Fulton single speed winches are designed to meet your toughest pulling demands. Featuring solid drum gear construction, factory-lubricated drive systems, and industry-leading Z-MAX 600 high performance zinc finish.
| BRAND: | FULTON |
| PART NUMBER: | 142208 |
| WARRANTY: | LIMITED 5 YEAR WARRANTY |
| WEIGHT: | 8.5 LBS |
| CAPACITY: | 1,500 LBS. |
| UNIVERSAL OR SPECIFIC FIT: | UNIVERSAL |
| TYPE: | SINGLE SPEED |
| WATERPROOF: | YES |
| HOOK INCLUDED: | YES |
| HOOK TYPE: | CLEVIS SAFETY HOOK |
| CABLE LENGTH: | 20 FT. |
| BRAKE ACTIVATION: | MANUAL |
| HANDLE TYPE: | 8 IN. OFFSET |
| RATED LINE PULL: | 1,500 LBS. |
| GEAR MATERIAL: | STEEL |
| MATERIAL: | STEEL |
| NUMBER OF STRAPS: | 1 |
| FREE SPOOLING: | YES |
| HARDWARE INCLUDED: | YES |
| HOUSING MATERIAL: | PLASTIC - COVER |
| TREE SAVER: | NO |
| FRAME MATERIAL: | STEEL |
| COLOR: | SILVER |
Fulton has produced marine and utility trailer hardware for more than a century, and its jacks, winches and couplers are a standard for light and medium-duty trailering. The XLT and F2 series cover swivel and fixed jacks, hand and powered winches from 1,500 to 3,200 pounds, and couplers built to keep working in wet, salty conditions.
With more than a hundred years of production behind it, Fulton has become the reference point for light and medium-duty trailer hardware, particularly on the marine side. That environment is the toughest test a trailer component faces. A boat trailer is reversed into fresh or salt water on every launch and left to sit wet, which finds every weakness in plating, sealing and material choice. Fulton's stated position is that the brand performs best when the weather is at its worst, and its product engineering reflects that. It sits within the Horizon Global towing group alongside Reese, Draw-Tite, Bulldog, Tekonsha and Wesbar.
Marine and utility jacks anchor the line. The XLT Series marine jack uses a bolt-through swivel mount built from three-dimensionally formed heavy-gauge steel stampings with a proprietary bushing material, a combination chosen to minimise deflection under tongue load while keeping the swivel action working after years of exposure. The F2 Series takes corrosion resistance further as the industry's only extruded aluminium marine jack with an anodised finish, which removes the rust problem at its source rather than coating over it. The wider trailer jack range covers topwind, sidewind and drop-leg configurations.
Trailer winches pull boats onto bunks and rollers. XLT Series winches use efficient gear ratios, full-length drum bearings, oil-impregnated shaft bushings and a Comfort Grip handle that makes the last few turns under load bearable, in 1,500 and 1,800 pound capacities. F2 Series winches use an enclosed frame for a cleaner look and added protection, in 1,600, 2,000 and 3,200 pound models, including two-speed options that trade line speed for cranking effort.
Couplers complete the range, including A-frame couplers matched to common tongue sizes and load ratings, serving boat owners, utility trailer users and trailer manufacturers.
Experts available to answer your questions
Call 888-634-94945 Years
Cequent trailer winches are available in capacities ranging from 900 lbs to 3700 lbs. Specific capacity depends on the model. Single-speed models are available in 900, 1100, 1300, 1500, 1800, 2000, 2600, and 3200 lbs capacities. Two-speed models are available in 2000, 2600, 3200, and 3700 lbs capacities. Always refer to the stamped markings or decals on your specific winch to confirm its rated capacity, or contact Cequent Performance Products at 1-800-632-3290 or www.cequentgroup.com if uncertain.
No. Only winches with a drum hub diameter of 1 3/4" can accommodate steel cable. Winches designed for steel cable have a larger drum hub to reduce bending fatigue and extend cable life. Check the Winch Information Chart to confirm your model's drum hub diameter. If your winch shows a drum hub diameter of 1 3/4", it can use steel cable. Models with smaller hub diameters are designed for rope or strap only.
Cequent trailer winches support three line attachment methods: rope, strap, or steel cable. Rope requires no bolts, nuts, or clamps—it weaves through the drum outer wall and is secured beneath itself. Strap uses a cross bolt through holes in the drum; a grade-5 bolt of the largest possible diameter is required. Steel cable is only available on winches with a 1 3/4" drum hub diameter; it passes through dimpled holes in the outer plate and is secured with a clamp. Check your winch model in the Winch Information Chart to see which options are available.
Mounting hardware is not supplied with the winch. You must provide three 3/8" diameter grade-5 bolts. The bolts vary in length depending on your specific application and mounting surface. The winch stand or frame must be capable of supporting at least five times the rated capacity of the winch. The mounting surface must be equal to or greater than the footprint of the winch frame. Consult your mounting structure specifications to determine the correct bolt length for your installation.
The mounting surface must be equal to or greater than the footprint of the winch frame. The winch stand or frame must be capable of supporting at least five times the rated capacity of the winch. Measure the frame footprint of your specific winch model and ensure your mounting structure meets or exceeds these dimensions before installation.
Attaching a rope requires no bolts, nuts, or clamps. The rope must weave through the drum outer wall and be secured beneath itself, as shown in the manual illustration. Always maintain a minimum of three complete wraps of rope on the drum. The rope is self-securing through the weaving method and does not require additional fasteners.
Winches designed for strap have holes in the drum to accommodate a strap cross bolt. Use a grade-5 bolt of the largest possible diameter available for your winch model (see the Winch Information Chart for your model's strap bolt size). Tighten the locknut just to where end play in the bolt is taken up; over-tightening can deform the drum. If your winch includes a strap anchor, pass the strap loop under the cross bolt, insert the strap anchor in the strap loop, then pull tight. Always maintain a minimum of three complete wraps or layers of strap on the drum.
If attaching a strap without a strap anchor to a plastic-covered winch, first remove the drum bolt and gently separate the plastic cover to allow the winch drum to be removed. Install the strap according to the standard strap attachment instructions, then re-install the winch drum as it was before. This allows access to the drum's strap attachment holes while protecting the plastic cover from damage.
Pass the cable from the inside of the drum through one of the dimpled holes in the outer plate. Loop the cable around the drum bearing, under itself, and leave 1" of cable extending past the clamp location. Tighten the clamp nuts to approximately 2 ft-lbs. Neatly wrapping the cable is necessary to reduce the chance of kinking or fraying. Always maintain a minimum of three complete wraps of cable on the drum.
Assemble the handle onto the flatted input shaft end. Tighten the 1/2" - 13 locknut against the handle and torque to 22-25 ft-lbs. Do not over-torque, as this can damage the input shaft or locknut.
When attaching the winch to the mounting structure, use three 3/8" diameter grade-5 bolts and torque them to 28-30 ft-lbs. Mounting bolts vary in length depending on your specific application. After installation, check that the winch is secure to the mounting structure.
Tighten the 1/2" - 13 handle locknut to 22-25 ft-lbs. Do not over-torque.
On single-speed winches, torque the drum locknut to 9-10 ft-lbs. Be sure not to over-tighten, as this may crush the spacer between the frame and keep the drum from turning.
On two-speed winches, torque the drum locknut to 24 ft-lbs. Be sure not to over-tighten, as this may crush the spacer between the frame and keep the drum from turning.
Tighten the clamp nuts securing the steel cable to approximately 2 ft-lbs.
Drum hub diameters vary by model: 900, 1100, 1300, 1500 lbs models have 7" or 8" hubs; 1800 lbs has 8"; 2000 lbs has 10"; 2600 lbs has 10"; 3200 lbs has 10"; and 3700 lbs has 10". Refer to the Winch Information Chart for your specific model's drum hub diameter. Only winches with a 1 3/4" drum hub diameter can accommodate steel cable.
Strap bolt sizes vary by model. Single-speed models use: M6 x 65mm (metric) or 1/4" x 2-3/4" (standard) for 900 lbs; M8 x 66mm (metric) or 5/16" x 2-3/4" (standard) for 1100, 1300, 1500, and 1800 lbs. Two-speed models use: 3/8" x 2-3/4" (standard) for 2000, 2600, 3200, and 3700 lbs. Refer to the Winch Information Chart for your specific model. Always use a grade-5 bolt of the largest possible diameter for your model.
Handle lengths vary by model: 900, 1100, 1300, 1500 lbs models have 7" handles; 1800 lbs has 7"; 2000, 2600, 3200, and 3700 lbs models have 10" handles. Refer to the Winch Information Chart for your specific model.
Gear ratios vary by model and speed. Single-speed models range from 3.25:1 to 4.1:1. Two-speed models have dual ratios such as 4.1:1 & 9.8:1 or 5.1:1 & 12.2:1. Refer to the Winch Information Chart for your specific model's gear ratio.
Storage capacity depends on the line type and model. For example, the 900 lbs model stores 36' x 1/4" rope or 15' x 2" strap. The 3700 lbs cable-only model stores 185' x 7/32" cable. Refer to the Winch Information Chart for your specific model's rope, cable, and strap storage capacities. Note that capacity is based on direct line pull on the first layer; capacity reduces as line builds up on the drum.
Winches require a maximum of 45 lbs of handle force to pull their rated load. If you cannot crank the winch with one hand, you are potentially overloading the winch. Excessive force in turning the winch handle may indicate overload. Never attempt to operate the winch beyond its rated capacity.
Always maintain a minimum of three complete wraps of rope, strap, or cable on the drum. This ensures proper line engagement and safe operation. Never allow the drum to become completely unwound.
A loud clicking sound from the ratchet must be heard when lifting the load. This indicates the ratchet pawl is properly engaged. If a loud clicking sound is not heard, do not use the winch and replace the ratchet components immediately. Always inspect the cable, strap, or rope and its attachment before each use to ensure they are not damaged, worn, kinked, or frayed.
No. Cequent trailer winches are not designed to move people. They are designed for manual operation only and the load rating is based on an intermittent duty cycle for lifting and securing loads only.
No. Cequent trailer winches are not designed to secure boats to trailers while towing. Boat tie-downs or boat-specific securing equipment should be used for this purpose.
If you cannot crank the winch with one hand, you are potentially overloading the winch. Stop immediately and do not continue operating. Excessive force in turning the winch handle indicates overload. Winches require a maximum of 45 lbs of handle force to pull their rated load. Check that your load does not exceed the winch's rated capacity, which is stamped on the winch frame or decals.
Before use, perform these checks: (1) Inspect rope, strap, or cable and replace if damaged. (2) Check mounting hardware for proper tightness and tighten if necessary. (3) Apply a drop or two of #30 weight engine oil to each bushing I.D. and to the ratchet pawl pivot points. (4) Maintain a thin layer of chassis grease on the gear teeth. (5) Verify that a loud clicking sound is heard from the ratchet when lifting a load. (6) Ensure the winch is securely mounted to the mounting structure.
Regular maintenance includes: (1) Periodically check mounting hardware for proper torque and tighten if necessary. (2) Inspect rope, strap, or cable before each use and replace if damaged, worn, kinked, or frayed. (3) Apply a drop or two of #30 weight engine oil to each bushing I.D. and to the ratchet pawl pivot points. (4) Maintain a thin layer of chassis grease on the gear teeth. (5) Always replace bent, broken, or worn parts before using the product. (6) Check that the ratchet pawl is properly engaged and holding loads.
Use #30 weight engine oil for the bushings and ratchet pawl pivot points. Apply a drop or two to each bushing I.D. and to the ratchet pawl pivot points. Maintain a thin layer of chassis grease on the gear teeth.
A loud clicking sound from the ratchet must be heard when lifting the load. If you do not hear this sound, the ratchet pawl is not properly engaged. Do not use the winch. Replace the ratchet components immediately. Contact Cequent Performance Products at 1-800-632-3290 for replacement parts.
Excessive force in turning the winch handle may indicate overload. Winches require a maximum of 45 lbs of handle force to pull their rated load. If the handle is difficult to turn, check that your load does not exceed the winch's rated capacity. If you cannot crank the winch with one hand, you are potentially overloading it. Stop operating immediately and reduce the load. If the handle remains difficult to turn after reducing the load, the winch may require maintenance or repair; contact Cequent Performance Products at 1-800-632-3290.
If the drum is not turning, the drum locknut may be over-tightened. Over-tightening can crush the spacer between the frame and prevent the drum from turning. For single-speed winches, the drum locknut should be torqued to 9-10 ft-lbs. For two-speed winches, torque to 24 ft-lbs. If the drum locknut is properly torqued and the drum still does not turn, the winch may require repair; contact Cequent Performance Products at 1-800-632-3290.
Never use a damaged, worn, kinked, or frayed cable, strap, or rope. If the cable or attachment breaks during operation, the cable will whip violently, causing property damage, serious bodily injury, and/or death. Always inspect the cable, strap, or rope and its attachment before each use. If damage is found, replace the line immediately before using the winch. Contact Cequent Performance Products at 1-800-632-3290 for replacement line.
Cequent trailer winches are available in capacities from 900 to 3700 lbs. Check your trailer's specifications and the winch's rated capacity (stamped on the frame or decals). The winch stand must support at least 5 times the rated capacity, and the mounting surface must equal or exceed the winch frame footprint. Contact Cequent at 1-800-632-3290 if you need help selecting the right model.
You need three 3/8" diameter grade-5 bolts. Bolt length varies by application. Mounting hardware is not supplied; you must provide the bolts. Torque them to 28-30 ft-lbs.
Torque the three 3/8" diameter grade-5 mounting bolts to 28-30 ft-lbs. After installation, verify the winch is secure to the mounting structure.
Torque the 1/2" - 13 handle locknut to 22-25 ft-lbs. Do not over-torque.
Never exceed the maximum rated capacity stamped on the winch frame or decals. Capacities range from 900 to 3700 lbs depending on model. If uncertain of your winch's capacity, contact Cequent Performance Products at 1-800-632-3290 or www.cequentgroup.com.
Before each use: (1) Inspect the cable, strap, or rope and attachment for damage. (2) Check mounting hardware tightness. (3) Verify a loud clicking sound is heard from the ratchet when lifting. (4) Ensure at least three complete wraps of line are on the drum. Never use if the line is worn, kinked, or frayed.
Periodically check mounting hardware torque and tighten if necessary. Before each use, inspect the line and attachment for damage. Apply #30 weight engine oil to bushings and ratchet pawl pivot points, and maintain a thin layer of chassis grease on gear teeth. Always replace bent, broken, or worn parts before use.
A loud clicking sound from the ratchet must be heard when lifting the load. If no clicking is heard, the ratchet pawl is not properly engaged. Do not use the winch. Replace the ratchet components immediately. Contact Cequent Performance Products at 1-800-632-3290 for replacement parts and further assistance.
Excessive force in turning the winch handle indicates overload. Winches require a maximum of 45 lbs of handle force to pull their rated load. Check that your load does not exceed the winch's rated capacity (stamped on the frame or decals). If the load is within capacity and the handle remains difficult to turn, the winch may have internal damage or require lubrication. Apply #30 weight engine oil to bushings and ratchet pawl pivot points, and maintain a thin layer of chassis grease on gear teeth. If the problem persists, contact Cequent Performance Products at 1-800-632-3290.
If the drum is not turning, the drum locknut may be over-tightened. Over-tightening can crush the spacer between the frame and prevent the drum from turning. Check the drum locknut torque: for single-speed winches, it should be 9-10 ft-lbs; for two-speed winches, 24 ft-lbs. Loosen the locknut if over-tightened and re-torque to the correct specification. If the drum still does not turn after proper torque adjustment, the winch may require repair; contact Cequent Performance Products at 1-800-632-3290.
Never use a worn, kinked, or frayed cable, strap, or rope. If the cable or attachment breaks during operation, the cable will whip violently, causing property damage, serious bodily injury, and/or death. Always inspect the cable, strap, or rope and its attachment before each use. If damage is found, replace the line immediately before using the winch. Contact Cequent Performance Products at 1-800-632-3290 for replacement line.
The ratchet pawl must be fully engaged and holding the load before you release the handle. If the load is not held, the ratchet pawl may not be properly engaged. Ensure the ratchet pawl is in the forward or loading position. If the ratchet pawl is engaged but the load still drops, the ratchet components may be worn or damaged. Do not use the winch and replace the ratchet components immediately. Contact Cequent Performance Products at 1-800-632-3290.
On Sale Today
Original price was $100.00. Current price is $76.19.You save $23.81 (24%)
Free Shipping
Ships free on all orders
Authorized Dealer
FREE ShippingFREE SHIPPING
Estimated delivery Tue, Aug 11 - Fri, Aug 14
Order before 2 PM EST Monday–Friday for same-day processing
Guaranteed safe & secure checkout
George
Ordered online. Shipment arrived on time and with all the correct parts. Great customer service and friendly staff. Also, pricing was great!
May 22, 2023
| Part Number | Capacity (lbs.) | Handle Length (in.) | Max Mechanical Advance* | Rope (ft. x in.) | Strap (ft. x in.) | Recommended Strap Bolt Sizes (in.) | Strap Included | Finish |
|---|---|---|---|---|---|---|---|---|
| 142001 | 900 | 7.00 | 39:1 | 36 x 1/4 | 15 x 2 | 1/4 x 2-1/2 Grade 5 | No | Clear Zinc |
| 142002 | 900 | 7.00 | 39:1 | 36 x 1/4 | 15 x 2 | 1/4 x 2-1/2 Grade 5 | No | Clear Zinc |
| 142003 | 900 | 7.00 | 39:1 | 36 x 1/4 | 15 x 2 | 1/4 x 2-1/2 Grade 5 | Yes | Clear Zinc |
| 142006 | 900 | 7.00 | 39:1 | 36 x 1/4 | 15 x 2 | 1/4 x 2-1/2 Grade 5 | Yes | Clear Zinc |
| 142007 | 900 | 7.00 | 39:1 | 36 x 1/4 | 15 x 2 | 1/4 x 2-1/2 Grade 5 | Yes | Clear Zinc |
| 142026 | 1,100 | 7.00 | 43:1 | 30 x 5/16 | 20 x 2 | 1/4 x 2-1/2 Grade 5 | No | Glossy Black |
| 142101 | 1,100 | 8.00 | 43:1 | 30 x 5/16 | 20 x 2 | 1/4 x 2-1/2 Grade 5 | No | Clear Zinc |
| 142102 | 1,100 | 8.00 | 43:1 | 30 x 5/16 | 20 x 2 | 1/4 x 2-1/2 Grade 5 | No | Clear Zinc |
| 142103 | 1,300 | 8.00 | 49:1 | 30 x 5/16 | 20 x 2 | 1/4 x 2-1/2 Grade 5 | No | Clear Zinc |
| 142104 | 1,300 | 8.00 | 49:1 | 30 x 5/16 | 20 x 2 | 1/4 x 2-1/2 Grade 5 | No | Clear Zinc |
| 142200 | 1,500 | 8.00 | 49:1 | 20 x 5/16 | 20 x 2 | 1/4 x 2-1/2 Grade 5 | Yes | Clear Zinc |
| 142201 | 1,500 | 8.00 | 49:1 | 20 x 5/16 | 20 x 2 | 1/4 x 2-1/2 Grade 5 | Yes | Clear Zinc |
| 142203 | 1,500 | 8.00 | 49:1 | 20 x 5/16 | 20 x 2 | 1/4 x 2-1/2 Grade 5 | Yes | Clear Zinc |
| 142204 | 1,500 | 8.00 | 49:1 | 20 x 5/16 | 20 x 2 | 1/4 x 2-1/2 Grade 5 | No | Clear Zinc |
| 142208 | 1,500 | 8.00 | 49:1 | 20 x 5/16 | 20 x 2 | 1/4 x 2-1/2 Grade 5 | No | Glossy Black |
| 142226 | 1,800 | 8.00 | 62:1 | 20 x 7/16 | 20 x 2 | 3/8 x 2-3/4 Grade 5 | No | Clear Zinc |
| 142300 | 1,800 | 8.00 | 62:1 | 20 x 7/16 | 20 x 2 | 3/8 x 2-3/4 Grade 5 | No | Clear Zinc |
| 142303 | 1,800 | 8.00 | 62:1 | 20 x 7/16 | 20 x 2 | 3/8 x 2-3/4 Grade 5 | No | Clear Zinc |
| 142306 | 1,800 | 8.00 | 62:1 | 20 x 7/16 | 20 x 2 | 3/8 x 2-3/4 Grade 5 | No | Clear Zinc |
| 142326 | 1,800 | 8.00 | 62:1 | 20 x 7/16 | 20 x 2 | 3/8 x 2-3/4 Grade 5 | No | Clear Zinc |
