Select your vehicle to find the exact plug-and-play parts that fit — no cutting or splicing.
DRAW-TITE Class 1 trailer hitches are the perfect mix of style and stability for those times when youre working on a home project or heading out on an adventure. This DRAW-TITE Class 1 receiver hitch is rated for up to 2,000 lbs. gross trailer weight (GTW) and up to 200 lbs. tongue weight (TW). No weight distribution kits can be used on this specific trailer hitch. DRAW-TITE hitches are designed to provide top towing performance, with solid-all-welded construction and a black powder coat finish to resist rust and corrosion. The Class 1 trailer hitch has a 1-1/4 inch square receiver tube opening so you can easily attach accessories like a bike rack or cargo carrier, or a utility trailer. Includes all the mounting hardware needed for installation and are backed by a nationwide lifetime limited warranty. DRAW-TITE trailer hitches are tested to exceed V-5 and SAE J684 standards. DRAW-TITE: North Americas Favorite Hitch.
| BRAND: | DRAW-TITE |
| PART NUMBER: | 24867 |
| WARRANTY: | LIMITED LIFETIME WARRANTY |
| WEIGHT: | 23.1 LBS |
| GROSS TOWING WEIGHT: | 2,000 LBS. |
| GROSS TONGUE WEIGHT: | 200 LBS. |
| RECEIVER SIZE: | 1.25 IN. |
| HITCH CLASS: | I |
| DRILLING REQUIRED: | NO |
| MOUNTING HARDWARE INCLUDED: | YES |
| ATTACHMENT LOCATION: | REAR |
| HITCH VISIBILITY: | VISIBLE |
| CROSS-TUBE TYPE: | SQUARE TUBE |
| BALL MOUNT INCLUDED: | NO |
| COLOR: | BLACK |
| FINISH: | BLACK POWDER COAT OVER E-COAT |
| MATERIAL: | STEEL |
| MOUNTING LOCATION: | VEHICLE FRAME |
| MOUNTING TYPE: | BOLT-ON |
Draw-Tite has designed custom-fit trailer hitches since 1946 and is one of North America's most widely fitted hitch brands. Receiver hitches use solid all-welded construction and low-profile designs that follow modern vehicle contours, install with minimal bumper cutting or drilling, meet or exceed V5 CSA and SAE J684 standards, and carry a limited lifetime warranty.
Draw-Tite has been leading custom-fit trailer hitch design and engineering since its founding in 1946, and it remains one of the most widely fitted hitch brands in North America. The company's stated approach is straightforward: every hitch is tested rigorously so that it performs well beyond published industry standards, a philosophy it markets as Tested Tough. It sits within the Horizon Global towing group alongside Reese, Fulton, Bulldog, Tekonsha, Bargman and Wesbar.
Custom fit is the defining characteristic. Rather than adapting a universal design, Draw-Tite engineers a trailer hitch for a specific make, model and model year, so it bolts to existing frame locations with minimal bumper cutting or drilling. Low-profile designs follow the rear contours and aerodynamic styling of modern vehicles, which matters more than it once did now that rear fascias are shaped and sensor-equipped. Construction is solid all-welded steel for maximum strength, and every hitch meets or exceeds V5 CSA and SAE J684 standards and is backed by a nationwide limited lifetime warranty.
The range spans receiver sizes and classes to suit different loads, from 1-1/4 inch receivers for bike racks, cargo carriers and light trailers up through 2 inch receivers for heavier towing. Front mount hitches add a receiver at the front of the vehicle for winch mounts, snow plows, spare carriers and precise trailer positioning.
The Hidden Hitch series takes concealment further by mounting behind the vehicle's rear fascia, so the vehicle keeps its factory appearance until a removable receiver is fitted. Each is custom designed per make and model for a no-drill installation that does not compromise ground clearance, rated for up to 3,500 pounds gross trailer weight and 350 pounds tongue weight. Matching plug-and-play wiring completes the towing system.
Experts available to answer your questions
Call 888-634-9494Lifetime
Draw•Tite® and the Checkered Flag Foundation
1 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2011 - 2017 | Nissan JUKE | Class 1 Trailer Hitch: 2000 lbs 200/2,000 lbs. Weight Carrying (tongue weight/gross trailer weight) Uses all existing holes. No Drilling required Install Time is 40 minutes |
The Draw-tite Class 1 Trailer Hitch, 1-1/4" Square Receiver, Black for Select Nissan JUKE 24867 (Part #DT24867) fits the following vehicles: 2011-2017 Nissan JUKE. Always verify your specific year, make, and model before ordering.
The Draw-tite Class 1 Trailer Hitch, 1-1/4" Square Receiver, Black for Select Nissan JUKE 24867 (Part #DT24867) fits 2011-2017 Nissan JUKE models. The 2017 model year is the last year covered by this part number. For newer models, check for an updated version.
Yes, the Draw-tite Class 1 Trailer Hitch, 1-1/4" Square Receiver, Black for Select Nissan JUKE 24867 (Part #DT24867) is designed to fit the 2011-2017 Nissan JUKE.
The Draw-tite Class 1 Trailer Hitch, 1-1/4" Square Receiver, Black for Select Nissan JUKE 24867 (Part #DT24867) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
Part number 24867 is designed for Nissan Juke AWD models from 2010, 2011, and 2015. Confirm your vehicle year and that it is AWD before purchasing. The manual does not confirm fitment for other years or FWD models.
The maximum gross trailer weight is 2000 LB (908 kg) and the maximum tongue weight is 200 LB (90.8 kg). Do not exceed the lower of the towing vehicle manufacturer's rating or these limits.
You will need wrenches in 17mm, 18mm, and 19mm sizes, a 6" extension, and a torque wrench. You will also need lubricant or soapy water to help remove the exhaust system rubber isolators.
Yes. Step 1 requires you to remove and return the factory tow hook and its 4 bolts to the vehicle owner before proceeding with hitch installation.
Yes. Step 2 requires you to lower the exhaust system at the rubber isolator in 3 places, leaving the rubber isolator attached to the muffler. Spray lubricant or soapy water on the metal hanger rod and rubber isolator to help removal, and support the system to prevent the muffler from falling under its own weight.
Yes. Step 3 requires you to scrape undercoating and caulking from the bottom of the frame rails in an area large enough to allow the hitch brackets to sit flush against the frame rails. You must also clean out undercoating from the weldnuts without damaging the threads, and confirm that an M10 hex bolt will thread into the weldnuts.
Step 4 requires you to raise the hitch into position on the driver's side and loosely install a hex bolt and conical washer through the elongated hole in the hitch into the vehicle frame. Repeat on the passenger's side. Then center the hitch on the vehicle and install the remaining hardware as shown in the diagram.
All M10 CL 8.8 fasteners must be tightened to 39 Lb.-Ft. (52 N*M) using a torque wrench.
All M12 CL 8.8 fasteners must be tightened to 68 Lb.-Ft. (92 N*M) using a torque wrench.
The hitch includes: 2 × M12 × 1.25 × 35mm CL8.8 hex bolts, 2 × M10 × 1.25 × 30mm CL8.8 hex bolts, 2 × 1/2" conical washers, and 2 × 3/8" conical washers. Additional fasteners are available in kit 24867F.
Yes. Step 6 requires you to reinstall the exhaust system after all hitch fasteners have been tightened to the required torque specifications.
Observe safety precautions when working beneath the vehicle and wear eye protection. Do not cut access or attachment holes with a torch. Do not allow the muffler to fall under its own weight when lowering the exhaust system. Support the exhaust system while removing all rubber hangers.
Check the hitch frequently to ensure all fasteners and the ball are properly tightened. If the hitch is removed, plug all holes in the trunk pan or other body panels to prevent entry of water and exhaust fumes.
The drawbar must be used in the rise position only. Do not use it in any other position.
A hitch or ball which has been damaged should be removed and replaced. Do not continue to use a damaged hitch or ball.
No. The drawbar is sold separately as kit 3593. You will need to purchase this separately if you require a drawbar.
No. The fascia is sold separately. You will need to purchase it separately if you require one.
Yes, part 24867 fits Nissan Juke AWD models from 2010, 2011, and 2015 only. Confirm your year and AWD drivetrain before purchasing.
You need 17mm, 18mm, and 19mm wrenches, a 6" extension, a torque wrench, and lubricant or soapy water for exhaust removal.
Yes, remove and return the factory tow hook and its 4 bolts to the vehicle owner before installing the hitch.
Yes, lower the exhaust at the rubber isolator in 3 places, leaving the isolator attached to the muffler. Use lubricant or soapy water and support the system to prevent it from falling.
M10 CL 8.8 bolts: 39 Lb.-Ft. (52 N*M). M12 CL 8.8 bolts: 68 Lb.-Ft. (92 N*M). Use a torque wrench for all fasteners.
Maximum gross trailer weight is 2000 LB (908 kg) and maximum tongue weight is 200 LB (90.8 kg). Do not exceed your vehicle manufacturer's rating.
The drawbar must be used in the rise position only. The drawbar is sold separately as kit 3593.
