Custom Designed For Your Vehicle
Material: Steel
Color: Black
Finish: Powder Coat
Mounting Type: Bolt On
Mounting Hardware Included Yes/No: Yes
Upgrade your towing setup with the Blue Ox BX1975 Tow Bar Bracket. Engineered with precision, this custom-designed base plate is perfect for every specific towed vehicle. Made from robust steel and finished with a black powder coating, this product ensures high durability and rust-resistance, providing a long-lasting solution for your towing needs. The bolt-on mounting type makes it easy to install, and with the included hardware, you have everything you need for a DIY installation. The Blue Ox BX1975 Tow Bar Bracket offers an unmatched combination of strength, convenience, and reliability.
Blue Ox is known internationally for recreational and commercial towing products, manufacturing in Pender, Nebraska since 1925. The line covers tow bars and vehicle-specific baseplates for flat towing behind a motorhome, sway control and weight distributing hitches, supplemental braking accessories and towing wiring, backed by patented designs and long-standing customer service.
Blue Ox has manufactured since 1925 and is recognised internationally for towing products and customer service. The company operates from Pender, Nebraska, where it grew out of Automatic Manufacturing Co., a business that started with cattle oilers and developed into agricultural equipment, tractor accessories and trailer towing hardware. That agricultural engineering heritage still shows in how the towing products are built, and the company holds patents across weight distribution, fifth wheel and tow bar designs.
Flat towing is the discipline Blue Ox is best known for. Towing a car with all four wheels on the ground behind a motorhome demands a system that stays rigid under braking, articulates properly over uneven ground, and connects to the towed vehicle at points strong enough to take the load. Blue Ox tow bars handle the first two, with self-aligning arms that latch under tension and release without a struggle when the load is off them. Vehicle-specific baseplates handle the third, engineered per make and model to tie into structural mounting points behind the fascia.
The wider flat towing range covers supplemental braking systems, safety cables and the accessories that make a complete legal setup, along with baseplate wiring and dinghy towing harnesses that pass lighting signals to the towed vehicle without back-feeding its electrical system.
For conventional trailer towing, Blue Ox weight distributing hitches with integrated sway control transfer tongue load onto the tow vehicle's front axle and resist the yaw that crosswinds and passing trucks induce.
The company describes its foundation as customer service, designing around what owners actually ask for, and it runs an RV park adjacent to the factory where customers can stay. Sister operations at the same Nebraska site include Automatic grain roller mills and MAD-RAMPS pivoting ramp systems.
Experts available to answer your questions
Call 888-634-94943 Years
Yes, the BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select, DODGE CALIBER E13 (Part #FDRWBX1975) is designed to fit the 2007-2012 Dodge Caliber.
The BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select, DODGE CALIBER E13 (Part #FDRWBX1975) fits 2007-2012 Dodge Caliber models. The 2012 model year is the last year covered by this part number. For newer models, check for an updated version.
The BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select, DODGE CALIBER E13 (Part #FDRWBX1975) fits the following vehicles: 2007-2012 Dodge Caliber. Always verify your specific year, make, and model before ordering.
The BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select, DODGE CALIBER E13 (Part #FDRWBX1975) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
Yes, the BX1975 baseplate is designed for 2007-12 Dodge Caliber vehicles. However, it does NOT fit SRT models. The manual notes that dimensional variations between otherwise identical vehicles can be considerable, so the baseplate may need slight tailoring to compensate for manufacturer tolerances.
The BX1975 baseplate has an attachment tab height of 15 inches and an attachment tab width of 24 inches.
Required tools include: T30 Torx, 7MM socket, 10MM socket, 13MM socket, 9/16" socket, 9/16" wrench, 13/32" drill bit, 1-1/4" hole saw, drill, reciprocating saw, torque wrench, large vise grip, flat screwdriver, Phillips screwdriver, utility knife, and tape measure. Loctite Red is also required.
Yes. The fascia and horn must be removed for baseplate installation and then reinstalled after the baseplate is mounted. The manual notes that handling of cosmetic parts may require protective covers, rags, and specialty tools to prevent damage.
Yes, drilling is required. You must drill a 1-1/4" access hole on the face of the frame above the bumper on both sides of the vehicle, and then drill four 13/32" holes through the frame on each side for baseplate mounting. The manual also recommends drilling a hole according to the BX8869 Tail Light Wiring Kit instructions.
Yes, trimming is required. Using a reciprocating saw, you must trim the end of the bumper flush with the frame on both sides, and trim the web 3/4" up from the tab back to the frame, then down flush with the frame on both sides. The manual also requires trimming around attachment tabs on the fascia during reinstallation.
According to the torque chart provided in the manual, 3/8"-16 Grade 5 bolts should be torqued to 33 foot-pounds. All bolts must be treated with Loctite Red before tightening.
On the driver side, install a 3/8"-16 x 1-1/2" bolt with 3/8" lock washer and 3/8"-16 nut. On the passenger side, install a 3/8"-16 x 1" bolt with 3/8" lock washer and 3/8"-16 nut. All fasteners must be treated with Loctite Red and tightened according to the torque chart.
On the driver side rear holes: install a 3/8"-16 x 1-1/2" bolt with 3/8" lock washer and 3/8" nut plate into each rear hole, using the access hole in front for the nut plates. On the lower middle hole, insert the spacer between the frame and baseplate, then install a 3/8"-16 x 1-3/4" bolt with 3/8" lock washer and 3/8"-16 nut. All fasteners must be treated with Loctite Red and tightened.
On the passenger side rear holes: install a 3/8"-16 x 1-1/2" bolt with 3/8" lock washer and 3/8" nut plate into the upper rear hole. Install a 3/8"-16 x 1-3/4" bolt with 3/8" lock washer and 3/8"-16 nut plate into the lower rear hole, using the access hole in front for the nut plates. On the lower middle hole, install a 3/8"-16 x 1" bolt with 3/8" lock washer and 3/8"-16 nut. All fasteners must be treated with Loctite Red and tightened.
When installing the baseplate, push the driver side up to the rear frame webbing, level the baseplate, and clamp it in place. The top of the baseplate crosstube should be approximately 1/4" from the bottom of the bumper.
Permanent baseplate safety cables are strongly recommended. They must be connected from the baseplate to the frame rail or cross member of the vehicle's frame. The cables must not be mounted against wires, hoses, or brake lines. These cables should remain installed as long as the baseplate is installed and must be used in conjunction with, not as a replacement for, legally required safety cables attaching the towed vehicle to the towing vehicle.
If the baseplate is in an accident, it must be replaced and not reused. An accident can cause unseen damage, and using it again could result in more damage or serious injury. Do not use the baseplate if it is damaged or missing parts.
No. Do not use the towed vehicle for storing luggage, equipment, or other items. This may cause you to exceed the towing capacity of the tow bar, baseplate, and its accessories.
Be sure that all electrical connections are plugged in and accessories are functioning properly before reinstalling the fascia. This includes verifying the horn and wiring harness are properly reconnected.
It is the owner's responsibility to inspect all towing equipment for cracked welds, missing or worn parts, and loose bolts before each towing trip. Be sure to use Loctite Red on all bolts and tighten them to the recommended specifications. Register your product online at www.blueox.com to be alerted of product offerings, updates, upgrades, maintenance and safety bulletins, and recalls.
The hardware kit includes: 1 BX1975 baseplate, 3 nut plates with 14" wire, 1 spacer plate, 2 bolts 3/8"-16 x 1", 4 bolts 3/8"-16 x 1-1/2", 2 bolts 3/8"-16 x 1-3/4", 8 lock washers 3/8", 5 hex nuts 3/8"-16, 2 self-drilling screws #12-14 x 1", 2 round slotted head screws #10-32 1/2", 2 lock washers #10, 2 hex nuts #10-32, 2 four-way connector adapters, 2 attachment tab assemblies with hole, 2 Class III safety cables, 2 quicklinks 3/8", and 2 black cap plug receivers.
The BX8869 Tail Light Wiring Kit is recommended for this vehicle. The manual states that a hole should be drilled according to the tail light wiring kit instructions.
Yes, the BX1975 is designed for 2007-12 Dodge Caliber (excluding SRT models). Dimensional variations between vehicles may require slight baseplate tailoring.
Essential tools include: reciprocating saw, drill with 13/32" and 1-1/4" bits, torque wrench, T30 Torx, 7MM/10MM/13MM sockets, and Loctite Red. A vise grip, screwdrivers, utility knife, and tape measure are also required.
Torque 3/8"-16 Grade 5 bolts to 33 foot-pounds. Apply Loctite Red to all bolts before tightening.
Permanent baseplate safety cables are strongly recommended and must be connected from the baseplate to the vehicle frame. They must not rub against hoses or moving parts and must be used with, not instead of, legally required safety cables.
If the baseplate is damaged or involved in an accident, it must be replaced immediately. Do not reuse a damaged baseplate, as unseen damage could cause separation during towing.
Before each towing trip, inspect for cracked welds, missing or worn parts, and loose bolts. Ensure all bolts are treated with Loctite Red and tightened to specification. Register your product at www.blueox.com for safety bulletins and recalls.
The manual notes that dimensional variations between otherwise identical vehicles can be considerable. If the baseplate does not sit level, it may be necessary to tailor the baseplate slightly to compensate for vehicle manufacturer's tolerances. Ensure the driver side is pushed up to the rear frame webbing and the baseplate is clamped in place before drilling. The top of the baseplate crosstube should be approximately 1/4" from the bottom of the bumper.
During fascia reinstallation, hold the fascia as close to its original position as possible, mark and trim around the attachment tabs on the backside of the fascia. This trimming allows the fascia to fit properly over the newly installed baseplate and attachment tabs.
1 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2007 - 2012 | Dodge Caliber | No SRT Comes with Removable Attachment Tabs Install Rating 4 Bumper Fascia Must Be Removed/Replaced During Install Requires Some Trimming of Bumper Fascia/Plastic/And/Or Grill Minor Drilling Required Use only w/Motorhome Mount Tow Bars Or PN BX8833/BX88151 Adapters Only Use Acclaim w/23”: 30” Spaced Removable Tab Baseplates Only Use Adventurer with 18”: 41” Spaced Removable Tab Baseplates Removable Tabs w/Only 1 Hole Will Not Attach to Car Mount Tow Bars or Adapters |
