Includes harness, 4-flat extension, mounting bracket and hardware
Includes harness, 4-flat extension, mounting bracket and hardware
Warranty: One-Year Limited Warranty
Installation Time Exact (Minutes): 0
Towing your vehicle behind your RV is a great way to experience more of the adventure on your cross-country excursions. Whether you're towing a compact car or a full-size truck, CURT has the perfect solution to help you Bring It! CURT towed-vehicle RV harnesses are a vehicle-specific, plug-and-play solution to wiring your vehicle for dinghy towing. They use original-equipment-compatible connectors to plug into your vehicle's wiring system without any cutting, splicing or soldering required. They provide a standard 4-way flat connector to plug into the RV socket and synchronize the vehicle's tail lights, turn signals and brake lights with the RV's. Because each towed-vehicle RV harness has a vehicle-specific design, installation is fast and easy. This particular RV dinghy towing wiring harness is designed for specific years of the GMC Acadia. CURT RV harnesses are also built to provide long-lasting operation. They feature integrated block diodes that protect the vehicle's circuits from the RV signals. They isolate the sensitive vehicle electronics, keeping them from overheating and short circuiting. Every CURT towed-vehicle RV harness comes ready to install with all necessary hardware included. They also come with a 4-way flat extension to provide plenty of length to plug into the RV socket, as well as a connector mounting bracket to mount the connector on the vehicle.
CURT offers a variety of high-quality trailer hitches and accessories for select vehicle models. Find the perfect fit for your towing needs at TowUniverse.
CURT, a Lippert brand, offers a complete line of towing products and is the leading manufacturer of custom-fit trailer hitches. We offer the broadest selection of custom-fit hitches, and each one is designed, welded, and coated in Wisconsin.
CURT is also a leader in flat towing products, as well as 5th wheel, gooseneck, and weight distribution hitches, ball mounts, electrical components, cargo solutions, and other towing accessories.
For everything from passenger cars and vans to full-size pickups and SUVs, CURT is 'The First Name in Towing Products®.'
Experts available to answer your questions
Call 888-634-9494Rediscover "Us" Time | Tested. Proven. Safe. Towing Products
Yes, the CURT Custom Towed-Vehicle RV Wiring Harness, Select GMC Acadia Trailer Connector Kit (Part #BKDK58973) is designed to fit the 2017-2019 GMC Acadia.
The CURT Custom Towed-Vehicle RV Wiring Harness, Select GMC Acadia Trailer Connector Kit (Part #BKDK58973) fits 2017-2019 GMC Acadia models. The 2019 model year is the last year covered by this part number. For newer models, check for an updated version.
The CURT Custom Towed-Vehicle RV Wiring Harness, Select GMC Acadia Trailer Connector Kit (Part #BKDK58973) fits the following vehicles: 2017-2019 GMC Acadia. Always verify your specific year, make, and model before ordering.
The CURT Custom Towed-Vehicle RV Wiring Harness, Select GMC Acadia Trailer Connector Kit (Part #BKDK58973) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
The CURT 58973 is an RV harness with a 4-way flat connector designed for SUVs and vans. It allows you to connect a trailer's lighting system to your vehicle's taillights so that the trailer lights function when the vehicle lights are activated.
The CURT 58973 is designed for SUVs and vans (designated as 'S' vehicles). The manual does not specify individual vehicle makes, models, or years. Consult the product fitment database or contact CURT directly to confirm compatibility with your specific vehicle.
You will need: a ratchet, drill, 7mm socket, 3/32" drill bit, T-15 Torx bit, fishwire, flathead screwdriver, and a panel trim removal tool. The manual notes that proper tools will improve installation quality and reduce time required.
Yes. You must disconnect the negative battery terminal in the engine compartment on the driver's side before beginning installation. Fasten this wire down and away from the battery while completing the installation process.
The installation difficulty is rated as Moderate. This rating is based on time and effort involved and may vary depending on the installer's level of expertise, the condition of the vehicle, and whether proper tools and equipment are available.
Open the hatch and remove the two fastener covers using a small flathead screwdriver. Using a 7mm socket, remove the taillight fasteners. Then pull the taillight straight rearward. Open the red locking tab by pulling out and applying pressure to the lock. This will allow the connectors to come apart. Separate the connectors from the taillight housing, taking care not to damage the locking tabs. Repeat on the other side.
Remove the two T-15 Torx screws from the inner fender and loosen the wheel well trim push fasteners using a panel trim removal tool until you clear the bumper cover. Loosen the bumper cover from the body all the way up to the rear taillight. On the driver's side, insert the RV harness end with the yellow wire between the separated taillight connectors, ensuring they are fully inserted with locking tabs in place. Route the yellow wire between the vehicle body and bumper cover, following the same route as the vehicle factory harness.
From under the rear bumper, route the RV harness end with the green wire along the backside of the bumper cover from the driver's side to the passenger's side. Use cable ties as needed, but do not completely tighten them, allowing for adjustment later. Repeat the taillight connector insertion steps on the passenger side using the harness end with the green wire.
Locate a suitable grounding point near the connector, such as an existing screw with nut in the vehicle frame. If no suitable point exists, drill a 3/32" pilot hole for the provided screw. The area should be free of rust, dirt, and paint. Secure the white ground wire using the ring terminal and provided screw.
Drilling may be required. You must drill a 3/32" pilot hole for the ground wire screw if no suitable existing screw with nut is available in the vehicle frame. Before drilling, check for miscellaneous items that may be hidden behind or under any surface to avoid damage and personal injury.
Route the 4-way flat between the muffler on the driver's side and the vehicle body up to the back side of the rear wheel well. Continue routing above the rear drive line suspension and the bottom of the vehicle floor to the rear of the fuel tank. Then route the harness wires between the fuel tank and the driver's side sub frame up to the back of the front tire. Use cable ties to secure the wires without tightening them, allowing for adjustment later.
Fishwire is a method to push or pull an electrical wire through a blind hole. From the engine compartment on the driver's side, run a fishwire down between the inner and outer fender. The fishwire will come out at the back of the front tire. Use tape to secure the harness to the fishwire and pull it back up into the engine compartment. If the fishwire gets hung up, you may need to push back down, wiggle it around, or twist the wire to loosen it. Fishwire can be made from a cut-up wire hanger, stiff wire, rope, or string.
Route the 4-way flat under the rubber hood seal and along the driver's side front fender to the back side of the headlight and mount it there.
Pull all excess wire so that it is not loose, but do not pull it too tight. Pulling too tight can cause unnecessary strain on the wire and could cause breakage over time. After removing all slack from the 4-way flat wire, tighten any cable ties and add as needed.
Once the RV harness is installed, verify that it is functioning by attaching the 4-way flat to any vehicle with functioning taillights. The taillights on the vehicle to be towed should function along with the taillights on the vehicle that is powering them. For testing purposes only, you may temporarily connect the taillights to the custom harness, but they should be removed once the test is complete.
Reinstall the bumper cover, wheel well trim, and taillights. Route the 4-way flat connector as described in the installation steps. Pull all excess wire to remove slack without pulling too tight. Tighten cable ties and add as needed. Reinstall all items removed during installation. If the negative battery terminal was disconnected at the beginning, reconnect it. Install the provided 4-way flat dust cover to help prevent corrosion.
The manual states: Do not exceed the product rating or tow vehicle lamp load rating, whichever is lower. The specific product rating is not provided in the manual. Contact CURT or check the product documentation for the exact rating.
Periodic inspection of all wires and connections should be performed to ensure there is no visible damage or loose connections. The manual does not specify the exact interval for these inspections.
The CURT 58973 is designed for SUVs and vans. Check the product fitment database or contact CURT to confirm compatibility with your specific make, model, and year.
Yes, you must disconnect the negative battery terminal before beginning installation.
Do not exceed the product rating or tow vehicle lamp load rating, whichever is lower. The specific product rating is not provided in the manual.
Perform periodic inspection of all wires and connections to ensure there is no visible damage or loose connections.
