High-quality steel construction guarantees longevity and withstands heavy-duty use.
Material: Steel
Color: Black
Finish: Powder Coat
Mounting Type: Bolt On
Mounting Hardware Included Yes/No: Yes
The Blue Ox BX3758 Tow Bar Bracket is an essential accessory for those who frequently tow vehicles. Custom designed for each specific towed vehicle, this bracket is a seamless solution that ensures an optimal fit and superior performance. Made from high-quality steel and coated with a black powder finish, it is not only durable but also corrosion resistant, ensuring it stands up to the toughest conditions. The bracket is a bolt-on type, meaning installation is a breeze. And don't worry about hunting for the right hardware - the bracket comes with everything you need for a DIY installation.
Blue Ox is known internationally for recreational and commercial towing products, manufacturing in Pender, Nebraska since 1925. The line covers tow bars and vehicle-specific baseplates for flat towing behind a motorhome, sway control and weight distributing hitches, supplemental braking accessories and towing wiring, backed by patented designs and long-standing customer service.
Blue Ox has manufactured since 1925 and is recognised internationally for towing products and customer service. The company operates from Pender, Nebraska, where it grew out of Automatic Manufacturing Co., a business that started with cattle oilers and developed into agricultural equipment, tractor accessories and trailer towing hardware. That agricultural engineering heritage still shows in how the towing products are built, and the company holds patents across weight distribution, fifth wheel and tow bar designs.
Flat towing is the discipline Blue Ox is best known for. Towing a car with all four wheels on the ground behind a motorhome demands a system that stays rigid under braking, articulates properly over uneven ground, and connects to the towed vehicle at points strong enough to take the load. Blue Ox tow bars handle the first two, with self-aligning arms that latch under tension and release without a struggle when the load is off them. Vehicle-specific baseplates handle the third, engineered per make and model to tie into structural mounting points behind the fascia.
The wider flat towing range covers supplemental braking systems, safety cables and the accessories that make a complete legal setup, along with baseplate wiring and dinghy towing harnesses that pass lighting signals to the towed vehicle without back-feeding its electrical system.
For conventional trailer towing, Blue Ox weight distributing hitches with integrated sway control transfer tongue load onto the tow vehicle's front axle and resist the yaw that crosswinds and passing trucks induce.
The company describes its foundation as customer service, designing around what owners actually ask for, and it runs an RV park adjacent to the factory where customers can stay. Sister operations at the same Nebraska site include Automatic grain roller mills and MAD-RAMPS pivoting ramp systems.
Experts available to answer your questions
Call 888-634-94943 Years
1 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2003 - 2007 | Toyota 4Runner | Comes with Removable Attachment Tabs Install Rating 3 Bumper Fascia Must Be Removed/Replaced During Install Requires Some Trimming of Bumper Fascia/Plastic/And/Or Grill Minor Drilling Required Requires Some Trimming of the Air Dam Use only w/Motorhome Mount Tow Bars Or PN BX8833/BX88151 Adapters Only Use Acclaim w/23”: 30” Spaced Removable Tab Baseplates Only Use Adventurer with 18”: 41” Spaced Removable Tab Baseplates Removable Tabs w/Only 1 Hole Will Not Attach to Car Mount Tow Bars or Adapters |
The BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select,TOYOTA 4-RUNNER E13 (Part #FDRWBX3758) fits the following vehicles: 2003-2007 Toyota 4Runner. Always verify your specific year, make, and model before ordering.
The BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select,TOYOTA 4-RUNNER E13 (Part #FDRWBX3758) fits 2003-2007 Toyota 4Runner models. The 2007 model year is the last year covered by this part number. For newer models, check for an updated version.
Yes, the BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select,TOYOTA 4-RUNNER E13 (Part #FDRWBX3758) is designed to fit the 2003-2007 Toyota 4Runner.
The BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select,TOYOTA 4-RUNNER E13 (Part #FDRWBX3758) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
Yes, the BX3758 baseplate is designed for 2003-07 Toyota 4-Runner models in both 2WD and 4WD configurations. The attachment tabs are 21 inches center to center with a height of 22 1/4 inches.
The manual states that the BX8847 is available for the vehicle, but does not provide details about compatibility or function. Contact Blue Ox directly or consult the BX8847 installation instructions for compatibility confirmation.
The front fascia, rubber air dam, and metal bumper must be removed. Specifically: remove six retainer clips and three push pins from the fascia cover, remove metric bolts from the fascia (one 10MM bolt just forward of the front tire on each side, one 7MM bolt above it on each side, and nine 10MM bolts on the bottom), unplug electrical components, remove two push pins from the bottom of the rubber air dam and two from the top, and remove four 14MM metric bolts from the metal bumper.
Yes, drilling is required. You must drill a 1 1/4" hole in the end of each frame rail cap using a 1 1/4" hole saw, and drill two 13/32" holes on each side of the baseplate and support plate for nut plate alignment. Trimming of the front grill and air dam is also required, or the air dam cannot be reinstalled.
Required tools are: 7MM, 8MM, 10MM, 12MM, and 14MM sockets; 9/16" socket; flat screwdriver; vise grips; rubber mallet; 1 1/4" hole saw; 13/32" drill bit; utility knife; and Loctite. A drill and drill press or hand drill are needed for the hole saw and drill bit work.
The kit includes: one baseplate weldment (61-6065), two support plates (101-6721), eight 3/8" nut plates with wire (61-5208), four 3/8-16 x 1 1/4" Grade 5 bolts, four 3/8-16 x 1 1/2" Grade 5 bolts, eight 3/8 lock washers, two 8MM-1.25 x 30MM Grade 8 hex bolts, two 8MM lock washers, two 12MM-1.25 x 45MM Grade 8 hex bolts, two 12MM lock washers, six 3/8" flat washers, four 1/2" flat washers, two #12-14 x 1" self-drilling screws, two 4-way connector adapters (101-5822), two #10-32 x 1/2" slot round head screws, two #10 lock washers, two #10-32 hex nuts, two attachment assemblies (62-3469), two 36" Class IV baseplate safety cables (226-0049), and four 1/2" quicklinks (229-0512).
1. Remove fascia cover clips and push pins. 2. Remove fascia bolts and unplug electrical components. 3. Remove rubber air dam push pins. 4. Remove metal bumper bolts. 5. Drill 1 1/4" holes in frame rail caps. 6. Position baseplate on frame rails and secure with vise grips. 7. Install support plate bolts with lock washers and flat washers, using Loctite, and tighten per torque chart. 8. Align side holes using rubber mallet and drill 13/32" top holes. 9. Insert nut plates and install 3/8-16 x 1 1/4" bolts with lock washers and Loctite. 10. Drill two 13/32" holes on each side using support plate as template. 11. Install nut plates and 3/8-16 x 1 1/2" bolts with lock washers and Loctite. 12. Reinstall metal bumper and fascia, trimming as needed. 13. Install tow bar and safety cables per their instructions.
The manual states that all bolts must be tightened according to the torque chart in the General Instruction sheet, which is not included in this document. Contact Blue Ox or your installer for the specific torque values, or request the General Instruction sheet from your dealer.
Yes, Loctite must be applied to all bolts before tightening. This is required for the support plate bolts (step 10), the 3/8-16 x 1 1/4" bolts (step 12), and the 3/8-16 x 1 1/2" bolts (step 13). Loctite Red is recommended for all bolts per the general information section.
The manual notes that dimensional variations between otherwise identical vehicles can be considerable. If a bolt does not clear, it may be necessary to file a hole slightly to allow proper alignment. This is a normal part of the installation process.
Permanent baseplate safety cables are strongly recommended. They prevent the towed vehicle from breaking loose if the connection between the frame and baseplate fails. The cables must be connected from the baseplate to the frame rail or cross member. Two 36" Class IV cables are included with the kit (part 226-0049). The cables must not be mounted against wires, hoses, or brake lines. These cables work in conjunction with, not as a replacement for, legally required safety cables attaching the towed vehicle to the towing vehicle.
Before each towing trip, inspect all towing equipment for cracked welds, missing or worn parts, and loose bolts. Ensure all bolts are tightened to the recommended specifications using Loctite Red. This is the owner's responsibility.
Remove the attachment tabs when not in use.
Do not substitute other devices if the tow bar pin and clip are lost. Obtain replacement parts from Blue Ox or your dealer to ensure proper and safe operation.
The rubber air dam can be reinstalled, but it will require trimming. The manual states that trimming of the front grill and air dam is required, or the air dam cannot be reinstalled. If you choose to reinstall both air dams, they will need to be trimmed.
Use only genuine factory replacement parts and replacement bolts of the same grade as the original (usually Grade 5). Do not use homemade or nontypical parts. Repair parts may be ordered through your nearest Blue Ox dealer or distributor. Using incorrect replacement parts could compromise the safety and integrity of the baseplate.
Yes, it is crucial to register your product online at www.blueox.com. Registration ensures you are alerted of product offerings, updates, upgrades, maintenance and safety bulletins, and recalls.
Yes, the BX3758 is designed for 2003-07 Toyota 4-Runner (2WD/4WD). Attachment tabs are 21 inches center to center, 22 1/4 inches height.
Yes. Drill a 1 1/4" hole in each frame rail cap using a 1 1/4" hole saw, and drill 13/32" holes for baseplate and support plate alignment. Trimming of the front grill and air dam is also required for reinstallation.
Required tools: 7MM, 8MM, 10MM, 12MM, 14MM, and 9/16" sockets; flat screwdriver; vise grips; rubber mallet; 1 1/4" hole saw; 13/32" drill bit; utility knife; and Loctite.
Yes, Loctite must be applied to all bolts before tightening. Loctite Red is recommended.
Yes, two 36" Class IV baseplate safety cables are included. They must be connected from the baseplate to the frame rail or cross member and must not be mounted against wires, hoses, or brake lines.
Inspect for cracked welds, missing or worn parts, and loose bolts. Ensure all bolts are tightened to specification using Loctite Red before each towing trip.
Remove the front fascia (including cover clips, push pins, and bolts), rubber air dam (push pins), and metal bumper (four bolts). Unplug electrical components from the fascia.
