007 GMC Sierra 1500 HD
Confirmed to Fit
1999 - 2004 GMC Sierra 2500
Confirmed to Fit
Always the correct part
We know our products
Quality Products
Free Shipping!
Verify Fitment
Select your vehicle to confirm this part fits.
Select your vehicle to find the exact plug-and-play parts that fit — no cutting or splicing.
DRAW-TITE Class 4 trailer hitches are the perfect mix of style and strength to get you and your equipment wherever you need to go. This DRAW-TITE Class 4 receiver hitch is rated for up to 6,000 lbs. gross trailer weight (GTW) and up to 900 lbs. tongue weight (TW). They are also suitable for use with weight distribution up to 10,500 lbs. weight distribution (WD) and 1,050 lbs. weight distribution tongue weight (WDTW). DRAW-TITE hitches are designed to provide top towing performance, with solid-all-welded construction and a black powder coat finish to resist rust and corrosion. The Class 4 trailer hitch has a 2 inch square receiver tube opening, allowing you to attach accessories like a bike rack or cargo carrier, or hook up your pop-up, boat trailer, or utility trailer. Includes all the mounting hardware needed for installation and are backed by a nationwide lifetime limited warranty. DRAW-TITE trailer hitches are tested to exceed V-5 and SAE J684 standards. DRAW-TITE: North Americas Favorite Hitch.
| BRAND: | DRAW-TITE |
| PART NUMBER: | 75521 |
| WARRANTY: | LIMITED LIFETIME WARRANTY |
| WEIGHT: | 42 LBS |
| GROSS TOWING WEIGHT: | 6,000 LBS. |
| GROSS TONGUE WEIGHT: | 900 LBS. |
| RECEIVER SIZE: | 2 IN. |
| HITCH CLASS: | IV |
| DRILLING REQUIRED: | NO |
| MOUNTING HARDWARE INCLUDED: | YES |
| ATTACHMENT LOCATION: | REAR |
| HITCH VISIBILITY: | VISIBLE |
| CROSS-TUBE TYPE: | ROUND TUBE |
| BALL MOUNT INCLUDED: | NO |
| COLOR: | BLACK |
| FINISH: | BLACK POWDER COAT OVER E-COAT |
| MATERIAL: | STEEL |
| MOUNTING LOCATION: | VEHICLE FRAME |
| MOUNTING TYPE: | BOLT-ON |
| GROSS TOWING WEIGHT WITH WEIGHT DISTRIBUTION: | 10,500 LBS. |
| GROSS TONGUE WEIGHT WITH WEIGHT DISTRIBUTION: | 1,050 LBS. |
Draw-Tite has designed custom-fit trailer hitches since 1946 and is one of North America's most widely fitted hitch brands. Receiver hitches use solid all-welded construction and low-profile designs that follow modern vehicle contours, install with minimal bumper cutting or drilling, meet or exceed V5 CSA and SAE J684 standards, and carry a limited lifetime warranty.
Draw-Tite has been leading custom-fit trailer hitch design and engineering since its founding in 1946, and it remains one of the most widely fitted hitch brands in North America. The company's stated approach is straightforward: every hitch is tested rigorously so that it performs well beyond published industry standards, a philosophy it markets as Tested Tough. It sits within the Horizon Global towing group alongside Reese, Fulton, Bulldog, Tekonsha, Bargman and Wesbar.
Custom fit is the defining characteristic. Rather than adapting a universal design, Draw-Tite engineers a trailer hitch for a specific make, model and model year, so it bolts to existing frame locations with minimal bumper cutting or drilling. Low-profile designs follow the rear contours and aerodynamic styling of modern vehicles, which matters more than it once did now that rear fascias are shaped and sensor-equipped. Construction is solid all-welded steel for maximum strength, and every hitch meets or exceeds V5 CSA and SAE J684 standards and is backed by a nationwide limited lifetime warranty.
The range spans receiver sizes and classes to suit different loads, from 1-1/4 inch receivers for bike racks, cargo carriers and light trailers up through 2 inch receivers for heavier towing. Front mount hitches add a receiver at the front of the vehicle for winch mounts, snow plows, spare carriers and precise trailer positioning.
The Hidden Hitch series takes concealment further by mounting behind the vehicle's rear fascia, so the vehicle keeps its factory appearance until a removable receiver is fitted. Each is custom designed per make and model for a no-drill installation that does not compromise ground clearance, rated for up to 3,500 pounds gross trailer weight and 350 pounds tongue weight. Matching plug-and-play wiring completes the towing system.
Experts available to answer your questions
Call 888-634-9494Lifetime
Equip your vehicle for towing and hitch-mounted accessories with a dependable CURT 2" trailer hitch. Designed for a vehicle-specific fit, CURT receiver hitches provide a strong and secure connection point for towing trailers, carrying bikes, transporting cargo and using other compatible 2-inch hitch accessories.
Our selection of CURT 2-inch receiver hitches includes options for trucks, SUVs, crossovers, vans and passenger vehicles. Each hitch is engineered to match specific vehicle mounting points, helping provide a clean installation and dependable performance. Depending on the vehicle application, available options may include Class 3, Class 4 and heavy-duty receiver hitches with different gross trailer weight and tongue weight capacities.
A 2" x 2" receiver opening is one of the most common hitch sizes and works with a wide range of towing accessories, including ball mounts, bike racks, cargo carriers, hitch steps and tow hooks. When towing a trailer, you may also need a properly rated trailer ball, hitch pin, wiring harness, brake controller or weight distribution system.
CURT trailer hitches feature a durable black finish designed to help protect against rust, scratches and exposure to road conditions. Many models install using existing holes in the vehicle frame, although drilling, trimming or temporary removal of vehicle components may be required for certain applications.
Use our vehicle fitment tools to find the correct CURT 2" trailer hitch for your year, make and model. Always compare the hitch rating with your vehicle’s towing capacity and the ratings of every component in your towing setup. The maximum towing capacity is determined by the lowest-rated component.
Shop CURT 2-inch trailer hitches at TowUniverse for vehicle-specific fitment, trusted towing performance and access to the accessories needed to complete your towing setup.
Draw•Tite® and the Checkered Flag Foundation
7 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 1999 - 2002 | Chevrolet Silverado 1500 | Class 4 Trailer Hitch: 6000 lbs 900/6,000 lbs. Weight Carrying (tongue weight/gross trailer weight) 1,050/10,500 lbs. when used with a Weight Distribution Kit (tongue weight/gross trailer weight) Uses all existing holes. No Drilling required Install Time is 15 minutes |
| 2003 - 2013 | Chevrolet Silverado 1500 | Class 4 Trailer Hitch: 6000 lbs 900/6,000 lbs. Weight Carrying (tongue weight/gross trailer weight) 1,050/10,500 lbs. when used with a Weight Distribution Kit (tongue weight/gross trailer weight) Uses all existing holes. No Drilling required Install Time is 15 minutes Installation requires OEM bumper and brackets |
| 2001 - 2003, 2005 - 2007 | Chevrolet Silverado 1500 HD | Class 4 Trailer Hitch: 6000 lbs 900/6,000 lbs. Weight Carrying (tongue weight/gross trailer weight) 1,050/10,500 lbs. when used with a Weight Distribution Kit (tongue weight/gross trailer weight) Uses all existing holes. No Drilling required Install Time is 15 minutes Installation requires OEM bumper and brackets |
| 1999 - 2004 | Chevrolet Silverado 2500 | Class 4 Trailer Hitch: 6000 lbs 900/6,000 lbs. Weight Carrying (tongue weight/gross trailer weight) 1,050/10,500 lbs. when used with a Weight Distribution Kit (tongue weight/gross trailer weight) Uses all existing holes. No Drilling required Install Time is 15 minutes Installation requires OEM bumper and brackets |
| 1999 - 2013 | GMC Sierra 1500 | Class 4 Trailer Hitch: 6000 lbs 900/6,000 lbs. Weight Carrying (tongue weight/gross trailer weight) 1,050/10,500 lbs. when used with a Weight Distribution Kit (tongue weight/gross trailer weight) Uses all existing holes. No Drilling required Install Time is 15 minutes Installation requires OEM bumper and brackets |
| 2001 - 2003, 2005 - 2007 | GMC Sierra 1500 HD | Class 4 Trailer Hitch: 6000 lbs 900/6,000 lbs. Weight Carrying (tongue weight/gross trailer weight) 1,050/10,500 lbs. when used with a Weight Distribution Kit (tongue weight/gross trailer weight) Uses all existing holes. No Drilling required Install Time is 15 minutes Installation requires OEM bumper and brackets |
| 1999 - 2004 | GMC Sierra 2500 | Class 4 Trailer Hitch: 6000 lbs 900/6,000 lbs. Weight Carrying (tongue weight/gross trailer weight) 1,050/10,500 lbs. when used with a Weight Distribution Kit (tongue weight/gross trailer weight) Uses all existing holes. No Drilling required Install Time is 15 minutes Installation requires OEM bumper and brackets |
Yes, the Draw-tite Class 4 Trailer Hitch, 2" Square Receiver, Black 75521 (Part #DT75521) is designed to fit the 1999-2013 Chevrolet Silverado 1500.
The Draw-tite Class 4 Trailer Hitch, 2" Square Receiver, Black 75521 (Part #DT75521) fits 1999-2013 Chevrolet Silverado 1500 models. The 2013 model year is the last year covered by this part number. For newer models, check for an updated version.
The Draw-tite Class 4 Trailer Hitch, 2" Square Receiver, Black 75521 (Part #DT75521) fits the following vehicles: 1999-2013 Chevrolet Silverado 1500; 2001-2007 Chevrolet Silverado 1500 HD; 1999-2004 Chevrolet Silverado 2500; 1999-2013 GMC Sierra 1500; 2001-2007 GMC Sierra 1500 HD; 1999-2004 GMC Sierra 2500. Always verify your specific year, make, and model before ordering.
The Draw-tite Class 4 Trailer Hitch, 2" Square Receiver, Black 75521 (Part #DT75521) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
Yes, part number 75521 is designed for Chevrolet Silverado Pickup 1500 and GMC Sierra Pickup 1500. However, the hitch requires that your vehicle has a factory-installed steel step bumper and brackets. The hitch must be used in conjunction with these OEM bumper components.
Yes. The factory-installed steel step bumper and brackets must be used in conjunction with this hitch. The installation procedure requires the existing weldnuts in the vehicle frame that are part of the factory bumper assembly.
The maximum towing capacity depends on the hitch type. For weight-distributing hitches, the maximum gross trailer weight is 10,500 lb (4,767 kg) with a maximum tongue weight of 1,050 lb (477 kg). For weight-carrying ball mount, the maximum gross trailer weight is 6,000 lb (2,724 kg) with a maximum tongue weight of 900 lb (409 kg). Do not exceed the lower of your towing vehicle manufacturer's rating or these hitch type ratings.
You will need wrenches in the following sizes: 3/4 inch, 21 mm, and 22 mm. A torque wrench is also required to properly tighten the fasteners to specification. No drill bits are needed for this installation.
The fastener kit 75521F includes: four M14 × 2.00 × 40 mm CL10.9 bolts, four 1/2-13 × 1-3/4 GR5 carriage bolts, four 9/16 inch flat washers, four 9/16 inch lock washers, four 1/2 inch conical washers, four 1/2-13 hex nuts, and four blocks. All fasteners are typical for both sides of the vehicle.
The installation sequence is: (1) Remove existing M14 bolts from the end of each frame rail. (2) Lift the receiver into position, locating the rearmost slots in the receiver under the existing weldnuts in the vehicle frame. (3) Install new M14 bolts through the receiver into the weldnuts in the vehicle frame and into the step bumper. (4) Install remaining fasteners as shown in the diagram.
No. The equipment required list specifies "Drill Bits: None". The installation uses existing factory weldnuts and frame holes.
All 1/2 inch GR5 fasteners must be tightened with a torque wrench to 75 lb.-ft. (102 N·m).
All M14 CL10.9 fasteners must be tightened with a torque wrench to 115 lb.-ft. (156 N·m).
Observe safety precautions when working beneath a vehicle and wear eye protection. Do not cut access or attachment holes with a torch. If the hitch is removed, plug all holes in the trunk pan or other body panels to prevent entry of water and exhaust fumes. A hitch or ball which has been damaged should be removed and replaced.
Check the hitch frequently, making sure all fasteners and the ball are properly tightened. The manual emphasizes regular inspection to ensure the installation remains secure during use.
Check the hitch frequently, making sure all fasteners and the ball are properly tightened. The manual does not specify an exact interval, but emphasizes regular inspection as part of ongoing maintenance.
The wiring access location is PU3, as specified in the equipment required section of the manual.
Yes, part 75521 fits Chevrolet Silverado Pickup 1500 and GMC Sierra Pickup 1500, but your vehicle must have a factory-installed steel step bumper and brackets.
Maximum gross trailer weight is 10,500 lb (weight-distributing) or 6,000 lb (weight-carrying), with maximum tongue weight of 1,050 lb or 900 lb respectively. Do not exceed your vehicle manufacturer's rating.
You need wrenches (3/4", 21 mm, 22 mm) and a torque wrench. No drilling is required.
Tighten 1/2" GR5 fasteners to 75 lb.-ft. (102 N·m) and M14 CL10.9 fasteners to 115 lb.-ft. (156 N·m) using a torque wrench.
Wear eye protection, work safely beneath the vehicle, and do not use a torch to cut holes. Check fasteners and ball frequently after installation.
Yes, a compatible bike rack, cargo carrier or other accessory with a 2" x 2" shank can generally be used. Make sure the accessory does not exceed the hitch’s tongue weight rating, the vehicle’s limits or the accessory manufacturer’s capacity. Account for the combined weight of the carrier and everything loaded onto it.
