Want to take the family on a cross-country adventure? Or perhaps you're planning a shorter trip to your favorite campground. Whatever your destination, it's important to have the right equipment, especially when towing a fifth wheel trailer. To ensure proper hookup and safety while towing, you'll need something to attach your fifth wheel hitch in the bed on your truck. Many pickups come equipped with factory-installed rails or puck systems, but if you don't have one of these already installed, don't worry. REESE has an extensive line of mounting rails and bracket kits, custom-made to the exact specifications needed based on your truck's year, make, and model. REESE also offers several Industry Standard designs, as well as fastener kits, spacer kits, and a Power Puck mounting kit, so you can be sure you're covered, no matter what pickup you're using to tow. So make it easy. Make it fun. Make it REESE, so you can make the journey as enjoyable as the destination.
| BRAND: | REESE |
| PART NUMBER: | 56015-53 |
| WARRANTY: | LIMITED LIFETIME WARRANTY |
| WEIGHT: | 89.68 LBS |
| UNIVERSAL OR SPECIFIC FIT: | SPECIFIC |
| WELDING REQUIRED: | NO |
| MOUNTING HARDWARE INCLUDED: | YES |
| RAILS INCLUDED: | YES |
| DRILLING REQUIRED: | YES |
| MATERIAL: | STEEL |
| BOLT GRADE: | Grade 8 |
| LOCKABLE: | NO |
| COLOR: | BLACK |
Reese has designed towing equipment since 1952 and remains a benchmark for heavy-duty towing. The line covers fifth wheel hitches such as the modular M5, gooseneck couplers including the Goose Box, air-ride and short-bed pin boxes, weight distribution systems with active sway control, and the accessories that connect them, all built to exceed published industry standards.
Reese has been pioneering towing performance since 1952, when Margaret Reese asked her husband TJ to stop travel trailers rocking every time somebody walked through them. His answer, the first pair of stabilising jacks, was simple and effective enough to change the RV industry. From that starting point Reese grew into a designer and manufacturer of complete towing systems, and today it anchors the heavy-duty end of the Horizon Global towing portfolio.
Fifth wheel towing is where the brand's engineering is most visible. The M5 fifth wheel hitch uses a modular design that breaks into manageable sections for assembly, with a wider stance, tighter tolerances and a shock absorption system aimed at the jolts that travel up through a truck bed. For owners who would rather tow from a gooseneck coupler and keep the bed clear, the Goose Box 20K replaces the trailer's king pin with a gooseneck connection carrying its own air-ride cushioning.
Pin boxes are a Reese speciality. The 5th Airborne uses air-ride technology to dampen road shock and reduce the chucking motion that makes fifth wheel towing tiring, while the Sidewinder was designed for short-bed pickups, pivoting the connection point so the trailer can turn sharply without the front cap meeting the cab.
For conventional towing, Reese weight distribution systems restore load to the tow vehicle's front axle and control sway. The Pro Round Bar distributes weight evenly while damping sway, and the Pro Dual Cam II uses active cam-based sway control that works harder the stronger the sway force becomes. Complete kits pair bars, head and shank to a rated tongue weight, and dedicated sway control kits can be added to existing setups. The products suit RV owners, horse and livestock haulers and anyone towing near the upper end of a vehicle's rating.
Experts available to answer your questions
Call 888-634-9494Lifetime
Yes, the Reese Fifth Wheel Hitch Mounting System Custom Install Kit, Outboard RE56015-53 (Part #RE56015-53) is designed to fit the 2019-2024 Chevrolet Silverado 1500.
The Reese Fifth Wheel Hitch Mounting System Custom Install Kit, Outboard RE56015-53 (Part #RE56015-53) fits the following vehicles: 2019-2024 Chevrolet Silverado 1500; 2019-2024 GMC Sierra 1500. Always verify your specific year, make, and model before ordering.
The Reese Fifth Wheel Hitch Mounting System Custom Install Kit, Outboard RE56015-53 (Part #RE56015-53) fits 2019-2024 Chevrolet Silverado 1500 models. The 2024 model year is the last year covered by this part number. For newer models, check for an updated version.
The Reese Fifth Wheel Hitch Mounting System Custom Install Kit, Outboard RE56015-53 (Part #RE56015-53) Drilling is required for installation. Basic hand tools are typically all you need.
The 56015 is designed for GMC/Chevy 1500 Pickup trucks, but fitment depends on the specific year and model. Check the REESE website or contact the manufacturer at 1-800-632-3290 to confirm your truck's year and bed length are compatible. The kit is designed for 5.5' and 6.5' truck beds.
The 56015 can be installed on a 5.5' bed truck, but only if your trailer is equipped with a sidewinder pinbox coupler. Do not install this product on or attempt to tow with a truck with a 5.5' bed unless a sidewinder pinbox coupler has been installed on the trailer.
The 56015 Custom Quick Install Mounting Kit is designed exclusively for the 30153 REESE® Rails only. It must be used with REESE Series Custom mounting kits (part 56000 series only). The kit cannot be used with other rail systems.
The 56015 kit includes: 1 Driver Side Frame Bracket, 1 Passenger Side Frame Bracket, 4 × 1/2"-13 U-Bolts (Grade 5), 10 × 1/2"-13 Nuts (Grade 8), 10 × 1/2" Conical Washers, 2 × 1/2"-13 × 1.75" Carriage Bolts (Grade 8), 2 × 1"×3" Blocks, 2 × 1"×2" Blocks, 2 × 1.5"×2" Blocks, 2 × 3.5"×1.5" Blocks, and 1 × 1/2" Pull Wire. Additional hardware is supplied with the 30153 rail kit.
Required tools are: 3/4" wrenches, 1/8" and 9/56" drill bits, a center punch, a measuring tape, a torque wrench, and a 3/4" crows foot attachment for the torque wrench. The fastener kit 56015F must also be obtained.
Yes. After drilling the initial 1/8" holes in the truck bed and marking the frame bracket positions, you must raise the rear of the vehicle and remove both rear tires before proceeding with bracket installation.
No. Do not install mounting rails over plastic bed liners. Plastic bed liners must be cut out of the way to provide metal-to-metal contact. Mounting rails may be installed on spray-in liners, but you should consult the installer for the recommended curing time before installation.
Yes. You must drill two sets of holes in the truck bed: first, 1/8" pilot holes to verify alignment with the frame brackets, then enlarge those holes to 9/16" for the final installation. Before drilling, verify what is below the truck bed in those locations to avoid damaging components underneath.
First drill 1/8" pilot holes to check alignment with the frame brackets. Once alignment is verified and the brackets are removed, enlarge the holes to 9/56" for final installation. Do not enlarge the holes while the brackets are in place.
Center the front mounting rail on the floor of the truck bed. Use a tape measure to locate the proper distance from the rear of the rail to the rear edge of the truck box as illustrated on page 3 of the instructions (24-13/16" from the rear edge for typical 5.5'/6.5' truck beds). Repeat the positioning process for the rear rail. Ensure the mounting rail is centered on the bed to position the 5th wheel correctly.
Temporarily position the frame brackets on the sides of the frame, aligning the center hole in the bracket with the existing slot in the truck frame. Check that the 1/8" drilled holes align with the slots in the frame brackets. To install, tilt the brackets at 45° to clear the leading edge of the bed hem seam, then lay them flat against the frame rail. After verifying fitment, remove the brackets and enlarge the holes to 9/56" before final installation.
When fastening the frame brackets to the frame using U-bolts, place the 3.5"×1.5" block (Item 7) behind the bracket as a spacer, with the U-bolt passing through the bottom hole. When installing the center bolt, use the 1.5"×2" block (Item 9) between the frame and the frame bracket. For the final center bolt installation through the bed, use the 1"×2" block (Item 10) on the bottom side of the bed floor.
Thread the supplied pull wire onto the supplied carriage bolt (Item 8), followed by the 1"×3" block (Item 9). Pull both components through the center slot on the frame, ensuring the 1.5"×2" block is positioned between the frame and the frame bracket. Place the conical washer (Item 5) on the bolt and secure with a nut (Item 4). The supplied pull wire must be used on both sides. Hand tighten initially, then torque to specification after all other fasteners are tightened.
Yes. When repositioning the mounting rails over the holes in the bed, use the U-shaped blocks between the frame bracket or mounting rails and the truck bed to ensure metal-to-metal contact. This is essential for proper load transfer and system integrity.
First, tighten the U-bolts snug to keep the brackets from moving (Step 6). Then, after repositioning the mounting rails and installing the center bolt, hand tighten the center bolt (Step 10). Finally, starting with the hardware that fastens the mounting brackets to the bed rails, torque all nuts to specification: 1/2" Grade 8 bolts to 110 ft-lbs (149 N·m), and 1/2" U-bolts to 75 ft-lbs (101 N·m) (Step 11).
Torque the 1/2" Grade 8 bolts to 110 ft-lbs (149 N·m). This applies to the hardware that fastens the mounting brackets to the bed rails.
Torque the 1/2" U-bolts to 75 ft-lbs (101 N·m). U-bolts must be tightened evenly to ensure proper load distribution.
All bolts and nuts in the 56015 kit are Grade 8 unless otherwise specified. The U-bolts (Item 3) are Grade 5. Only the supplied bolts, nuts and washers must be used for installation; do not substitute with other hardware.
Do not exceed the towing vehicle manufacturer's recommended vehicle towing capacity, or the lowest rated component of your system. Refer to the rail label and rail markings for the correct weight capacity of the 30153 REESE® Rails.
Yes. Always measure your truck and trailer before installing the hitch to ensure there is clearance at the cab and at the bumper to allow for turns. This is the responsibility of the installer and owner.
After installation, verify that all fasteners are torqued to specification (1/2" Grade 8 bolts to 110 ft-lbs, 1/2" U-bolts to 75 ft-lbs). Ensure the mounting rails are centered on the truck bed and that the 5th wheel has a snug fit. Check that clearance exists at the cab and bumper for turns.
Check the mounting system bolt tightness once per year. This is an owner responsibility to ensure the system remains secure and safe for towing.
The 56015 is designed for GMC/Chevy 1500 Pickup trucks with 5.5' or 6.5' beds. Check the REESE website or call 1-800-632-3290 to confirm your specific year and model are compatible. For 5.5' beds, your trailer must have a sidewinder pinbox coupler.
You need: 3/4" wrenches, 1/8" and 9/56" drill bits, a center punch, measuring tape, torque wrench with 3/4" crows foot, and fastener kit 56015F. You will also need to remove both rear tires.
Yes. You must drill 1/8" pilot holes in the truck bed to verify alignment, then enlarge them to 9/56" for final installation. Verify what is below the bed before drilling.
No. Plastic bed liners must be cut away to provide metal-to-metal contact. Spray-in liners may be used if cured per installer recommendations.
Torque 1/2" Grade 8 bolts to 110 ft-lbs (149 N·m) and 1/2" U-bolts to 75 ft-lbs (101 N·m). Tighten U-bolts evenly.
Do not exceed your vehicle manufacturer's towing capacity or the lowest rated component. Refer to the 30153 rail label for the weight capacity.
Check all mounting system bolt tightness once per year. Ensure fasteners remain at specification torque.
If the holes do not align, restart the installation at step 1 by adjusting the 1/8" holes on the truck bed. Do not enlarge the holes to 9/56" until alignment is verified. Remove the frame brackets before enlarging the holes. Reposition the mounting rail to ensure it is centered on the truck bed floor and measure the correct distance from the rear of the rail to the rear edge of the truck box.
To install the brackets, they must be tilted in at a 45° angle to clear the leading edge of the bed hem seam, then laid flat against the frame rail. If the bracket is not lying flat after this procedure, verify that the center hole in the bracket is properly aligned with the existing slot in the truck frame, and that the 1/8" drilled holes align with the slots in the frame brackets.
Yes. Deflection in the bracket below the vehicle frame is expected and acceptable. This is a normal characteristic of the system design. However, ensure that U-bolts are tightened evenly and to the correct specification (75 ft-lbs for 1/2" U-bolts) to maintain proper load distribution.
2 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2019 - 2024 | Chevrolet Silverado 1500 | Fifth Wheel Trailer Hitch Install Kit Drilling Required Install Time is 0 minutes Outboard Bracket & Rail Kit Models with Adaptive Ride Control |
| 2019 - 2024 | GMC Sierra 1500 | Fifth Wheel Trailer Hitch Install Kit Drilling Required Install Time is 0 minutes Outboard Bracket & Rail Kit |
