1. Custom-Designed Fit: Each Blue Ox BX1128 Tow Bar Bracket is engineered specifically for each towed vehicle, ensuring a perfect fit and superior performance.
Material: Steel
Color: Black
Finish: Powder Coat
Mounting Type: Bolt On
Mounting Hardware Included Yes/No: Yes
The Blue Ox BX1128 Tow Bar Bracket is a robust and reliable towing solution designed to serve you for years. Expertly crafted from high-quality steel, it's finished with a durable, black powder coat to ensure maximum resistance against rust and corrosion. This custom-designed base plate comes with all the necessary hardware and comprehensive instructions for a hassle-free, DIY installation. Its bolt-on mounting type makes it easy to attach to any specific towed vehicle, providing you with the ultimate towing experience.
Blue Ox is known internationally for recreational and commercial towing products, manufacturing in Pender, Nebraska since 1925. The line covers tow bars and vehicle-specific baseplates for flat towing behind a motorhome, sway control and weight distributing hitches, supplemental braking accessories and towing wiring, backed by patented designs and long-standing customer service.
Blue Ox has manufactured since 1925 and is recognised internationally for towing products and customer service. The company operates from Pender, Nebraska, where it grew out of Automatic Manufacturing Co., a business that started with cattle oilers and developed into agricultural equipment, tractor accessories and trailer towing hardware. That agricultural engineering heritage still shows in how the towing products are built, and the company holds patents across weight distribution, fifth wheel and tow bar designs.
Flat towing is the discipline Blue Ox is best known for. Towing a car with all four wheels on the ground behind a motorhome demands a system that stays rigid under braking, articulates properly over uneven ground, and connects to the towed vehicle at points strong enough to take the load. Blue Ox tow bars handle the first two, with self-aligning arms that latch under tension and release without a struggle when the load is off them. Vehicle-specific baseplates handle the third, engineered per make and model to tie into structural mounting points behind the fascia.
The wider flat towing range covers supplemental braking systems, safety cables and the accessories that make a complete legal setup, along with baseplate wiring and dinghy towing harnesses that pass lighting signals to the towed vehicle without back-feeding its electrical system.
For conventional trailer towing, Blue Ox weight distributing hitches with integrated sway control transfer tongue load onto the tow vehicle's front axle and resist the yaw that crosswinds and passing trucks induce.
The company describes its foundation as customer service, designing around what owners actually ask for, and it runs an RV park adjacent to the factory where customers can stay. Sister operations at the same Nebraska site include Automatic grain roller mills and MAD-RAMPS pivoting ramp systems.
Experts available to answer your questions
Call 888-634-94943 Years
5 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2011 - 2013 | Dodge Durango | Comes with Removable Attachment Tabs Install Rating 3 Vehicles With Adaptive Cruise Control Baseplate Has Non 24 in. Spaced Attachment Tabs Bumper Fascia Must Be Removed/Replaced During Install Minor Drilling Required Only Use Acclaim w/23in./Greater Spaced Tab Removable Tab Baseplates Only Use Adventurer w/16: 36 in. Spaced Removable Tab Baseplates Only Use Ambassador w/24 in. Spaced Removable Tabs PN BX88152 Adapter Can Not Be Used w/This Baseplate Removable Tabs w/Only 1 Hole Will Not Attach To Car Mount Tow Bars Removable Tabs w/Only 1 Hole Will Not Attach To Other Adapters Req. Motorhome Mounted Towbar/Adapter To Utilize Car Mounted Tow Bar Requires Some Trimming Of Bumper Fascia/Plastic/And/Or Grill Tow Bar Adapters Not To Be Used On Vehicles Over 5000 lbs. Tow Hooks Must Be Removed And Remain Off After Install Use only w/Motorhome Mount Tow Bars Or PN BX8833/BX88151 Adapters |
| 2012 | Dodge Durango | Comes with Removable Attachment Tabs Install Rating 3 Vehicles With Adaptive Cruise Control. Baseplate Has Non 24 in. Spaced Attachment Tabs Bumper Fascia Must Be Removed/Replaced During Install Minor Drilling Required Only Use Acclaim w/23in./Greater Spaced Tab Removable Tab Baseplates Only Use Adventurer w/16: 36 in. Spaced Removable Tab Baseplates Only Use Ambassador w/24 in. Spaced Removable Tabs PN BX88152 Adapter Can Not Be Used w/This Baseplate Removable Tabs w/Only 1 Hole Will Not Attach To Car Mount Tow Bars Removable Tabs w/Only 1 Hole Will Not Attach To Other Adapters Req. Motorhome Mounted Towbar/Adapter To Utilize Car Mounted Tow Bar Requires Some Trimming Of Bumper Fascia/Plastic/And/Or Grill Tow Bar Adapters Not To Be Used On Vehicles Over 5000 lbs. Tow Hooks Must Be Removed And Remain Off After Install Use only w/Motorhome Mount Tow Bars Or PN BX8833/BX88151 Adapters |
| 2011 - 2021 | Jeep Grand Cherokee | Vehicles With Adaptive Cruise Control For Use w/Quadra Trac/Drive II Comes with Removable Attachment Tabs Install Rating 3 Bumper Fascia Must Be Removed/Replaced During Install Requires Some Trimming of Bumper Fascia/Plastic/And/Or Grill Minor Drilling Required Tow Hooks Must be Removed and Remain off the Vehicle After Installation Baseplate Has Non 24 in. Spaced Attachment Tabs Requires Motorhome Mounted Tow Bar/Adapter To Utilize Car Mounted Tow Bar Tow Bar Adapters Not To Be Used On Vehicles Over 5000 lbs Use only w/Motorhome Mount Tow Bars Or PN BX8833/BX88151 Adapters Only Use Acclaim w/23”: 30” Spaced Removable Tab Baseplates Only Use Adventurer with 18”: 41” Spaced Removable Tab Baseplates Removable Tabs w/Only 1 Hole Will Not Attach to Car Mount Tow Bars or Adapters Due to the Design of the Baseplate, the Adventurer Tow Bar Can Not be Used with the Baseplate |
| 2022 | Jeep Grand Cherokee WK | No L or WL Vehicles With Adaptive Cruise Control For Use w/Quadra Trac/Drive II Comes with Removable Attachment Tabs Install Rating 3 Bumper Fascia Must Be Removed/Replaced During Install Requires Some Trimming of Bumper Fascia/Plastic/And/Or Grill Minor Drilling Required Tow Hooks Must be Removed and Remain off the Vehicle After Installation Baseplate Has Non 24 in. Spaced Attachment Tabs Requires Motorhome Mounted Tow Bar/Adapter To Utilize Car Mounted Tow Bar Tow Bar Adapters Not To Be Used On Vehicles Over 5000 lbs Use only w/Motorhome Mount Tow Bars Or PN BX8833/BX88151 Adapters Only Use Acclaim w/23”: 30” Spaced Removable Tab Baseplates Only Use Adventurer with 18”: 41” Spaced Removable Tab Baseplates Removable Tabs w/Only 1 Hole Will Not Attach to Car Mount Tow Bars or Adapters Due to the Design of the Baseplate, the Adventurer Tow Bar Can Not be Used with the Baseplate |
| 2022 | Jeep Grand Cherokee WK | Vehicles With Adaptive Cruise Control, For Use w/Quadra Trac/Drive II, Comes with Removable Attachment Tabs, Install Rating 3, Bumper Fascia Must Be Removed/Replaced During Install, Requires Some Trimming of Bumper/Fascia/Plastic/And/Or Grill, Minor Drilling Required, Tow Hooks Must be Removed and Remain off the Vehicle After Installation, Baseplate Has Non 24 in. Spaced Attachment Tabs, Requires Motorhome Mounted Tow Bar/Adapter To Utilize Car Mounted Tow Bar, Tow Bar Adapters Not To Be Used On Vehicles Over 5000 lbs., Use only w/Motorhome Mount Tow Bars Or PN BX8833/BX88151 Adapters, Only Use Acclaim w/23”: 30” Spaced Removable Tab Baseplates, Only Use Adventurer with 18”-41” Spaced Removable Tab Baseplates, Removable Tabs w/Only 1 Hole Will Not Attach to Car Mount Tow Bars or Adapters, Due to the Design of the Baseplate, the Adventurer Tow Bar Can Not be Used with the Baseplate |
The BlueOx Base Plate, Jeep Grand Cherokee BX1128 (Part #FDRWBX1128) fits 2011-2013 Dodge Durango models. The 2022 model year is the last year covered by this part number. For newer models, check for an updated version.
The BlueOx Base Plate, Jeep Grand Cherokee BX1128 (Part #FDRWBX1128) fits the following vehicles: 2011-2013 Dodge Durango; 2011-2021 Jeep Grand Cherokee; 2022 Jeep Grand Cherokee WK. Always verify your specific year, make, and model before ordering.
Yes, the BlueOx Base Plate, Jeep Grand Cherokee BX1128 (Part #FDRWBX1128) is designed to fit the 2011-2013 Dodge Durango.
The BlueOx Base Plate, Jeep Grand Cherokee BX1128 (Part #FDRWBX1128) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
Yes, the BX1128 is designed for 2011-13 Dodge Durango. However, the manual notes that dimensional variations between otherwise identical vehicles can be considerable, and it may be necessary to tailor the baseplate slightly to compensate for vehicle manufacturer's tolerances. If the front of your vehicle looks different than shown in the manual, contact Blue Ox Technical Service at (402) 385-3051.
No. The BX1128 is designed for 2022 Jeep Grand Cherokee WK models only, and explicitly excludes L and WL variants. If you have a WL or L model, you will need a different baseplate.
Yes. The BX1128 is compatible with 2011-21 Jeep Grand Cherokee models equipped with Trail Rated and Adaptive Cruise Control features.
Only if your vehicle is equipped with tow hooks. The manual states that if equipped, tow hooks are removed for baseplate installation and not reinstalled. Vehicles without tow hooks do not require this step. The removal involves using a 16MM socket to remove two bolts from the front and a 30MM socket or wrench to remove the nut from the back of each tow hook.
Required tools include: large vise grip, flat screwdriver, utility knife, torque wrench, drill, plastic pop rivet gun, tape measure, Loctite Red, 1/4" and 3/8" drill bits, 8MM, 10MM, 13MM, 16MM, and 30MM sockets, 30MM wrench, and 9/16" socket and wrench.
The manual does not specify whether the BX8869 Tail Light Wiring Kit is included. The manual states that the kit is recommended for this vehicle and instructs to drill a hole according to the tail light wiring kit instructions, but does not confirm whether it comes with the baseplate or must be purchased separately. Contact your Blue Ox Dealer for clarification.
Blue Ox recommends that towing products be installed by Blue Ox Dealers who are familiar with the products and have the equipment and knowledge necessary to do fit work. However, the manual does not explicitly state that professional installation is mandatory. If you choose to install it yourself, you must have the required tools, knowledge of the procedures, and ability to perform drilling, trimming, and torque specifications. Blue Ox Dealers can be found at www.blueox.com or by contacting (402) 385-3051.
The following components must be removed and reinstalled: fascia (front bumper cover), lower plastic shielding (if equipped), windshield washer fluid reservoir, and tow hooks (if equipped). The manual states that the fascia, plastic shielding, and washer reservoir are removed and reinstalled for baseplate installation. All removed items will be reinstalled unless otherwise noted after the baseplate is installed.
Yes. The manual provides separate fascia removal procedures for 2011-13 Dodge Durango and Jeep Grand Cherokee models versus 2014 and up Jeep Grand Cherokee models. The 2014+ procedure includes additional steps for headlight sprayers on some models and notes that Summit/High Altitude models require pushing in on corners to release clips before pulling downward and out.
The installation sequence depends on whether your vehicle is equipped with tow hooks. For vehicles with tow hooks: slide the baseplate into position, install two 10MM-1.5 x 80MM bolts with 10MM lock washers and 3/8" washers into bottom holes, install 3/4"Ø x 1-23/32" spacer tubes with 10MM-1.5 x 100MM bolts, 10MM lock and flat washers into front holes, then tighten all hardware. For vehicles without tow hooks: slide baseplate into position, install two 3/4"Ø x 2-3/4" spacer tubes into front holes, install two 10MM-1.5 x 80MM bolts with 10MM lock washers and 3/8" washers into bottom holes, insert 3/8"-16 x 4-1/2" bolts with 3/8" lock washers into front holes with spacer plate and 3/8"-16 nuts on top of bumper, then tighten all hardware. Do this on both sides of the vehicle.
With the taper facing the front, install the support plate onto the baseplate. Insert 3/8"-16 x 1-1/2" bolts with 3/8" lock and flat washers into the holes and the 3/8" nut plates on the inside of the baseplate. Flush the top of the plate with the frame and tighten all hardware. Do this on both sides of the vehicle. Then, using a 3/8" drill bit, drill the top two holes of the support plate through the frame. Install 3/8"-16 x 1-1/4" bolts with 3/8" lock washers and 3/8"-16 lock nuts, and fully tighten all hardware on both sides.
Attach the permanent baseplate safety cables to the provided convenience link on the baseplate. The manual shows the recommended installation of the cables to the frame of the vehicle. Additional options may interfere with suggested mounting; in that case, secure the cables to a solid piece of the frame. Be sure the safety cables do not rub against any hoses or moving parts. Do this on both sides of the vehicle. The cables must be connected from the baseplate to the frame rail or cross member of the vehicle's frame, and must not be mounted against wires, hoses, or brake lines.
Loosely reinstall the compressor, checking for clearance around the baseplate. If needed, shim the compressor away from the baseplate with 5/16" washers. This will keep the compressor from vibrating against the baseplate.
Measure approximately 7" from the convenience link or choose your desired location. Install the bracket to the bumper with a #10-16 x 1" self-drilling screw. Attach the breakaway to the bracket with a 1/4"-20 x 3/4" bolt and 1/4"-20 lock nut.
Install the electrical bracket to the fascia at your desired location and bend it to the desired angle. Using a 1/4" drill bit, drill out the two mounting holes through the fascia and attach the bracket to the fascia with 1/4"-20 x 3/4" bolts and 1/4"-20 lock nuts.
Hold the fascia as close to its original position as possible, mark and trim the fascia around the convenience links and attachment tabs. Reinstall the fascia. Using the plastic pop rivet gun, replace the two rivets in the wheel well on both sides of the vehicle. Note: Summit/High Altitude models have a different style fascia with no tow hook pockets. It is recommended to trim a preliminary area approximately the size shown or smaller and test fit/trim as needed to fit around the convenience links and attachment tabs.
Yes. Drilling is required in two locations: (1) a hole must be drilled according to the BX8869 Tail Light Wiring Kit instructions, and (2) the top two holes of the support plate must be drilled through the frame using a 3/8" drill bit. Additionally, two 1/4" holes must be drilled through the fascia for the electrical bracket mounting. The manual warns to be aware of the dangers of torque and drill bit length when using power drills.
Yes. The fascia must be trimmed around the convenience links and attachment tabs. The manual instructs to hold the fascia as close to its original position as possible, mark and trim the fascia around these components. For Summit/High Altitude models, it is recommended to trim a preliminary area approximately the size shown or smaller and test fit/trim as needed. This is a permanent modification to the fascia.
Two drill bit sizes are required: 1/4" and 3/8". The 1/4" bit is used to drill mounting holes through the fascia for the electrical bracket. The 3/8" bit is used to drill the top two holes of the support plate through the frame.
The manual provides a general torque chart for metric and inch bolts by grade, but does not specify the exact grade or torque value for each individual bolt used in the BX1128 installation. The chart shows: for 10MM Grade 8.8 bolts, 31 ft-lbs; for 10MM Grade 10.9 bolts, 40 ft-lbs; for 3/8" Grade 5 bolts, 33 ft-lbs; for 3/8" Grade 8 bolts, 47 ft-lbs. The manual emphasizes using Loctite Red on all bolt threads and tightening all bolts according to the torque chart provided. Consult the parts list to determine the grade of each bolt used.
The attachment tab height is 17-1/2" and the attachment tab width is 34-3/4".
Two spacer tube sizes are used: 3/4"Ø x 1-23/32" (used with vehicles equipped with tow hooks) and 3/4"Ø x 2-3/4" (used with vehicles without tow hooks). Four of each size are included in the hardware kit.
Failure to read and follow the installation instructions could result in separation of the towed vehicle from the tow bar, causing property damage, loss of towed vehicle, personal injury or death. The baseplate is computer tested to your vehicle's GVWR; exceeding this weight will void the manufacturer's warranty. If the baseplate is involved in an accident, it must be replaced and not reused, as an accident can cause unseen damage that could result in more damage or serious injury. Do not use the baseplate if it is damaged or missing parts.
Permanent baseplate safety cables are strongly recommended when towing a vehicle with a tow bar. Their principle function is to prevent the towed vehicle from breaking loose in the event the connection between the frame of the towed vehicle and the baseplate fails or becomes disconnected. However, these cables must be used in conjunction with, and NOT as a replacement for, legally required safety cables attaching the towed vehicle to the towing vehicle. Each cable must have an adequate weight rating for the towing system; the weight rating of the two cables together will not qualify.
Do not mount the permanent baseplate safety cables against wires, hoses, or brake lines. Be sure the safety cables do not rub against any hoses or moving parts. If the baseplate is improperly installed and is against a wire or hose, it could cause fluid leaks or electrical shorts some time after the actual baseplate installation.
Remove the attachment tabs when not in use, if applicable.
Be sure that all electrical connections are plugged in and accessories are functioning properly before reinstalling the fascia. This ensures that any electrical components removed during fascia removal are properly reconnected and operational.
After installation, verify that all bolts are tightened to the correct torque specifications using Loctite Red. Check that the support plate is flush with the frame. Verify that the permanent baseplate safety cables do not rub against any hoses or moving parts. Ensure the compressor has adequate clearance around the baseplate. Confirm that all electrical connections are functioning properly. It is the owner's responsibility to inspect all towing equipment for cracked welds, missing or worn parts, and loose bolts before each towing trip.
It is the owner's responsibility to inspect all towing equipment for cracked welds, missing or worn parts, and loose bolts before each towing trip. Be sure to use Loctite Red on all bolts and tighten to the recommended specifications. Use a good quality paint to spray cut edges of frame to prevent rusting. Permanent baseplate safety cables should remain installed as long as the baseplate is installed on the vehicle.
The hardware kit includes: 4 nut plates with 14" wire, 2 support plates, 2 spacer plates, 2 breakaway brackets, 4 spacer tubes (3/4"Ø x 1-23/32"), 4 spacer tubes (3/4"Ø x 2-3/4"), 1 electrical bracket, various bolts (1/4"-20, 3/8"-16, 10MM), nuts, washers, lock washers, 2 Class IV safety cables, 2 1/2" quicklinks, 4 plastic rivets, and 2 black cap plug receivers. See the parts list on page 4 for complete details.
No. If a bolt is lost or in need of replacement, you must use a replacement bolt of the same grade. In most cases it will be Grade 5. Refer to the parts list to determine the grade of the bolt you need to replace. Use only genuine factory replacement parts on your baseplate. Do not substitute homemade or non-typical parts. Replacement parts may be ordered through your nearest Blue Ox Dealer or Distributor. Failing to follow this requirement will void the manufacturer's warranty.
Blue Ox provides a three-year limited warranty to the original retail purchaser. The product is warranted to be free from defect in material and workmanship under normal use and service for three years from the date of delivery. During this period, Blue Ox will repair or replace any parts found to be defective if returned to the factory, transportation prepaid. Coverage is valid only if the customer warranty card is returned within 30 days of purchase and a copy of the original invoice accompanies any claim. The warranty is non-transferable and does not cover incorrect or improper installation, improper use, modification, neglect, failure to properly service and maintain, misuse, accident, normal wear and tear, paint or rust. Register your warranty at http://blueox.com/warranty/.
The warranty is voided by: exceeding your vehicle's GVWR, incorrect or improper installation, improper use, modification or neglect of product, failure to properly service and maintain, misuse, accident, failure to follow guidelines in the instructional material, towing behind a non-motorized vehicle, or using a baseplate that has been involved in an accident. The warranty also does not cover normal wear and tear, paint or rust.
Contact Blue Ox Technical Service Department at (402) 385-3051. You can also visit www.blueox.com to find a Blue Ox Dealer or to access the latest version of installation instructions. Blue Ox is committed to providing exceptional customer care and their technical service team is available to assist with any questions regarding product performance.
The BX1128 fits 2011-13 Dodge Durango, 2011-21 Jeep Grand Cherokee (excluding L and WL models), and 2022 Jeep Grand Cherokee WK (excluding L and WL). If your vehicle looks different than shown in the manual, contact Blue Ox at (402) 385-3051.
You need: torque wrench, drill with 1/4" and 3/8" bits, sockets (8MM, 10MM, 13MM, 16MM, 30MM), wrenches (30MM, 9/16"), utility knife, flat screwdriver, vise grip, tape measure, plastic pop rivet gun, and Loctite Red.
Yes. You must drill a hole for the tail light wiring kit, drill the top two support plate holes through the frame using a 3/8" bit, and drill two 1/4" holes through the fascia for the electrical bracket.
Yes. The fascia must be trimmed around the convenience links and attachment tabs. For Summit/High Altitude models, trim a preliminary area approximately the size shown and test fit as needed.
The manual provides a torque chart: 10MM Grade 8.8 bolts = 31 ft-lbs, 10MM Grade 10.9 bolts = 40 ft-lbs, 3/8" Grade 5 bolts = 33 ft-lbs, 3/8" Grade 8 bolts = 47 ft-lbs. Use Loctite Red on all bolt threads before tightening.
If the baseplate is in an accident, it must be replaced. Do not reuse it, as an accident can cause unseen damage that could result in more damage or serious injury.
Before each towing trip, inspect all towing equipment for cracked welds, missing or worn parts, and loose bolts. Use Loctite Red on all bolts and tighten to the recommended specifications. Paint cut frame edges to prevent rusting.
If the compressor vibrates against the baseplate, loosen the compressor mounting bolts and shim the compressor away from the baseplate using 5/16" washers. This will keep the compressor from vibrating against the baseplate. Retighten the mounting bolts after shimming.
If the fascia does not fit properly, hold it as close to its original position as possible and check that you have trimmed adequately around the convenience links and attachment tabs. For Summit/High Altitude models, it is recommended to trim a preliminary area approximately the size shown or smaller and test fit/trim as needed. Trim additional material as necessary until the fascia fits properly.
Check that all electrical connections are properly plugged in. Verify that all connectors are fully seated and that no wires were pinched or damaged during fascia removal and reinstallation. If a connector was disconnected during removal, ensure it is reconnected to the correct component. If the problem persists, consult your vehicle owner's manual or contact a qualified technician.
