Custom-designed to fit your specific towed vehicle for a precise match, allowing for optimal performance.
Material: Steel
Color: Black
Finish: Powder Coat
Mounting Type: Bolt On
Mounting Hardware Included Yes/No: Yes
The Blue Ox BX3329 Tow Bar Bracket is the ultimate in strength and durability, specifically custom-designed to fit your vehicle for a perfect match. Made from high-quality steel, this tough bracket is built to last. Its sleek black finish is more than just stylish; it's a powder coat that provides extra protection against rust and wear. The bolt-on mounting type ensures easy installation, and we've included all the mounting hardware you'll need. You'll also receive comprehensive instructions for a smooth, DIY installation. Trust Blue Ox BX3329 for a towing solution that delivers both in quality and functionality.
Blue Ox is known internationally for recreational and commercial towing products, manufacturing in Pender, Nebraska since 1925. The line covers tow bars and vehicle-specific baseplates for flat towing behind a motorhome, sway control and weight distributing hitches, supplemental braking accessories and towing wiring, backed by patented designs and long-standing customer service.
Blue Ox has manufactured since 1925 and is recognised internationally for towing products and customer service. The company operates from Pender, Nebraska, where it grew out of Automatic Manufacturing Co., a business that started with cattle oilers and developed into agricultural equipment, tractor accessories and trailer towing hardware. That agricultural engineering heritage still shows in how the towing products are built, and the company holds patents across weight distribution, fifth wheel and tow bar designs.
Flat towing is the discipline Blue Ox is best known for. Towing a car with all four wheels on the ground behind a motorhome demands a system that stays rigid under braking, articulates properly over uneven ground, and connects to the towed vehicle at points strong enough to take the load. Blue Ox tow bars handle the first two, with self-aligning arms that latch under tension and release without a struggle when the load is off them. Vehicle-specific baseplates handle the third, engineered per make and model to tie into structural mounting points behind the fascia.
The wider flat towing range covers supplemental braking systems, safety cables and the accessories that make a complete legal setup, along with baseplate wiring and dinghy towing harnesses that pass lighting signals to the towed vehicle without back-feeding its electrical system.
For conventional trailer towing, Blue Ox weight distributing hitches with integrated sway control transfer tongue load onto the tow vehicle's front axle and resist the yaw that crosswinds and passing trucks induce.
The company describes its foundation as customer service, designing around what owners actually ask for, and it runs an RV park adjacent to the factory where customers can stay. Sister operations at the same Nebraska site include Automatic grain roller mills and MAD-RAMPS pivoting ramp systems.
Experts available to answer your questions
Call 888-634-94943 Years
1 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2007 - 2009 | Saturn Aura | Also XR Comes with Removable Attachment Tabs Install Rating 3 Bumper Fascia Must Be Removed/Replaced During Install Requires Some Trimming of Bumper Fascia/Plastic/And/Or Grill Minor Drilling Required Use only w/Motorhome Mount Tow Bars Or PN BX8833/BX88151 Adapters Only Use Acclaim w/23”: 30” Spaced Removable Tab Baseplates Only Use Adventurer with 18”: 41” Spaced Removable Tab Baseplates Removable Tabs w/Only 1 Hole Will Not Attach to Car Mount Tow Bars or Adapters |
Yes, the BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select, SATURN AURA (Part #FDRWBX3329) is designed to fit the 2007-2009 Saturn Aura.
The BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select, SATURN AURA (Part #FDRWBX3329) fits 2007-2009 Saturn Aura models. The 2009 model year is the last year covered by this part number. For newer models, check for an updated version.
The BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select, SATURN AURA (Part #FDRWBX3329) fits the following vehicles: 2007-2009 Saturn Aura. Always verify your specific year, make, and model before ordering.
The BlueOx Tow Bar Base Plate, Front Mount, RV Flat Towing for Select, SATURN AURA (Part #FDRWBX3329) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
Yes, the BX3329 is designed for 2007-09 Saturn Aura vehicles. However, if the front of your vehicle looks different than shown in the manual, contact Blue Ox at (402) 385-3051 before proceeding with installation.
Motorhome mount tow bars are recommended for use with the BX3329. The Acclaim tow bar may be used, but will not fold and store on the front of the vehicle. The RangeFinder II, Adventurer and Ambassador tow bars cannot be used due to the design of the removable tabs.
Most adapters cannot be used with the BX3329 baseplate. Only the BX8833 and BX88151 adapters are compatible. All other adapters are not compatible.
Required tools include: 7MM socket, 10MM socket, 9/16" socket, 13/32" drill bit, 1/4" drill bit, Loctite RED, vice grips, Phillips screwdriver, utility knife, flat screwdriver, hack saw blade, and tape measure.
The kit includes: one weldment base plate (61-6328), three 3/8" nut plates with wire (61-5208), seven 3/8-16 x 1 1/4" Grade 5 bolts (201-0368), seven 3/8" lock washers (203-0010), four 3/8-16 hex nuts (202-0003), one 6MM-1 x 30MM Grade 8.8 hex bolt (201-0655), one 1/4" lock washer (203-0008), one 1/4" flat washer (203-0001), two #12-14 x 1" self-drilling screws (201-0979), two #10-32 x 1/2" round head screws (201-0192), two #10 lock washers (203-0054), two #10-32 hex nuts (202-0047), two 4-way connector adapters (101-5822), two attachment assemblies (62-3468), one #10-16 x 1 self-drilling screw (201-0654), two black cap plugs (290-0437), two 36" permanent baseplate safety cables Class III (226-0046), and two 3/8" quick links (229-0359).
The following components must be removed: radiator cover, fascia, fascia support, horn bracket (driver's side), air baffle (passenger's side), air dams (both sides), and belly pan. Additionally, various bolts, clips and pushpins must be removed and set aside for reinstallation.
The BX8869 Bulb and Socket Wiring Kit is recommended for this vehicle. The manual does not state whether it is required, but recommends its use.
Yes, drilling is required. You will drill three holes on the driver's side and four holes on the passenger's side into the frame using a 13/32" drill bit. The baseplate is used as a template for hole placement.
Trimming is required in several areas: (1) remove tabs from the back corners of the fascia using a utility knife; (2) remove clips from both corners of the fascia support; (3) trim the passenger's side air dam in three specific areas as marked in steps 20-22; (4) trim the driver's side air dam in two areas as marked in steps 23-24; (5) trim necessary openings in the grille style for the attachment tabs on both sides using a hack saw blade.
The manual provides a general torque table for Grade 5 and Grade 8 bolts. For 3/8" Grade 5 bolts, the torque specification is 33 foot-pounds. For 3/8" Grade 8 bolts, the torque specification is 47 foot-pounds. The BX3329 uses Grade 5 bolts (33 foot-pounds) unless otherwise specified. All bolts must be secured with Loctite RED.
The manual provides a general torque table for metric bolts. For a 6MM Grade 8.8 bolt, the torque specification is 8 foot-pounds. The horn bracket is reinstalled using a 6MM-1 x 30MM Grade 8.8 hex bolt with a 1/4" lock washer and 1/4" flat washer.
The attachment tab height is 13-1/4" and the attachment tab width is 20".
On the driver's side: (1) align the upper back hole of the baseplate with the existing horn bracket hole and clamp in place with vice grips; (2) drill three remaining holes into the frame using a 13/32" drill bit; (3) install 3/8-16 x 1-1/4" hex bolts with 3/8" lock washers and 3/8-16 hex nuts to the lower two holes; (4) insert a 3/8" nut plate through the opening in the bottom of the frame rail and align to the upper front hole; (5) install a 3/8-16 x 1-1/4" hex bolt with 3/8" lock washer and tighten to the nut plate; (6) reinstall the horn bracket to the upper back hole using a 6MM hex bolt, 1/4" lock washer and 1/4" flat washer; (7) trim excess nut plate wire.
On the passenger's side: (1) align the upper front baseplate hole with the existing air baffle hole and clamp in place with vice grips; (2) drill four holes into the frame using a 13/32" drill bit; (3) insert 3/8" nut plates through the opening in the bottom of the frame rail and align to the upper two holes; (4) install 3/8-16 x 1-1/4" hex bolts with 3/8" lock washers and tighten to the nut plates; (5) install 3/8-16 x 1-1/4" hex bolts with 3/8" lock washers and 3/8-16 hex nuts to the lower two holes; (6) trim excess nut plate wires.
Three trim areas are required on the passenger's side: (1) mark from the back portion of the lip diagonally to the bend and down 3 inches around the contour, then mark straight down from the air dam tab 3 inches and horizontally back to the contour, and trim with a utility knife; (2) just behind the tab, mark 3" down and 2" horizontally, then mark upwards following the contour to the top of the air dam and trim away; (3) on the upper rear, make a 1" horizontal cut level with the opening next to the air dam and trim vertically to remove this portion.
Two trim areas are required on the driver's side: (1) just behind the air dam tab, cut down 3", then cut horizontally toward the rear of the air dam approximately 2", then cut upwards to the top following the contour of the air dam; (2) approximately 1" from the top of the air dam, cut horizontally from the front of the air dam to the back.
Attach the permanent baseplate safety cables to the provided convenience link (quick link) on the baseplate. The cables must be connected from the baseplate to the frame rail or cross member of the vehicle's frame. Do not mount the cables against wires, hoses or brake lines. If the vehicle has additional options that interfere with mounting the cables, secure the cable to a solid piece of the vehicle's frame as described in the instructions included with the permanent baseplate safety cables.
Reinstall all removed components: air dams, air baffle, belly pan, fascia, radiator cover, pushpins and bolts. Then install the tow bar and safety cables according to the instructions provided in their packages. Ensure all electrical connections are plugged in properly and functioning before installing the fascia.
Permanent baseplate safety cables are strongly recommended when towing a vehicle with a tow bar. Their function is to prevent the towed vehicle from breaking loose in the event the connection between the frame and baseplate fails or becomes disconnected. The cables must be connected from the baseplate to the frame rail or cross member. These cables are to be used in conjunction with, and NOT a replacement for, legally required safety cables attaching the towed vehicle to the towing vehicle.
Before each towing trip, inspect all towing equipment for: cracked welds, missing or worn parts, and loose bolts. Ensure all bolts are secured with Loctite RED and tightened to the recommended specifications. Verify that all electrical connections are properly plugged in and functioning.
Ensure that ALL electrical connections are plugged in properly and functioning BEFORE installing the fascia. This is critical to ensure proper operation of the towing system.
Yes, the attachment tabs should be removed when not in use, if applicable. This helps preserve the baseplate and tow bar system.
Yes, it is crucial to register your product online at www.blueox.com. Registration ensures you will be alerted of product offerings, updates, upgrades, maintenance and safety bulletins, and/or recalls.
Use a replacement bolt of the same grade as the original. In most cases, BX3329 bolts are Grade 5. Do not substitute homemade or non-typical parts. Replacement parts may be ordered through your nearest Blue Ox Dealer or Distributor. Ensure the replacement bolt is the correct size and grade for safety and preservation of the baseplate.
No. Even though bolts may exist in certain locations, do not assume they are adequate for baseplate mounting. Always use hardware supplied in the hardware kit or existing hardware specified in the Baseplate Installation Instructions. The manual specifies which existing holes (horn bracket hole on driver's side and air baffle hole on passenger's side) are used as alignment points, but new holes must be drilled for the remaining attachment points.
Blue Ox towing products are intended to be installed by Blue Ox Dealers who are familiar with the products and have the equipment and knowledge to do "fit work". Blue Ox Dealers can be found at www.blueox.com or by contacting the Customer Care Department at 1-800-228-9289.
Contact Blue Ox at (402) 385-3051 before attempting installation. The manual notes that if the front of your vehicle looks different than shown, you should verify compatibility before proceeding.
Blue Ox Customer Care can be reached at 1-800-228-9289. You can also visit www.blueox.com for product information and to locate Blue Ox Dealers. The company is located at One Mill Road, Industrial Park, Pender, Nebraska 68047, with phone (402) 385-3051 and fax (402) 385-3360.
Yes, the BX3329 is designed for 2007-09 Saturn Aura. Motorhome mount tow bars are recommended; RangeFinder II, Adventurer and Ambassador tow bars cannot be used. Only BX8833 and BX88151 adapters are compatible.
You will need: 7MM and 10MM sockets, 13/32" and 1/4" drill bits, vice grips, utility knife, flat and Phillips screwdrivers, hack saw blade, tape measure, and Loctite RED.
For 3/8" Grade 5 bolts (used on the BX3329), the torque specification is 33 foot-pounds. All bolts must be secured with Loctite RED.
You must remove the radiator cover, fascia, fascia support, horn bracket, air baffle, air dams, and belly pan, along with their associated bolts, clips and pushpins.
Permanent baseplate safety cables are strongly recommended. They prevent the towed vehicle from breaking loose if the baseplate connection fails. They must be used in conjunction with, not as a replacement for, legally required safety cables.
Inspect all towing equipment for cracked welds, missing or worn parts, and loose bolts. Ensure all bolts are secured with Loctite RED and tightened to recommended specifications. Verify all electrical connections are properly plugged in and functioning.
