B&W Trailer Hitches
Verify Fitment
Select your vehicle to confirm this part fits.
2007 - 2018 Chevrolet Silverado 1500
Confirmed to Fit
2007 Chevrolet Silverado 1500 Classic
Confirmed to Fit
2007 Chevrolet Silverado 1500 HD Classic
Confirmed to Fit
2007 - 2018 GMC Sierra 1500
Confirmed to Fit
Confirmed to Fit
2007 GMC Sierra 1500 HD Classic
Confirmed to Fit
Always the correct part
We know our products
Quality Products
Free Shipping!
Always the correct part
We know our products
Quality Products
Free Shipping!
| PROP 65 WARNING: | WARNING: This product may expose you to chemicals including Nickel (Metallic), which is known to the state of California to cause cancer. For more information, go to www.P54Warnings.ca.gov. |
B&W Trailer Hitches is an American manufacturer known for durable, innovative towing products, including gooseneck hitches, fifth-wheel hitches, receiver hitches, and ball mounts. Built in Kansas by employee-owners, B&W products are engineered for dependable performance, easy installation, and long-lasting quality.
B&W Trailer Hitches is an American manufacturer known for building innovative, dependable towing products designed to make hitching easier and towing more comfortable. The company began in 1987 in Humboldt, Kansas, when founders Roger Baker and Joe Works combined their fabrication experience to build custom truck beds and solve common problems faced by truck owners.
B&W changed the gooseneck hitch industry with the introduction of the Turnoverball Gooseneck Hitch. Its under-bed mounting system and reversible hitch ball allowed truck owners to quickly store the ball beneath the bed, leaving a clean and unobstructed surface when the hitch was not in use. B&W later applied the same practical approach to the Companion Fifth Wheel Hitch, creating a removable fifth-wheel hitch engineered for a quiet, smooth, and secure towing experience.
Today, B&W manufactures gooseneck hitches, fifth-wheel hitches, receiver hitches, ball mounts, and towing accessories at its nearly 600,000-square-foot facility. The company is owned by approximately 500 employee-owners who remain committed to American manufacturing, trusted materials, skilled craftsmanship, and long-lasting product quality.
Whether you are towing a work trailer, livestock trailer, camper, or fifth wheel, B&W Trailer Hitches offers thoughtfully engineered towing equipment built to perform mile after mile.
Experts available to answer your questions
Call 888-634-94946 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2007 - 2018 | Chevrolet Silverado 1500 | — |
| 2007 | Chevrolet Silverado 1500 Classic | — |
| 2007 | Chevrolet Silverado 1500 HD Classic | — |
| 2007 - 2018 | GMC Sierra 1500 | — |
| 2007 | GMC Sierra 1500 Classic | — |
| 2007 | GMC Sierra 1500 HD Classic | — |
The B&W Trailer Hitches Custom Installation Brackets For Universal Mounting Rails For Some GM Trucks Fifth Wheel Trailer Hitch Bracket BQVLRVR2503 (Part #BQVLRVR2503) fits 2007-2018 Chevrolet Silverado 1500 models. The 2018 model year is the last year covered by this part number. For newer models, check for an updated version.
Yes, the B&W Trailer Hitches Custom Installation Brackets For Universal Mounting Rails For Some GM Trucks Fifth Wheel Trailer Hitch Bracket BQVLRVR2503 (Part #BQVLRVR2503) is designed to fit the 2007-2018 Chevrolet Silverado 1500.
The B&W Trailer Hitches Custom Installation Brackets For Universal Mounting Rails For Some GM Trucks Fifth Wheel Trailer Hitch Bracket BQVLRVR2503 (Part #BQVLRVR2503) fits the following vehicles: 2007-2018 Chevrolet Silverado 1500; 2007 Chevrolet Silverado 1500 Classic; 2007 Chevrolet Silverado 1500 HD Classic; 2007-2018 GMC Sierra 1500; 2007 GMC Sierra 1500 Classic; 2007 GMC Sierra 1500 HD Classic. Always verify your specific year, make, and model before ordering.
The B&W Trailer Hitches Custom Installation Brackets For Universal Mounting Rails For Some GM Trucks Fifth Wheel Trailer Hitch Bracket BQVLRVR2503 (Part #BQVLRVR2503) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
Yes, the RVK2503 is designed for 2007–2018 Chevrolet and GMC 1500 trucks, including 2019 Chevy LD and GMC Limited 1500 trucks. However, if your truck is equipped with MagneRide suspension, additional brackets are required. Contact B&W at 800.248.6564 or hitches@turnoverball.com for details on MagneRide-equipped trucks.
Yes, if your truck has a removable bed liner or mat, it must be removed to allow the mounting rails to connect directly with the bed. However, if you have a spray-in bed liner, the rails can be installed over it. When measuring and drilling, account for the thickness of any spray-in liner applied over the end of the bed.
Required tools include: impact wrench or ratchet with 1/2" and 3/4" sockets; 1/2" and 3/4" box end wrenches; drill with 1/8" and 9/16" drill bits; tape measure; torque wrench; center punch tool; hammer; flashlight; and eye protection and ear protection. You will also need a Patriot 5th wheel or Slider Base for positioning the forward rail.
The manual states that installation must be completed by someone who is aware of the hazards involved and is knowledgeable of proper safety procedures for vehicle installation and equipment usage. While not explicitly requiring a professional, the installer must understand the risks of adding components to a vehicle chassis, proper tool usage, and towing safety. If you are not confident in these areas, professional installation is recommended.
The kit includes: 2 Patriot Rail Box mounting rails (RVR3210); 1 Bracket Set Box (RVR2503) containing 2 side plates (driver and passenger), 2 U-bolts (1/2" x 5-1/2" x 4-1/4"), 1 relocation bracket, 12 carriage bolts (1/2"), 16 split lockwashers (1/2"), 16 finish nuts (1/2"), 2 locking straps (1/2"), 2 retainers (1/2"), 2 frame bushings (1/2"), 2 flat washers (1/2"), 2 cap screws (5/16"), 2 split lockwashers (5/16"), 2 finish nuts (5/16"), 10 offset rectangle washers, and 10 U-shaped spacers (5/16").
Yes, drilling is required. You must drill 5 holes in the rear rail location and 5 holes in the forward rail location in the truck bed. Holes are first marked with a center punch tool, then drilled with an 1/8" bit, and finally enlarged to 9/16" using the 1/8" holes as pilots. Before drilling, carefully examine the area under the truck to ensure the fuel tank or other equipment will not be damaged.
Hole locations differ between short bed and long bed trucks. For the rear rail: measure 25-1/2" from the rear edge of the bed for short beds (less than 8' long), or 30-3/8" for 8' long beds. Center the rail by measuring equal distances from the rail edges to the bed sides. Mark 5 drill locations using a center punch tool, then drill with an 1/8" bit. The forward rail has slightly different hole locations; see Figure B2 in the manual. Ensure the mounting rail does not move while marking.
No, you must drill through the truck bed. The manual requires drilling 1/8" pilot holes and then enlarging them to 9/16" through the bed to attach the mounting rails. Before drilling, carefully examine the area under the truck to ensure the fuel tank or other equipment will not be damaged. If your truck has a spray-in bed liner, account for its thickness when measuring.
The installation sequence is: 1) Install the relocation bracket on the driver side frame to move brake lines out of the way; 2) Drill rear mounting holes in the truck bed; 3) Install frame carriage bolts and side plates; 4) Install the U-bolt to secure the side plate to the frame; 5) Install the rear mounting rail with carriage bolts, offset washers, lockwashers, and finish nuts; 6) Position the forward mounting rail using the base; 7) Drill forward mounting holes; 8) Install the forward mounting rail; 9) Torque all hardware to specification.
The manual does not specify that the battery must be disconnected for this installation.
The relocation bracket is a small L-shaped bracket that relocates the truck's frame-mounted brake bracket to move the brake lines close to the inside of the driver side frame. This creates room to install the U-bolts. To install it, disconnect the truck brake bracket by removing the two bolts on top of the frame, attach the relocation bracket to the top of the frame using the same holes, then re-attach the truck brake bracket to the relocation bracket holes using two 5/16" cap screws, lockwashers, and nuts.
On some short bed trucks, a wire cable bracket may be located where the driver side plate will be installed. If present, it may be necessary to temporarily remove the bracket by removing the bolt attaching it to the frame. Replace the bracket after the side plates are securely installed.
U-shaped spacers function as space fillers between the mounting rails and kit attachment hardware to account for corrugation in the truck bed. They must be placed in the gap either above the bed (between the mounting rail and bed) or below the bed (between the bed and side plates). Failure to use U-shaped spacers will result in property damage when hardware is tightened.
Place the forward mounting rail in front of the rear mounting rail. Place the Patriot base over the rail attachment points and carefully lower it until the pin tabs pass through the attachment points on the rear mounting rail. Attach the forward mounting rail to the forward mounting points on the base. Before drilling forward mounting holes, pull the RV base towards the rear of the truck and push the forward rail towards the cab to correctly space the mounting rails. Ensure the base rests flat against the top of the rails and the forward rail is centered in the truck bed.
Torque all 1/2" nuts in the mounting rails to 80 ft-lbs. Then torque all 1/2" nuts in the side plates to 80 ft-lbs. Use a torque wrench for this step.
Tighten the U-bolts slowly, alternating between the top and bottom legs of the U-bolt until equally tightened to a maximum of 40 ft-lbs. The manual notes that this torque may not be obtained without bending the side plate slightly, which is normal and will not hinder the function of the hitch.
The U-bolts are 1/2" x 5-1/2" x 4-1/4". Two U-bolts are included in the kit, one for each side of the truck.
The frame geometry differs between long bed and short bed versions. The manual provides Figures D2 and D3 to show the correct U-bolt hole locations for each configuration. You must determine whether your truck is a long bed or short bed and use the corresponding hole locations when installing the U-bolt.
Do not exceed the tow or tongue rating of the coupler, hitch, truck, or trailer. See your vehicle and trailer manufacturer information for ratings. Exceeding these ratings may cause damage to towing components or loss of attachment between the trailer and truck. Understand all risks involved with towing before proceeding. For detailed towing safety information, refer to "The Trailer Handbook: A guide to Understanding Trailer and Towing Safety" from the National Association of Trailer Manufacturers (www.NATM.com) and your trailer manufacturer's owner's manual.
Additional caution must be used when towing a wedge car trailer. Keep the center of gravity as low as possible by loading heavy cars over the axles. Never tow with a single car on the front of the trailer. Never exceed speeds that are reasonable for the roadway conditions (e.g., turns, curves). Failure to account for proper trailer center of gravity and reasonable speeds may cause damage to the truck, trailer, towing components, and loss of attachment between the truck and trailer.
No, do not modify this product in any manner. Doing so could alter its integrity and lead to a loss of attachment between the trailer and the tow vehicle.
After installation, perform a visual inspection of all bolted connections before each time you tow. Regularly check that all bolted connections are at the correct torque specification. Ensure all 1/2" nuts are torqued to 80 ft-lbs and U-bolts are torqued to 40 ft-lbs.
Regularly check that all bolted connections are at the correct torque specification. A visual inspection should be performed before each time you tow.
Yes, the RVK2503 fits 2007–2018 Chevrolet and GMC 1500 trucks, including 2019 Chevy LD and GMC Limited 1500 trucks. If your truck has MagneRide suspension, additional brackets are required; contact B&W at 800.248.6564.
A Patriot 5th wheel or Slider Base is required. The base is used to position the forward mounting rail and must rest flat against the top of the rails.
Yes, you must drill 10 holes total in the truck bed (5 for the rear rail and 5 for the forward rail). Holes are drilled with an 1/8" bit and enlarged to 9/16". Before drilling, examine the area under the truck to ensure the fuel tank will not be damaged.
Yes, removable bed liners must be removed or cut to allow the mounting rails to connect directly with the bed. Spray-in bed liners are acceptable and the rails can be installed over them.
Torque all 1/2" nuts in the mounting rails to 80 ft-lbs, then torque all 1/2" nuts in the side plates to 80 ft-lbs. Tighten U-bolts to a maximum of 40 ft-lbs, alternating between top and bottom legs.
Do not exceed the tow or tongue rating of the coupler, hitch, truck, or trailer. See your vehicle and trailer manufacturer information for specific ratings.
Perform a visual inspection of all bolted connections before each time you tow. Verify that all bolts are at the correct torque specification: 1/2" nuts at 80 ft-lbs and U-bolts at 40 ft-lbs.
If the 1/8" drilled holes are not centered within the slots in the side plates, re-drill the 1/8" holes until the side plates and drilled holes are aligned. Then use the corrected 1/8" holes as pilots to enlarge the holes to 9/16".
The manual states "While carefully ensuring the mounting rail does not move, use a center punch tool to mark the 5 drill locations." If the rail moves during marking, reposition it and re-mark the hole locations. The manual emphasizes that failure to place the mounting rail precisely may result in added difficulty during installation and/or property damage.
