Draw-Tite Hardware Kit For Ultra Frame® Class 5 Trailer Hitch, 2 Inch 41954 For 2021-2026 Ford F-150 Draw-tite$55.49Out of Stock
View productAsk a Question About This Product
Our in-house experts typically reply within one business day.
Our in-house experts typically reply within one business day.
Draw-tite
Verify Fitment
Select your vehicle to confirm this part fits.
2015 - 2025 Ford F-150
Confirmed to Fit
Always the correct part
We know our products
Quality Products
Free Shipping!
Always the correct part
We know our products
Quality Products
Free Shipping!
Select your vehicle to find the exact plug-and-play parts that fit — no cutting or splicing.
DRAW-TITE Class 5 trailer hitches are the choice of professionals and big toy haulers who need to get the job done! These Class 5 heavy-duty hitches are rated for up to 11,000 lbs. gross trailer weight (GTW) and up to 1,100 lbs. tongue weight (TW). They are also suitable for use with weight distribution up to 14,000 lbs. weight distribution (WD) and 1,400 lbs. weight distribution tongue weight (WDTW). DRAW-TITE hitches are designed to provide top towing performance, with solid-all-welded construction and a black powder coat finish to resist rust and corrosion. The 2 inch square receiver tube opening, bigger chain loops, tighter ball mount fit, and reinforced pin holes make these heavy-duty hitches ideal for toy haulers and commercial vehicles alike. Includes all the mounting hardware needed for installation and are backed by a nationwide lifetime limited warranty. DRAW-TITE trailer hitches are tested to exceed V-5 and SAE J684 standards. DRAW-TITE: North Americas Favorite Hitch.
| BRAND: | DRAW-TITE |
| PART NUMBER: | 41954 |
| WARRANTY: | LIMITED LIFETIME WARRANTY |
| WEIGHT: | 46.25 LBS |
| GROSS TOWING WEIGHT: | 11,000 LBS. |
| GROSS TONGUE WEIGHT: | 1,100 LBS. |
| RECEIVER SIZE: | 2 IN. |
| HITCH CLASS: | V |
| DRILLING REQUIRED: | NO |
| MOUNTING HARDWARE INCLUDED: | YES |
| ATTACHMENT LOCATION: | REAR |
| HITCH VISIBILITY: | CONCEALED |
| CROSS-TUBE TYPE: | SQUARE TUBE |
| BALL MOUNT INCLUDED: | NO |
| COLOR: | BLACK |
| FINISH: | BLACK POWDER COAT OVER E-COAT |
| MATERIAL: | STEEL |
| MOUNTING LOCATION: | VEHICLE FRAME |
| MOUNTING TYPE: | BOLT-ON |
| GROSS TOWING WEIGHT WITH WEIGHT DISTRIBUTION: | 14,000 LBS. |
| GROSS TONGUE WEIGHT WITH WEIGHT DISTRIBUTION: | 1,400 LBS. |
Draw-Tite has designed custom-fit trailer hitches since 1946 and is one of North America's most widely fitted hitch brands. Receiver hitches use solid all-welded construction and low-profile designs that follow modern vehicle contours, install with minimal bumper cutting or drilling, meet or exceed V5 CSA and SAE J684 standards, and carry a limited lifetime warranty.
Draw-Tite has been leading custom-fit trailer hitch design and engineering since its founding in 1946, and it remains one of the most widely fitted hitch brands in North America. The company's stated approach is straightforward: every hitch is tested rigorously so that it performs well beyond published industry standards, a philosophy it markets as Tested Tough. It sits within the Horizon Global towing group alongside Reese, Fulton, Bulldog, Tekonsha, Bargman and Wesbar.
Custom fit is the defining characteristic. Rather than adapting a universal design, Draw-Tite engineers a trailer hitch for a specific make, model and model year, so it bolts to existing frame locations with minimal bumper cutting or drilling. Low-profile designs follow the rear contours and aerodynamic styling of modern vehicles, which matters more than it once did now that rear fascias are shaped and sensor-equipped. Construction is solid all-welded steel for maximum strength, and every hitch meets or exceeds V5 CSA and SAE J684 standards and is backed by a nationwide limited lifetime warranty.
The range spans receiver sizes and classes to suit different loads, from 1-1/4 inch receivers for bike racks, cargo carriers and light trailers up through 2 inch receivers for heavier towing. Front mount hitches add a receiver at the front of the vehicle for winch mounts, snow plows, spare carriers and precise trailer positioning.
The Hidden Hitch series takes concealment further by mounting behind the vehicle's rear fascia, so the vehicle keeps its factory appearance until a removable receiver is fitted. Each is custom designed per make and model for a no-drill installation that does not compromise ground clearance, rated for up to 3,500 pounds gross trailer weight and 350 pounds tongue weight. Matching plug-and-play wiring completes the towing system.
Experts available to answer your questions
Call 888-634-9494Lifetime
Equip your vehicle for towing and hitch-mounted accessories with a dependable CURT 2" trailer hitch. Designed for a vehicle-specific fit, CURT receiver hitches provide a strong and secure connection point for towing trailers, carrying bikes, transporting cargo and using other compatible 2-inch hitch accessories.
Our selection of CURT 2-inch receiver hitches includes options for trucks, SUVs, crossovers, vans and passenger vehicles. Each hitch is engineered to match specific vehicle mounting points, helping provide a clean installation and dependable performance. Depending on the vehicle application, available options may include Class 3, Class 4 and heavy-duty receiver hitches with different gross trailer weight and tongue weight capacities.
A 2" x 2" receiver opening is one of the most common hitch sizes and works with a wide range of towing accessories, including ball mounts, bike racks, cargo carriers, hitch steps and tow hooks. When towing a trailer, you may also need a properly rated trailer ball, hitch pin, wiring harness, brake controller or weight distribution system.
CURT trailer hitches feature a durable black finish designed to help protect against rust, scratches and exposure to road conditions. Many models install using existing holes in the vehicle frame, although drilling, trimming or temporary removal of vehicle components may be required for certain applications.
Use our vehicle fitment tools to find the correct CURT 2" trailer hitch for your year, make and model. Always compare the hitch rating with your vehicle’s towing capacity and the ratings of every component in your towing setup. The maximum towing capacity is determined by the lowest-rated component.
Shop CURT 2-inch trailer hitches at TowUniverse for vehicle-specific fitment, trusted towing performance and access to the accessories needed to complete your towing setup.
1 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2015 - 2025 | Ford F-150 | Class 5 Trailer Hitch: 11000 lbs 1,100/11,000 lbs. Weight Carrying (tongue weight/gross trailer weight) 1,400/14,000 lbs. when used with a Weight Distribution Kit (tongue weight/gross trailer weight) Uses all existing holes. No Drilling required Install Time is 30 minutes |
The Draw-tite Ultra Frame® Class 5 Trailer Hitch, 2" Square Receiver, Black for Select Ford F-150 41954 (Part #DT41954) fits 2015-2025 Ford F-150 models. The 2025 model year is the last year covered by this part number. For newer models, check for an updated version.
Yes, the Draw-tite Ultra Frame® Class 5 Trailer Hitch, 2" Square Receiver, Black for Select Ford F-150 41954 (Part #DT41954) is designed to fit the 2015-2025 Ford F-150.
The Draw-tite Ultra Frame® Class 5 Trailer Hitch, 2" Square Receiver, Black for Select Ford F-150 41954 (Part #DT41954) fits the following vehicles: 2015-2025 Ford F-150. Always verify your specific year, make, and model before ordering.
The Draw-tite Ultra Frame® Class 5 Trailer Hitch, 2" Square Receiver, Black for Select Ford F-150 41954 (Part #DT41954) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
Yes, part number 41954 is designed for Ford F150 models from 2015 to current. However, visit the manufacturer's website for the most up-to-date information regarding specific application years and trim levels, as compatibility may vary by year and trim.
Yes, the 41954 hitch is compatible with 2020 Ford F150 models, as the product covers 2015-Current applications. For the most current information on specific trim levels and configurations, visit the manufacturer's website.
The 41954 hitch has two capacity ratings depending on the hitch type: Weight Carrying hitch supports a maximum gross trailer weight of 11,000 lb. (4,990 kg) with a maximum tongue weight of 1,100 lb. (499 kg); Weight Distributing hitch supports a maximum gross trailer weight of 14,000 lb. (6,350 kg) with a maximum tongue weight of 1,400 lb. (635 kg). Do not exceed the lower of your towing vehicle manufacturer's rating or these limits.
Maximum tongue weight depends on hitch type: Weight Carrying hitch allows 1,100 lb. (499 kg) maximum tongue weight; Weight Distributing hitch allows 1,400 lb. (635 kg) maximum tongue weight. Do not exceed the lower of your vehicle manufacturer's rating or these limits.
Required tools include: 10 mm socket, 13 mm socket, 15/16" socket, 6" socket extension, ratchet, torque wrench, safety glasses, flat head screwdriver, and masking tape. A torque wrench is essential for final fastener tightening to the specified values.
The fastener kit 41954F includes: four 5/8-11 x 2.00 Gr5 carriage bolts, four .250 x 1.12 x 3.00 spacer blocks, two .188 x 1.00 x 2.00 U-shaped spacer blocks, four 5/8 conical washers, four 5/8-11 Gr2 hex nuts, two .250 x 1.75 x 2.50 spacer blocks, one M8 x 1.25 x 30 CL8.8 bolt, one 5/16 lock washer, one 5/16 flat washer, four 5/8 pull wires, and two cable ties.
Yes, you must lower the spare tire before beginning hitch installation. This is step 2 of the installation process. After installation is complete, raise the spare tire back to its original stowed position.
The manual does not specify whether the vehicle battery must be disconnected during installation. Contact the manufacturer at 1-800-632-3290 or TechnicalSupport@horizonglobal.com for clarification on this requirement.
The first step is to remove the ground wire and wiring harness. Using a 10 mm socket, remove the ground wire from the inside of the passenger side frame rail and return the fastener to the vehicle owner. For model years after 2021, use a flat head screwdriver to detach the wiring harness on the driver side if present.
Use masking tape to secure spacer blocks in place. Secure the U-shaped spacer block (③) to the inside of the frame rail in the recessed area, centered around the hole in the frame, on both sides. Do not cover the ground wire hole below the hitch mounting hole. Also secure the .250 x 1.75 x 2.50 spacer block (⑥) to the forward mounting hole of the hitch bracket outer surface, centering the hole in the block with the slot in the bracket, on both sides.
Pull wires (⑩) are used to feed fasteners through the frame during installation. Feed the 5/8 pull wire through the attachment hole and out of the access hole in the frame. Attach the spacer block (②) and 5/8 carriage bolt (①) to the pull wire, then pull the fasteners inside the frame at four locations. Keep pull wires attached to hardware and leave hardware inside the frame temporarily until the hitch is raised into position.
Raise the hitch into position by feeding the end of the pull wires through the holes in the hitch, then pull the fasteners into position. Carefully remove the pull wires and loosely install the conical washers (④) and hex nuts (⑤) onto the carriage bolts. Be careful to keep the carriage bolts from falling inside the frame. On the driver's side, hold the wiring harness away from the hitch during installation.
Using a 13 mm socket, reattach the ground wire using the M8 bolt (⑦), lock washer (⑧), and flat washer (⑨) provided. Bend or flatten the ground wire bracket if needed. See Figure 1 for reference.
Using a cable tie (⑪), reattach the wiring harness to the chassis near its original location. This is done after reinstalling the ground wire.
Tighten all 5/8-11 Gr5 fasteners with a torque wrench to 150 Lb.-Ft. (203 N·m). Proper torque is needed to keep the hitch secure to the vehicle when towing.
Tighten all M8 CL8.8 fasteners with a torque wrench to 20 Lb.-Ft. (27 N·m).
Always wear safety glasses when installing the hitch. Observe safety precautions when working beneath a vehicle and wear eye protection. Do not cut access or attachment holes with a torch. Be careful to keep carriage bolts from falling inside the frame during installation.
Key towing safety warnings: Always wear your seatbelt; slow down when towing and never exceed posted speed limits; load the trailer heavier in front; do not exceed the lower of your towing vehicle manufacturer's rating or the hitch rating; if excess sway occurs, take your foot off the gas pedal and hold the steering wheel as steady as possible—do not apply brakes and do not speed up.
No. Do not cut, weld, or modify the receiver. Doing so may compromise the structural integrity and safety of the hitch.
Check that all fasteners are tight and the hitch is securely mounted to the vehicle. Check hitch frequently, making sure all fasteners and ball are properly tightened. Proper torque is needed to keep the hitch secure to the vehicle when towing.
Check the hitch frequently, making sure all fasteners and ball are properly tightened. The manual does not specify an exact interval, but periodic checks are essential to ensure the hitch remains securely mounted to the vehicle during towing.
If the hitch is removed, plug all holes in the trunk pan or other body panels to prevent entry of water and exhaust fumes.
A hitch or ball which has been damaged should be removed and replaced. Do not continue to use a damaged hitch.
Yes, the 41954 is designed for Ford F150 models from 2015 to current. Visit the manufacturer's website for the most up-to-date information on specific trim levels and application years.
Weight Carrying: 11,000 lb. (4,990 kg) max gross trailer weight, 1,100 lb. (499 kg) max tongue weight. Weight Distributing: 14,000 lb. (6,350 kg) max gross trailer weight, 1,400 lb. (635 kg) max tongue weight. Do not exceed the lower of your vehicle manufacturer's rating or these limits.
Required tools: 10 mm socket, 13 mm socket, 15/16" socket, 6" socket extension, ratchet, torque wrench, safety glasses, flat head screwdriver, and masking tape.
Yes, lower the spare tire before installation and raise it back to its original stowed position after installation is complete.
5/8-11 Gr5 carriage bolts: 150 Lb.-Ft. (203 N·m). M8 CL8.8 ground wire bolt: 20 Lb.-Ft. (27 N·m). Use a torque wrench for proper tightening.
Always wear safety glasses during installation. Do not cut, weld, or modify the receiver. Always wear your seatbelt when towing. Slow down when towing and never exceed posted speed limits. Load the trailer heavier in front. If excess sway occurs, take your foot off the gas and hold the steering wheel steady—do not brake or speed up.
Yes, a compatible bike rack, cargo carrier or other accessory with a 2" x 2" shank can generally be used. Make sure the accessory does not exceed the hitch’s tongue weight rating, the vehicle’s limits or the accessory manufacturer’s capacity. Account for the combined weight of the carrier and everything loaded onto it.
